一种提高干涉相位识别精度的方法

杨练根; 刘丙康; 王选择; 翟中生

doi:10.5768/JAO201536.0403006

一种提高干涉相位识别精度的方法

1.
湖北工业大学机械工程学院,湖北武汉 430068;
2.
天津大学精密测试技术及仪器国家重点实验室,天津 300072

基金项目:

国家自然科学基金(51275157;51175154);天津大学精密测试技术及仪器国家重点实验室开放基金(PIL1209)

详细信息

通讯作者:
杨练根(1965-)，男，湖南平江人，博士，教授，主要从事精密测量技术及仪器方面的研究。 Email：yanglg@mail.hbut.edu.cn

中图分类号: TH741
计量
- 文章访问数: 1602
- HTML全文浏览量: 75
- PDF下载量: 173
出版历程

Method for improving precision of interferometric phase-recognization

1.
Mechanical Engineering School,Hubei University of Technology,Wuhan 430068,China;
2.
State Key Laboratory of Precision Measuring Technology and Instruments,Tianjin University,Tianjin 300072,China

摘要

摘要: 针对开环相移驱动下的单色光干涉测量，提出一种满足四步法的高精度相位识别的方法。首先选取干涉场中存在适当相位差的两像素点，建立相移驱动单周期内两像素点灰度序列值之间的干涉方程组。运用椭圆拟合获取相应干涉方程组参数，然后通过反算序列相位确定逐点驱动步长或序列相位信息。结合序列相位信息，运用Lagrange抛物插值算法，设计计算满足四步法的4幅干涉图，并计算各像素点的初相位。最后，运用多波长算法计算表面形貌并进行误差分析。实验表明：计算得到的方波多刻线样板的Ra值为0.439 0 m，测量误差为0.23%,此方法降低了对测量条件的硬件与环境要求，满足表面形貌高精度测量的要求。
- 干涉测量 /
- 相位识别 /
- 椭圆拟合 /
- Lagrange插值
Abstract: For monochromatic light interferometry under open-loop phase shifter, a high precision method for phase recognization was developed to satisfy four-step phase-shift algorithm. Firstly two pixels with suitable phase-difference were selected from the interference field, and the interference equations of the two pixels gray values were established in one phase-shifting cycle. Secondly, the interference equations parameters could be obtained by using ellipse fitting algorithm, and the point-to-point driven step length and sequence phases could be determined through back calculation of sequence phases. Then four interference gray scales meeting the four-step phase-shift algorithm were designed and calculated through Lagrange parabolic interpolation, which were used to calculate the initial phase of every pixel. Finally, the surface topography was calculated through multi-wavelength algorithm and the measurement errors were analyzed. Experimental results show that the Ra value of square wave specimen with multiple grooves is 0.4390m, and the measurement error is 0.23%. This method decreases the requirement for hardware and environment. It can meet the high precision demands of surface topography measurement.
- interference measurement /
- phase-recognization /
- ellipse fitting /
- Lagrange interpolation

HTML全文

参考文献(1)

[1]Song L M, Dong X X, Xi J T, et al. A new phase unwrapping algorithm based on Three wavelength phase shift profilometry method[J]. Optics & Laser Technology, 2013, 45: 319-329.
[2]Takamasa S, Zhao X F, Osami S. Phaselocked phase-shifting laser diode interferometer with photothermal modulation[J]. Applied Optics, 2001, 40(13): 2126-2131.
[3]Luo Zhiyong, Chen Zhaohui, Gu Yingzi, et al. Five-bucket phase-shifting algorithm based on numerical simulation[J]. Acta Optica Sinica, 2006, 26(11): 1687-1690.
罗志勇, 陈朝晖, 顾英姿, 等. 基于数值模拟的高准确度五步相移算法研究[J]. 光学学报, 2006, 26(11):1687-1690.
[4]Jun-ichi K, Lchirou Y. Phase-shifting fringe analysis for laser diode wavelength-scanning interferometer[J]. Optical Review, 2000, 7(2): 158-163.
[5]Shan Xiaoqin, Zhu Rihong, Li Jianxin. Phase extraction for single frame interferogram based on 2D Fourier transform[J]. Journal of Applied Optics, 2013, 34(5): 802-808.
单小琴, 朱日宏, 李建欣. 基于二维傅里叶变换的单帧干涉图相位提取方法[J]. 应用光学, 2013, 34(5): 802-808.
[6]Hao Q, Zhu Q D, Hu Y. Random phase-shifting interferometry without accurately controlling or calibrating the phase shifts[J]. Optics Letters, 2009, 34(8): 1288-1290.
[7]Liu Dong, Yang Yongying, Tian Chao, et al. Study on phase retrieval from single close fringe pattern with high precision[J]. Chinese Journal of Lasers, 2010, 37(2): 531-536.
刘东, 杨甬英, 田超, 等. 高精度单幅闭合条纹干涉图相位重构技术[J]. 中国激光, 2010, 37(2): 531-536.
[8]Hui Mei. Study on the theory and algorithms of phase-stepping interferometry[D]. Xi’an: Xi’an Institute of Optics and Precision Mechanics of CAS,2001.
惠梅. 表面微观形貌测量中相移干涉术的算法与实验研究[D]. 西安：中国科学院西安光学精密机械研究所, 2001.
[9]Kamel H, Frederic C. Two-wavelength interferometry: extended range and accurate optical path difference analytical eatimator[J]. J.Opt. Soc. Am. A, 2009, 26(12): 2503-2511.
[10]Warnasooriya N, Kim M K. LED-based multi-wavelength phase imaging interference microscopy[J]. Optics Express, 2007, 15(15): 9239-9247.
[11]Christopher J M, Philip R B, Vincent C P. Quantitative phase imaging by three-wavelength digital holography[J]. Optics Express, 2008, 16(13): 9753-9764.
[12]Nilanthi W, Myung K K. Quantitative phase imaging using three-wavelength optical phase unwrraping[J]. Journal of Modern Optics, 2009, 56(1): 67-74.

(上接第571页)

陶本藻，姚宜斌. 基于多面核函数配置型模型的参数估计[J].武汉大学学报：信息科学版，2003,28（5）：547-550
[15]Cao Tianning,Bai Jian, Kong Yanbo. Application of CQG-Ⅱshop digital interferometer in several special testing cases[J]. Optical Technology,2001,27(6):562-563.
曹天宁，白剑，孔燕波.CGQ-II车间数字干涉仪的几种特殊检测的应用[J].光学技术，2001,27(6):562-563.
