Laser simulation of DIRCM system
-
摘要: 针对半实物仿真中定向红外对抗系统的有效模拟问题，在分析定向红外对抗激光源技术的基础上，依据实战应用，计算得到3 m~5 m波段定向红外对抗激光源的辐射能量为飞机红外辐射强度绝对值的8倍，结合波长4 m处简化的大气传输透过率随传输距离的变化，推导出实战应用中红外导引头上辐射照度随飞机导弹之间距离的变化规律。设计半实物仿真中定向红外对抗的模拟方案，依据逼真模拟的原则，计算得到模拟激光源能量随飞机导弹之间距离和飞机辐射强度的变化规律，据此将飞机导弹相互距离1 km时刻的红外干扰源辐射能量设置为波长4 m模拟激光源能量，其他距离的模拟能量通过衰减片来控制。为提高定向红外对抗模拟的通用性和智能性，设计了模拟激光源的闭环控制方案。Abstract: Aiming at the effective simulation of the DIRCM in the hardware-in-the-loop simulation, the calculated radiation energy for the laser source is 8 times of the absolute value of the aircraft radiation intensity in the band range of 3 m~5 m based on the analysis of the laser source in DIRCM and real battlefield scenario. Combined with the change of atmospheric transmission transmittance in 4 m, the change rule of radiance on the IR seeker is obtained with the change of distance between the aircraft and the missile. The simulation scheme of DIRCM in the hardware-in-the-loop simulation is designed based on the principle of realistic simulation, the energy change of the laser source is calculated with the change of distance between the aircraft and the missile, the energy of IR interference radiation energy in 1 km is set as the energy of the simulation laser source, and the energies in other distances are controlled through the attenuation slice. At last, for the purpose of improving the versatility and intelligence in DIRCM simulation, the closed loop control of simulation laser is designed, and the method of closed loop control for interference wavelength and modulation mode is studied.
-
Keywords:
- DIRCM /
- laser source /
- closed loop technology /
- simulation
-
-
［1］Bernhard Molocher. Countermeasure laser development［J］. SPIE, 2005, 5989: 598902.
［2］车进喜,王东,张恒伟，等.激光参数对红外成像系统干扰效果影响的实验研究［J］.应用光学,2011,32(5):992-996.
CHE Jin-xi, WANG Dong, ZHANG Heng-wei, et al.Influence of laser parameters on jamming effectiveness of IR imaging system［J］. Journal of Applied Optics, 2011,32(5): 992-996.(in Chinese with an English abstract)
［3］付伟.定向红外对抗技术的发展现状［J］.航空电子技术,2000 (3): 64-69.
FU Wei.The development of DIRCM［J］.Avionics Technology,2000 (3): 64-69.(in Chinese with an English abstract)
［4］HECHT J . Solid-state high-energy laser weapons［J］. Optics & Photonics News, 2003,1:42-47.
［5］BEKMAN H H P T, HEUVEL J C, PUTTEN F J M, et al. Development of- a- mid-infrared laser for study of infrared countermeasures techniques［J］. SPIE, 2004,5615:578214.
［6］HAELLSTIG E,STIGWALL J, LINDGREN M, et al. Laser beam steering and tracking using a liquid crystal spatial light modulator［J］. SPIE, 2003, 5087:486892.
［7］张建奇,方小平. 红外物理［M］.西安:电子科技大学出版社,2004.
ZHANG Jian-qi,FANG Xiao-ping.Infrared physics［M］.Xi-an:Xidian University Press,2004.(in Chinese)
［8］刘兴堂.精确制导、控制与仿真技术［M］.北京:国防工业出版,2006.
LIU Xing-tang.Precise guidance, control and simulation technology［M］.Beijing:National Defense Industry Press,2006.(in Chinese)
［9］徐大伟.定向红外干扰技术的发展分析［J］.红外与激光工程,2008(6):695-698.
XU Da-wei.Development analysis of the IR decoy anti-jamming technology［J］.Infrared and - Laser Engineering,2008(6):695-698.(in Chinese with an English abstract)
