大口径非球面主反射镜的装调方法研究

韩娟, 段嘉友, 张钧

韩娟, 段嘉友, 张钧. 大口径非球面主反射镜的装调方法研究[J]. 应用光学, 2012, 33(3): 490-495.
引用本文: 韩娟, 段嘉友, 张钧. 大口径非球面主反射镜的装调方法研究[J]. 应用光学, 2012, 33(3): 490-495.
shu
HAN Juan, DUAN Jia-you, ZHANG Jun. Alignment method for large aperture aspheric mirror[J]. Journal of Applied Optics, 2012, 33(3): 490-495.
Citation: HAN Juan, DUAN Jia-you, ZHANG Jun. Alignment method for large aperture aspheric mirror[J]. Journal of Applied Optics, 2012, 33(3): 490-495.
shu

大口径非球面主反射镜的装调方法研究

  • 1.

    中科院 西安光学精密机械研究所,陕西 西安 710119;

  • 2.

    中航工业自控所,陕西 西安 710065

详细信息
    通讯作者:

    韩娟（1977-），女，陕西咸阳人，工程师，主要从事光学仪器装调工作。

  • 中图分类号: TN206; TH74

Alignment method for large aperture aspheric mirror

  • 1.

    Xi-an Institute of Optics and Precision Mechanics,CAS,Xi-an 710119,China;

  • 2.

    Flight Automatic Control Research Institute,AVIC,Xi-an 710065,China

摘要

    摘要
  • 摘要: 针对大口径非球面主反射镜（简称主镜）的装调要求，对比分析常用大口径非球面面形检测方法，提出该类主镜检测面形的最佳方案。在主镜的装调过程中，通过对主镜的固定方式和主镜变形补偿这2个关键环节的阐述，总结主镜固定的难点及主镜变形的原因，提出一套全新的装调方案，以旋转消重力法进行检测，并用专用工装实时定心调节，再用辅料焊接法固定主镜与中心轴，最后采用辅助支撑对主镜组件进行最终固定修正。装调结果表明：对于大口径非球面反射镜，装调完成后的主镜面形精度Rms0.03（＝632.8 nm）。
    Abstract: According to the alignment demand of the large aperture aspheric mirror(hereinafter to be referred as the main mirror), the common detection methods for the large aperture aspheric surface were comparatively analyzed, and the best method for this sort of surface shape detection was put forward. In the alignment procedure of the main mirror, the two key links of the main mirror's fixation and deformation compensation were expounded, the difficulties of the fixation and the reasons for the deformation were summarized, and then a fire-new set of project was established by using measurement method with circumrotation counteracting gravity, real-time center position controling with particular tools, assistant material jointing method for the main mirror fixation and finally adjusting fixation with assistant upholders. The result showed that the method obtained good experimental effect, and the surface shape error of the main mirror was less than or equal to 0.03（＝632.8nm）.
    • HTML全文
    • 参考文献(1)
  • ［1］范俊玲.大口径非球面检测方法研究［D］.哈尔滨：哈尔滨工业大学, 2007.

    FAN Jun-ling .The research on the testing methods of large aperture aspheric mirror［D］. Harbin: Harbin Institute of Technology, 2007.(in Chinese)

    ［2］付兴科.大口径、非球面光学反射镜装调和检测技术研究［D］.长沙：国防科学技术大学,2006.

    FU Xing-ke .The research of large aspheric optics mirror for alignment and measurement［D］. Changsha : Graduate School of National University of Defense Technology Changsha, human, P.R.China, 2006. (in Chinese)

    ［3］潘君骅.光学非球面的设计、加工与检验［M］.苏州:苏州大学出版社, 2004.

    PAN Jun-hua .The design manufacture and test of the aspherical optical surfaces［M］. Suzhou, Suzhou University Press, 2004. (in Chinese)

    ［4］李新南，袁吕军，刘星涛，等. Φ520 mm F/1.6 椭球面反射镜加工［J］. 光学技术，2004，30（5）：619-622.

    LI Xin-nan,YUAN Lu-jun, LIU Xing-tao,et al. Manufacturing of the Φ520 mm F/1.6 ellipsoid mirror ［J］. Optical Technique, 2004，30（5）：619-622. (in Chinese with an English abstract)

    ［5］尤锐，王晶，王文革，等.大口径测量系统主反射镜装调及精度分析［J］.长春理工大学学报：自然科学版，2008，31（3）：20-23.

    YOU Rui，WANG Jing, WANG Wen-ge, et al.  Adjustment and error analysis of the large mirror of test system［J］. Journal of Changchun University of Science and Technology:national science edition. 2008，31（3）：20-23. (in Chinese with an English abstract)

    ［6］王孝坤，郑立功，张斌智，等.子孔径拼接检测大口径非球面技术的研究［J］.应用光学，2009,30（2）：273-278.

    WANG Xiao-kun, ZHENG Li-gong, ZHANG Bin-zhi,et al. Testing of large aspheric surfaces by subaperture stitching interferometry［J］.Jurnal of Applied Optics, 2009,30（2）：273-278. (in Chinese with an English abstract)

    ［7］王孝坤，王丽辉，张学军.干涉法测量浅度非球面技术［J］.光学精密工程，2008,16（2）：184-189.

    WANG Xiao-kun, WANG Li-hui, ZHANG Xue-jun. Test of weak aspheric surface by real-time interferometry ［J］. Opties and Precision Engineering, 2008,16（2）：184-189. (in Chinese with an English abstract)

    ［8］张忠玉，余景池.用补偿器测量非球面的研究［J］.光学精密工程，1999,7（1）：125-129.

    ZHANG Zhong-yu, YU Jing-chi. Study of testing aspherle surface with null corrector［J］. Opties and Precision Engineering, 1999,7（1）：125-129. (in Chinese with an English abstract)
