快速匹配算法在药筒模块检测中的应用

郭栋; 董友; 王明泉; 高远飞

快速匹配算法在药筒模块检测中的应用

郭栋^1, ,,
董友²,
王明泉¹,
高远飞¹

1.
中北大学仪器科学与动态测试教育部重点实验室,山西太原030051;
2.
朔州市朔城区第一中学,山西太原036000

详细信息

通讯作者:
郭栋(1983-)，男，江苏徐州人，硕士研究生，主要研究方向：信息处理与重建。

中图分类号: TN911.73；TP751.1
计量
- 文章访问数: 2848
- HTML全文浏览量: 107
- PDF下载量: 680
- 被引次数: 0
出版历程
- 刊出日期: 2010-07-15

Fast matching algorithm in cartridge module detection

1.
The Ministry Education Key Lab for Instrumentation Science and Dynamic Test,North University of China,Taiyuan 030051,China;
2.
No.1 Middle School of Shuocheng District,Shuozhou 036000,China

摘要

摘要: 为了能够快速、准确判断药筒模块是否合格，实现检测的自动化，针对药筒模块中可燃性紧塞盖图像的特点和检测要求，在研究经典相关系数匹配算法基础上，采用了一种快速图像匹配算法，即通过减少相关系数计算量和模板搜索范围，在保证匹配准确度的前提下来提高图像匹配速度。实验和现场测试表明，使用该方法，匹配速度提高了近67%，实现了图像的快速匹配，软件误判率＜1%,满足实际生产要求。
- 图像匹配 /
- 药筒模块 /
- 相关系数 /
- 搜索范围
Abstract: In order to quickly, automatically and accurately judge whether the cartridge module is qualified, according to the combustible tight plug cover image of cartridge module and the detection requirements, a fast image matching algorithm based on classical correlation coefficient matching algorithm is used to reduce the correlation coefficient calculation and template matching search scope, and the speed of the image matching is increased without sacrificing the matching accuracy. Field test shows that this method can rapidly and accurately complete target detection, false rate＜1%, matching speed increased by 67%, which meet the production requirements.
- image matching /
- cartridge module /
- correlation coefficient /
- search scope

HTML全文

参考文献(1)

［1］容观澳.计算机图像处理［M］.北京：清华大学出版社,2002.
RONG Guan-ao. Computer image processing［M］. Beijing:Tsinghua University Press,2002.(in Chinese)
［2］李卓,邱慧娟.基于相关系数的快速图像匹配研究［J］.北京理工大学学报,2007,11(27):998-1000.
LI Zhuo,Qiu Hui-juan. Fast image matching based on the correlation coefficient［J］.Journal of Beijing Institute of Technology,2007,11(27):998-1000.(in Chinese with an English abstract)
［3］董安国.图像匹配最大互相关快速算法［J］.浙江万里学院学报,2005,18(4):13-15.
DONG An-guo. The fast algorithm of maximum cross-correlation algorithm for image match［J］.Journal of Zhejiang Wanli University ,2005,18(4):13-15. (in Chinese with an English abstract)
［4］王兵.基于差分矩因子的灰度图像矩快速算法［J］.计算机学报,2005,28(8):1367-1372.
WANG Bing. A new algorithm of fast computing geometric moments for gray level image based on differential moments factor［J］. Chinese Journal of Computers,2005,28(8):1367-1372.( in Chinese with an English abstract)
［5］刘锦峰.图像模板匹配快速算法研究［D］.长沙：中南大学,2007,5:21-24.
LIU Jin-feng. Study on fast image template matching algorithm［D］.Changsha: Central South University Scientific Dissertation,2007,5:21-24. (in Chinese)
［6］张遂南,黄士坦.图像匹配最大互相关算法的专用ASIC硬件实现方法研究［J］.电子技术应用,2001(7):69-71.
ZHANG Sui-nan,HUANG Shi-tan. The image matching algorithm of one’s special hardware ASIC research［J］.Application of ElectronicTechnique,2001(7):69-71.(in Chinese with an English abstract)
［7］刘杰，安博文.基于动态阈值分割的目标提取技术［J］.红外技术,2008(12):707-708.
LIU Jie,AN Bo-wen. Object extraction technique based on dynamic threshold segmentation［J］. Infrared Technology, 2008(12):707-708. (in Chinese with an English abstract)
［8］KASS M, WITKIN D. Terzopoulos. Snake: active contour models［J］.International Journal of Computer Vision,1998,1(4):321-331.
