AMacro-condenser test of reflection converged paraboloid
-
摘要: 目前反射式抛物面的检测主要是利用光的干涉法测量抛物面的光程来实现，虽然精度比较高，但却只能检测抛物面的光滑程度，而对抛物面的聚光效果无能力。该文从基本原理出发，重申反射式抛物面的聚焦成像本质，进而指出确定其聚光精度的关键是反射面各点的面积元方向与入射光的夹角关系，而不是光程关系。同时给出了应用特大口径平行光源或特大口径平行光源组合直接对反射抛物面进行检测的方法，它可以定性地检测出抛物面宏观的聚光效果和成像质量。Abstract: Test of parabolic mirror is often completed by measuring the optical path length. Though it is highly accurate, it can only detect the smoothness instead of light convergence. Based on the basic principals, this paper describes the nature of convergence for parabolic mirror. It points out that convergence accuracy depends only on the angle between the direction vectors of surface elements and the incident ray instead of optical path length. Inthe end, methods for testing parabolic mirrors by collimated flood light sourceare provided.
-
Keywords:
- parabolic /
- interference of light /
- light condensation /
- collimated light
-
-
［1］权贵秦,安毓英,李庆国. 激光干涉法检测大口径抛物面反射镜［J］.光子学报,2008,37(10):2035-2038.QUAN Gui-qin, AN Yu-ying,LI Qing-guo. Test of large aperture parabola mirror by laser interferometric［J］.Acta Phoponica Sinica, 2008, 37(10):2035-2038. (in Chinese with an English abstract)
［2］章邦基,胡炳生.旋转抛物面焦域的聚焦核曲面及其方程［J］.安徽师范大学学报：自然科学版，1985（1）:15-18.ZHANG Bang-ji,HU Bing-sheng. On the study of surface and It’s equation of the focal kernel of the parabolid of revolution［J］. Journal of Anhui Normal University：-Natural Science，1985（1）:15-18. (in Chinese with an English abstract)
［3］王孝坤，郑立功，张斌智,等.子孔径拼接检测大口径非球面技术的研究［J］.应用光学,2009,30(2):273-278. WANG Xiao-kun，ZHANG Li-gong，ZHANG Bin-zhi, et al.Testing of large aspheric surfaces by sub aperture stitching interferometry［J］.Journal of Applied Optics,2009,30(2):273-278.(in Chinese with an English abstract)
［4］张斌,王鸣,马力.非球面光学测试技术［J］.南昌大学学报：工科版,2003,25(2):51-54.ZHANG Bin, WANG Ming,MA Li. Optical testing technique for aspherical surface［J］.Journal of Nanchang University：-Engineering ＆-Technology, 2003,25(2):51-54.(in Chinese with an English abstract)
