极大口径光学望远镜凸非球面副镜的补偿检测法研究

李洋; 李新南

极大口径光学望远镜凸非球面副镜的补偿检测法研究

李洋^1,2,3, ,,
李新南^1,2

1.
中国科学院国家天文台南京天文光学技术研究所,江苏南京 210042;
2.
中国科学院天文光学技术重点实验室,江苏南京 210042;
3.
中国科学院研究生院,北京 100049

详细信息

通讯作者:
李洋（1985－），女，吉林磐石人，硕士研究生，主要从事大口径非球面光学检测与光学系统设计。

中图分类号: P111.2;TH706
计量
- 文章访问数: 3608
- HTML全文浏览量: 167
- PDF下载量: 577
- 被引次数: 0
出版历程
- 刊出日期: 2012-05-15

Null compensator for convex secondary asphere of very large optical telescope

LI Yang^{1,2,3
, ,},
LI Xin-nan^1,2

1.
National Astronomical Observatories / Nanjing Institute of Astronomical Optics &Technology,CAS,Nanjing 210042,China;
2.
Key Laboratory of Astronomical Optics &Technology,CAS,Nanjing 210042,China;
3.
Graduate University of Chinese Academy of Science,Beijing 100049,China

摘要

摘要: 提出了一种检测大口径、快焦比凸双曲面反射镜的补偿检验方法，补偿系统由一组小透镜和一块大口径反射标准镜组成，标准镜的口径约为被检验镜的1.8倍，该方法为极大口径光学望远镜凸非球面副镜的检验提供了一种有效的解决方案。以美国30 m望远镜（TMT）3.1 m，F/1的凸双曲面副镜为例，进行了补偿光路的设计优化。设计结果表明，该方法可以直接检测到直径达3.1 m的大口径、快焦比凸双曲面副镜的整个表面质量，补偿系统像差被校正得很好，PV值约为/100，弥散斑直径在衍射极限范围内。
- 补偿检验 /
- 大口径 /
- 快焦比 /
- 凸双曲面镜 /
- 补偿器
Abstract: A new test for steep convex hyperboloidal secondary mirrors with large aperture and fast focus ratio is presented. It makes use of small correcting lens and an auxiliary ellipsoidal mirror which aperture is about 1.8 times as large as that of the convex mirror tested. This method is sutable for convex secondary asphere of very large aperture optical telescope. Taking TMT as an example whose surface is a convex shape with the diameter of 3.1m, fast focus ratio of F/1 and conic constant of -1.318 228, a null compensation system is successfully designed and optimized. The design results indicate that the surface quality of the steep convex hyperboloidal secondary mirror could be measured directly, in addition the aberration of the testing system is well corrected，PV is about /100 and the spot diameter is smaller than the diffraction limit. Analyses of the system-s wave-front error with respect to the change in the surface parameter of optical elements are described.
- compensation test /
- large aperture /
- fast focus ratio /
- convex hyperboloidal mirror /
- compensator

HTML全文

参考文献(1)

［1］侯溪，伍凡. 大型双曲面次镜面形检测技术现状及发展趋势［J］. 中国光学与应用光学，2010，3(4)：310-315.

HOU Xi, WU Fan. Status and trends of surface measurement technologies for large hyperboloidal secondary mirrors ［J］. Chinese Journal of Optics and Applied Optics，2010，3(4)：310-315.(in Chinese with an English abstract)

［2］SMITH W S, JONES G W. Comparison of metrology methods for large astronomical secondary mirrors ［J］. SPIE, 1994，2263:243-252.

［3］曾晶，李新南. 大口径快焦比凸双曲面拼接检测方法研究［J］. 天文研究与技术，2009，6(2)：154-157.

ZENG Jing, LI Xin-nan. Study of the tests of large aperture and fast focal ratio convex hyperboloid mirrors with a stitching method ［J］. Astronomical Research&Technology，2009，6(2)：154-157. (in Chinese with an English abstract)

［4］BURGE J H, SU P, ZHAO C. Optical metrology for very large convex aspheres ［J］. SPIE, 2008, 7018:1-12.

［5］潘君骅. 光学非球面的设计、加工与检验［M］. 苏州：苏州大学出版社，2004.

PAN Jun-hua. The design, manufacture and test of the aspherical optical surfaces ［D］. Suzhou：Suzhou University Press，2004. (in Chinese )

［6］王欣，潘君骅. 2.4米天文望远镜光学系统的设计及副镜检验的几种可能方案［J］. 云南天文台台刊, 2002, 2(2)：41-47.

WANG Xin, PAN Jun-hua. Optic system design of a 2.4m class telescope and several methods for testing the secondary mirror ［J］. Publications of Yunnan Observatory, 2002,2(2)：41-47. (in Chinese with an English abstract)

［7］伍凡. 非球面零检验的镜式补偿器设计［J］. 应用光学，1994，17(4)：12-15.

WU Fan. Design of mirror compensator for asphere null check ［J］. Journa1 of Applied Optic, 1994，17(4)：12-15. (in Chinese with an English abstract)

［8］伍凡. 非球面零检验的offner补偿器设计［J］. 应用光学，1993，16(3)：8-11.

WU Fan. Design of reflective offner compensator for null testing of aspherical surface ［J］. Journa1 of Applied Optic, 1993，16(3)：8-11. (in Chinese with an English abstract)

［9］MALACARA D. Optical shop testing-3rd ed.［M］. Hoboken：John Wiley & Sons, Inc., 2007: 355-358.

［10］张以谟. 应用光学［M］. 北京:机械工业出版社，1987.

ZHANG Yi-mo. Applied optics ［M］. Beijing:Publishing House of Electronics Industry,2008. (in Chinese )

［11］胡明勇，刘文清，张权，等. 超大相对孔径抛物面反射镜的补偿检验［J］.量子电子学报, 2006，23(2)：156-158.

HU Ming-yong, LIU Wen-qing, ZHANG Quan, et al. Testing of paraboloid mirror with super relative aperture using compensator ［J］.Chinese Journal of Quantum Electronics, 2006，23(2)：156-158. (in Chinese with an English abstract)
