具光反馈功能的星模拟器设计

刘瑞敏, 郭喜庆, 刘洋, 边强, 秦莹莹, 李伟燕

刘瑞敏, 郭喜庆, 刘洋, 边强, 秦莹莹, 李伟燕. 具光反馈功能的星模拟器设计[J]. 应用光学, 2012, 33(3): 485-489.
引用本文: 刘瑞敏, 郭喜庆, 刘洋, 边强, 秦莹莹, 李伟燕. 具光反馈功能的星模拟器设计[J]. 应用光学, 2012, 33(3): 485-489.
shu
LIU Rui-min, GUO Xi-qing, LIU Yang, BIAN Qiang, QIN Ying-ying, LI Wei-yan. Star simulator with optical feedback[J]. Journal of Applied Optics, 2012, 33(3): 485-489.
Citation: LIU Rui-min, GUO Xi-qing, LIU Yang, BIAN Qiang, QIN Ying-ying, LI Wei-yan. Star simulator with optical feedback[J]. Journal of Applied Optics, 2012, 33(3): 485-489.
shu

具光反馈功能的星模拟器设计

  • 1.

    中国科学院 光电研究院,北京 100094;

  • 2.

    中国科学院 研究生院,北京 100080

详细信息
    通讯作者:

    刘瑞敏(1985-)，男，湖北广水人，硕士研究生，主要从事光学系统设计研究。

  • 中图分类号: TN202; V524

Star simulator with optical feedback

  • 1.

    Academy of Opto-electronics,Chinese Academy of Sciences,Beijing 100094,China;

  • 2.

    Graduate University of Chinese Academy of Sciences,Beijing 100080,China

摘要

    摘要
  • 摘要: 为满足天文导航设备星敏感器内场高精度检测和标校的实际工程需要，设计了一种结构简单并且具有光反馈功能的新型高精度单星模拟器。选用发光二极管作为光源，采用先聚焦再准直的方法实现模拟星光的平行输出。星模拟器的光反馈系统可以在输出光强发生变化的时候自动调节星光光源的发光强度，从而使星模拟器的输出光强在相当长的时间段内保持稳定。星模拟器输出光束的平行度达到8，输出光束的均匀性达到80 %，在连续工作至少8 h的情况下输出光束的稳定性达到89 %。相对稳定的输出光强减少了星模拟器因为模拟的星等发生变化而产生的影响，提高了星敏感器检测和标定的精度。
    Abstract: A novel high-accuracy star simulator with simple structure and the function of optical feedback was designed to satisfy the practical requirements of highaccuracy test and calibration of star sensor, which was a device used for celestial navigation. LED was selected as the light source. The parallel output beam was formed by means of focusing first and then collimating. The optical feedback system of the star simulator automatically adjusted the luminous intensity of its light source to keep the output intensity stable within a quite long time when the output intensity was changing.The parallelism of output beam of the star simulator reached 8, the uniformity of its output beam achieved 80% and the stability of output intensity of the star simulator reached 89% under the continuous working condition of at least 8 hours. Because the stable output intensity reduces the influence of magnitude change of the star simulator, it is very useful for improving the accuracy of test and calibration of star sensor.
