液体折射率的一种新型测量方法

苗润才; 韩鹏斌; 李能能; 高美玲

液体折射率的一种新型测量方法

陕西师范大学物理与信息技术学院,陕西西安710062

详细信息

通讯作者:
苗润才(1957-)，男，陕西乾县人，博士，主要从事光学信息处理及液体表面的光学探测研究。

中图分类号: O435.1
计量
- 文章访问数: 3891
- HTML全文浏览量: 139
- PDF下载量: 566
出版历程
- 刊出日期: 2012-02-14

Novel method for measuring refractive index of liquid

College of Physics &Information Technology,Shaanxi Normal University,Xi-an 710062,China

摘要

摘要: 利用液体薄膜的遮光效应原理，建立了一种新的测量液体折射率的方法和装置。选择了3种常见液体：蒸馏水、无水乙醇和1,2-丙二醇。利用新建的装置对其折射率进行了测量。实际测量过程中，对实验形成的图样进行了2种测量分析：一种是利用读数显微镜直接测量分析实验结果；一种是利用CCD拍摄记录实验结果，并利用计算机对拍摄结果进行了智能化处理分析。分析了实验误差，实现了实时、全自动化测量。测量结果均与理论值吻合。该方法操作简便、设备简单、重复性好、准确度高。
- 遮光效应 /
- 液体薄膜 /
- 折射率 /
- 测量
Abstract: A new method for measuring the refractive index of the liquid was proposed and a device was developed by using liquid film shading effect principle. Distilled water, anhydrous alcohol and 1.2-trimethylene glycol were chosen as samples to be measured. The refractive indices of these liquids were measured by the new experiment device. In the measurement process, the experimental graphs were analyzed by two methods. One used the reading microscope to measure and analyze the results directly, the other used the CCD to record and intelligently analyzed the CCD records by computer. Experimental errors were analyzed. Automatic real-time measurement was realized. Measurement results agree with the theoretical calculation. This device is simple, accurate, and easy to operate.
- Shading effect /
- liquid film /
- refractive index /
- measure

HTML全文

参考文献(1)

［1］BARTER J D， Y.LEE P H. Imaging surface-wave analyzer for liquid surfaces ［J］.Appl.Opt.,1997,36(12):2630-2635.
［2］BARTER J D. A capacitive antenna for measurement of the dispersion relation of capillary wave on water ［J］.Rev.Sci.Instrum. 1993,64(2):556-560.
［3］EHROOZI F B, ERKINS A P. Direct measurement of the dispersion relation of capillary waves by laser interferometry ［J］.Am.J.Phys., 2006,74(11):957-961.
［4］PADDAY J F,.PITT A R, PASHLEY R M. Menisci at a free liquid surface: surface tension from the maximum pull on a rod ［J］.J.Chem.Soc.Faraday Trans.,1975,71(1):1919-1931.

［5］KAISER N, CROLL A, SZOFRAN F R，et al. Wetting angle and surface tension of germanium melts on different substrate materials ［J］. Crystal Growth , 2001,231(4):448-457.

［6］MIAO Run-cai, SHI Jian, ZHAO Xiao-feng. Determination of the attenuation coefficient of surface acoustic wave by means of the light interference［J］.Acta Photonica Sinica,2005,34(3):382-385.
［7］MIAO Run-cai, YANG Zong-li .Physical properties of liquid surface wave and its optical effect ［J］. Acta Phys Sin., 1996,46(9):1521-1525.
［8］MIAO Run-cai，YANG Zong-li，ZHU Jing-tao. Critical light reflection from curved liquid surface ［J］. Optics Communications，2003，218(4-6)：199-203.
［9］MIAO Run-cai，YANG Zong-li，ZHU Jing-tao,et al. Visualization of low-frequency liquid surface acoustic wave by means of optical diffraction ［J］.Appl.Phys.Lett., 2002,80(17):3033-3035.
［10］MIAO Run-ai,DONG Jun,QI Jian-xia. The asymmetry of diffraction patterns from liquid surface waves ［J］.Acta Photonica Sinica,2006,35(1):1921-1924.
［11］DONG Jun, MIAO Run-cai, QI Jian-xia, et al. Unusual distribution of the diffraction patterns from liquid surface waves ［J］.Appl.Phys.,2006,100(3)：1-3.
［12］MIAO Run-cai,ZHAO Xiao-feng，SHI Jian. Modulated interference of reflected light from a liquid surface wave at tens Hertz frequencies［J］.Opt.Commun.,2006,259(2):592-597.
［13］MIAO Run-cai,ZHU Jing-tao,YANG Zong-li. The shading effect of the liquid surface and its application ［J］. Photon Journal, 2002,31(4):489-491.
［14］姚启钧.光学教程［M］.北京：高等教育出版社，2004.
YAO Qi-jun. Optical tutorial ［M］. Beijing: Higher Education Press,2004.(in Chinese)
