积分球辐射光源照度均匀性研究

赫英威; 李平; 吴厚平; 李成; 熊利民

积分球辐射光源照度均匀性研究

中国计量科学研究院光学与激光计量科学研究所,北京 100013

详细信息

通讯作者:
赫英威(1982-),男，满族，黑龙江大庆人，博士，主要从事光学精密测量及太阳能光伏计量相关工作。

中图分类号: TN201; TB96
计量
- 文章访问数: 3984
- HTML全文浏览量: 186
- PDF下载量: 1615
出版历程
- 刊出日期: 2012-05-14

Output irradiance uniformity of integrating sphere source

Division of Metrology in Optics and Laser,National Institute of Metrology,Beijing 100013,China

摘要

摘要: 针对CCD等焦面阵列光电器件常被置于积分球辐射光源出口平面进行测试的误区，研究了积分球辐射光源照度分布的均匀性，得到了合理使用积分球光源测试光电器件的依据。基于数值解析方法和蒙特卡罗方法，建立了理想积分球辐射光源照度均匀性数学模型和非理想积分球辐射光源照度均匀性仿真模型，分析了与积分球光源出口不同距离处光电器件受光面上照度分布情况，并实验测试了两套积分球辐射光源照度分布情况，得到了与积分球辐射光源不同距离处光电器件受光面上照度均匀性分布规律。研究表明：当光电器件受光面直径小于积分球光源出口直径一半、光电器件和积分球出口之间的距离与积分球出口直径的比值在3至5之间时，可在光电器件受光面上获得均匀性优于99%的照度场。
- 光学测试 /
- 积分球 /
- 照度均匀性 /
- 光电器件 /
- 标定
Abstract: Regarding to the mistake that the focal plane array optoelectronic devices such as CCD were often placed on the exit port plane of integrating sphere source to perform calibration, the output irradiance uniformity of integrating sphere source was analyzed, and the basis on which the integrating sphere source was used rationally to calibrate the optoelectronic devices was obtained. Two theoretical output irradiance uniformity models based on numerical analysis method and Monte Carlo method were developed respectively. The models considered two fundamental situations of integrating sphere sources, namely ideal Lambertian source and non-ideal Lambertian source. The distribution regularity of irradiance uniformity was generalized by contrast of the theoretical data obtained by the models and the measured data obtained by two different actual integrating sphere sources. The results show that when the diameter of optoelectronic device is less than the half of the sphere exit port diameter and the ratio of the distance between device and exit port to the exit port diameter is 3~5, a 99% better output irradiance uniformity can be obtained.
- optical measurement /
- integrating sphere /
- irradiance uniformity /
- optoelectronic device /
- calibration

HTML全文

参考文献(1)

［1］CLARE J F. Comparison of four analytic methods for the calculation of irradiance in integrating spheres［J］. Journal of the Optical Society of America a-Optics Image Science and Vision, 1998,15(12): 3086-3096.

［2］FINKEL M W. Integrating sphere theory［J］. Optics Communications, 1970, 2(1): 25-28.

［3］SCHAEPMAN M E, DANGEL S. Solid Laboratory Calibration of a Nonimaging Spectroradiometer［J］. Appl. Opt., 2000,39(21): 3754-3764.

［4］徐秋云, 郑小兵, 张伟，等. 利用可调谐激光的积分球光源辐射特性测试［J］. 光学学报, 2009, 29(5):1310-1314.

XU Qiu-yun,ZHENG Xiao-bing,ZHANG Wei,et al.Radiometric characteristics test of integrating sphere source using wavelength-tunable laser［J］. Acta Opti-ca Sinica, 2009,29(5): 1310-1314.(in Chinese with an English abstract)

［5］杨永本, 张黎明, 陈洪耀,等. 可见短波红外高光谱星上定标用积分球系统的设计［J］.光学学报, 2009, 29(12):3545-3550.

YANG Yong-ben,ZHANG Li-ming,CHEN Hong-yao, et al.System design of the integtating sphere uUsed for on-board calibration of visible-SWIR hyperspectral remote sensors［J］. Acta Optica Sinica, 2009,29(12): 3545-3550.(in Chinese with an English abstract)

［6］刑进, 王淑荣, 李福田. 空间紫外遥感光谱辐射计光谱辐亮度定标三种方法的比较［J］. 中国激光, 2006, 33(4):509-515.

XING Jin,WANG Shu-rong,LI Fu-qian.Comparison of spectral radiance calibrations of spectroradiometer for ultraViolet space remote sensing using three calibration techniques［J］. Chinese Journal of Lasers, 2006. 33(4): 509-515.(in Chinese with an English abstract)

［7］邹思成, 王钢. 大天区面积多目标光纤光谱天文望远镜科学级CCD相机低噪声设计和检测［J］. 兵工学报, 2008, 29(4): 434-439.

ZOU Si-cheng,WANG Gang. Development and test of scientific CCD camera for large sky area multi-object fiber spectroscopic telescope［J］. Acta Armamentarii, 2008,29(4): 434-439.(in Chinese with an English abstract)
