基于xPC的光电平台系统半实物实时仿真

黄显林; 鲍文亮; 卢鸿谦; 李明明

基于xPC的光电平台系统半实物实时仿真

哈尔滨工业大学控制理论与制导技术研究中心,哈尔滨黑龙江 150001

详细信息

通讯作者:
黄显林(1956-)，男，黑龙江哈尔滨人，教授，博士生导师，主要从事飞行器导航与控制及复杂系统控制的研究工作。

中图分类号: TN209; TP275
计量
- 文章访问数: 3546
- HTML全文浏览量: 133
- PDF下载量: 437
出版历程
- 刊出日期: 2012-02-14

xPC based hardware-in-the-loop simulation of electro-optical platform systems

Center for Control Theory and Guidance Technology,Harbin Institute of Technology,Harbin 150001,China

摘要

摘要: 为了便捷高效地设计和调试光电平台系统的稳定、跟踪控制算法，基于Matlab的xPC Target环境设计开发了半实物实时仿真系统。阐述了系统的总体设计方案，给出了系统软、硬件实现方法。通过半实物仿真，完成了平台的模型结构参数辨识，设计并测试了比例积分控制器、校正控制器和综合控制器。对半实物仿真系统进行摇摆实验以评估所设计的控制系统的视轴稳定精度。实验结果显示，校正控制器因其在低频段具有更高的增益从而使系统获得了最高的稳定精度，通过实验结果可有效地选择出扰动抑制特性最优的控制器设计。
- 光电平台 /
- 惯性稳定 /
- xPC目标 /
- 半实物仿真 /
- μ综合
Abstract: In order to design and debug the stabilizing and tracking control arithmetic of an electro-optical platform system conveniently and efficiently, a hardware-inthe-loop simulation system was designed and implemented based on Matlab xPC target environment. The overall design of the system was presented, and the implementation of software and hardware was described. Through hardware-in-the-loop simulation, the model structure and parameter of the plant were identified, furthermore, proportional integral controller, correction controller, and synthesis controller were designed and tested. Vibration experiments were carried out for every control system designed to evaluate the line-of-sight stabilization accuracy. Experimental results show that the correction controller, which has the maxium gain value in the low frequency band, makes the system achieve the highest stabilization accuracy. According to experimental results, the controller which has optimal disturbance attenuation is selected.
- electro-optical platform /
- inertial stabilization /
- xPC Target /
- hardware-in-the-loop simulation /
- μ synthesis

HTML全文

参考文献(1)

［1］MASTEN M K. Inertially stabilized platforms for optical imaging systems: tracking dynamic targets with mobile sensors［J］. IEEE Control Systems Magazine, 2008, 28(1): 47-64.
［2］HILKERT J M. Inertially stabilized platform technology: concepts and principles［J］. IEEE Control Systems Magazine, 2008, 28(1): 26-46.
［3］杨正贤, 孔宪仁, 王继河, 等. 基于xPC的小卫星半物理仿真验证平台［J］. 系统仿真学报, 2009, 21(20): 6444-6448.
YANG Zheng-xian, KONG Xian-ren, WNAG Ji-he, et al. Hardware-in-Loop simulation platform for small satellite based on xPC real-time simulator［J］. Journal of System Simulation, 2009, 21(20): 6444-6448.(in Chinese with an English abstract)
［4］王广雄, 何朕. 控制系统设计［M］. 北京: 清华大学出版社, 2008.
WANG Guang-xiong, HE Zhen. Control system design［M］. Beijing: Tsinghua University Press, 2008.(in Chinese)
［5］SAFONOV M G, LAUB A J, HARTMANN G L. Feedback properties of multivariable systems: the role and use of the return difference matrix［J］. IEEE Transactions on Automatic Control, 1981, 26(1): 47-65.
［6］王广雄, 何雨奋. 伺服设计的性能极限［J］. 电机与控制学报, 1997, 1(4): 238-240.
WANG Guang-xiong, HE Yu-fen. Performance limit of servo design［J］. Electric Machines and Control, 1997, 1(4): 238-240.(in Chinese with an English abstract)
［7］王广雄, 何朕. 应用H∞控制［M］. 哈尔滨: 哈尔滨工业大学出版社, 2010.
WANG Guang-xiong, HE Zhen. Applied H∞ control［M］. Harbin: Harbin Institute of Technology Press, 2010.(in Chinese)
［8］SEFTON J, GLOVER K. Pole/zero cancellations in the general H∞ problem with reference to a two block design［J］. Systems Control Letters, 1990, 14: 295-306.
