连续变焦大气相干长度测量系统设计

李广; 汪建业; 邵慧; 徐鹏

连续变焦大气相干长度测量系统设计

中国科学院安徽光学精密机械研究所中国科学院大气成分与光学重点实验室,安徽合肥 230031

详细信息

通讯作者:
李广（1988-），男，安徽亳州人，硕士，主要从事光机设计工作。

中图分类号: TN942.2; TH743
计量
- 文章访问数: 3596
- HTML全文浏览量: 143
- PDF下载量: 542
出版历程
- 刊出日期: 2012-05-14

Continuous zoom measurement system for atmospheric coherence length

Key Laboratory of Atmospheric Composition and Optical Radiation,Anhui Institute of Optics and Fine Mechanics,CAS,Hefei 230031,China

摘要

摘要: 望远镜在大气光学参数测量中起到至关重要的作用，测量方法是通过跟踪恒星或者信标实时测量数据。基于不同速度信标的移动特点，需要设计3 m~6 m变焦大气相干长度测量系统用于大气相干长度的测量，设计波段为可见光486 nm~656 nm，探测元全视场11 mm，入瞳直径300 mm。利用光学设计软件设计出一款折返式变焦望远系统，光学结构由卡式望远系统和三组元机械补偿式连续变焦系统组成,系统结构简单，成本低，凸轮曲线平滑，压力升角均小于45。系统可对变焦焦距数据实时输出，适合于快速和慢速不同场合下实时进行大气参数测量。
- 变焦系统 /
- Zemax /
- 光学设计 /
- 望远系统
Abstract: Telescope is important to measure atmosphere optical parameters by tracking star or beaconing to measure data in real time. Based on the moving characteristics of beaconing at different speeds, design of a continuous zoom measurement system for atmospheric coherence length was required. The designed focal length of the system was 3 m~6 m, the wavelength was 486 m~656 m, the charge coupled device (CCD) size was 11mm and the entrance pupil diameter was 300mm. By using optical design software, a catadioptric zoom telescope system was designed which consisted of a Cassegrain telescope and three-component mechanically compensated zoom system. The optical zoom system has high quality, simple structure, low cost and smooth cam curve, and all the pressure rise angles are no more than 45. It can output real-time zoom data of focus length and is suitable for measuring the atmosphere coherent length real-timely on the occasion of high and low speeds.
- zoom system /
- Zemax /
- optical design /
- telescope system

HTML全文

参考文献(1)

［1］FRIED D L. Optical resolutipon through a randomly inhomogeneous medium for very long and very short exposures［J］. J.Opt.Soc.,Am.,1966,56:1372

［2］汪建业.大气光学湍流光学测量方法的研究［D］.合肥：中国科学院安徽光学精密机械研究所，2004.

WANG Jian-ye. Studies of measuring atmospheric optical turbulence［D］.Hefei: Anhui Institute of Optics and Fine Mechanics Chinese Academy of Sciences，2004.(in Chinese)

［3］王之江.实用光学设计手册［M］ .北京：机械工业出版社,2006.

WANG Zhi-jiang. Handbook of practical optical technology［M］.Beijing: China Machine Press, 2006. (in Chinese)

［4］张以漠.应用光学［M］.3版.北京：电子工业出版社,2008.

ZHANG Yi-mo. Applied Optics［M］ . 3rd ed.Beijing: Publishing House of Electronics Industry,2008. (in Chinese)

［5］陶纯堪.变焦距光学系统设计［M］.北京:国防工业出版社,1988.

TAO Chun-kan.Zoom optical system design［M］. Bei jing: Defense Industry Publishing House,1988. (in Chinese)

［6］ANHK,PSK. Diffraction limited constant-resolution zoom lens across multiwavelengths for the advanced technology solar telescope［J］. SPIE, 2006,6342:63421L.

［7］钱义先,梁伟,高晓东.含多个非球面大视场卡塞格林系统光学设计［J］.光子学报，2009，38(4):896-899.

QIAN Yi-xian, LIANG Wei, GAO Xiao-dong. Optical design of cassegrain system with wide angle and multiple aspheric surfaces［J］.Acta Photonica Sinica,2009,38(4):896-899. (in Chinese with an English abstract)

［8］曾吉勇,金国藩,王民强等.折衍混合复消色差望远物镜设计的PWC方法［J］.光子学报,2006,35(10): 1569-1572.

ZENG Ji-yong,JIN Guo-pan,WANG Min-qiang,et al.Hybrid diffractive-refractive apochromatic telescope objectives design using pwc method ［J］. Acta Photonica Sinica, 2006,35(10): 1569-1572. (in Chinese with an English abstract)

［9］贺应红,马臻,赵葆常,等.实现两档长焦距的空间遥感光学系统设计［J］.光学学报,2010,30(10):3028-3033.

HE Ying-hong,MA Zhen,ZHAO Bao-chang,et al. Optical system design of space sensor with two long focal length lens［J］.Acta Optica Sinica, 2010,30(10):3028-3033. (in Chinese with an English abstract)

［10］王平,张葆,程志峰.变焦距镜头凸轮结构优化设计［J］.光学精密工程,2010,18(4):893-898.

WANG Ping,ZHANG Bao,CHENG Zhi-feng.Optimal design of cam structure of zoom lens［J］.Optics and Precision Engineering, 2010,18(4):893-898. (in Chinese with an English abstract)

［11］廖胜，沈忙作.连续变焦望远镜导向机构的设计与研究［J］.光电工程,1999,26(增刊):59-61.

LIAO Sheng,SHEN Mang-zuo. An anlysis of technological properties for cam in continuous zoom telescope［J］. Opto-Electronic Engineering,1999,26(s1):59-61. (in Chinese with an English abstract)
