推扫式线阵TDI CCD扫描调制传递函数分析

杨永明, 李昕阳, 赵嘉鑫

杨永明, 李昕阳, 赵嘉鑫. 推扫式线阵TDI CCD扫描调制传递函数分析[J]. 应用光学, 2011, 32(5): 872-877.
引用本文: 杨永明, 李昕阳, 赵嘉鑫. 推扫式线阵TDI CCD扫描调制传递函数分析[J]. 应用光学, 2011, 32(5): 872-877.
shu
YANG Yong-ming, LI Xin-yang, ZHAO Jia-xin. Scanning modulation transfer function analysis of push-broom linear TDI CCD[J]. Journal of Applied Optics, 2011, 32(5): 872-877.
Citation: YANG Yong-ming, LI Xin-yang, ZHAO Jia-xin. Scanning modulation transfer function analysis of push-broom linear TDI CCD[J]. Journal of Applied Optics, 2011, 32(5): 872-877.
shu

推扫式线阵TDI CCD扫描调制传递函数分析

  • 中国科学院 长春光学精密机械与物理研究所,吉林 长春 130033

详细信息
    通讯作者:

    杨永明（1980-），男，吉林长春人，博士，助理研究员，主要从事航空相机成像控制技术研究工作。

  • 中图分类号: TN911.73;TP75

Scanning modulation transfer function analysis of push-broom linear TDI CCD

  • Changchun Institute of Optics,Fine Mechanics and Physics,CAS,Changchun 130033,China

摘要

    摘要
  • 摘要: 根据线阵TDI CCD离散采样的特点，以采样间距内成像调制度均值为基础，构建了推扫成像模式下线阵TDI CCD扫描方向的调制传递函数。该调制传递函数的数值分析表明：对于像元为10 m的线阵TDI CCD，行转移驱动时钟相数为4， 3或2时,Nyquist频率处调制传递函数值分别为0.363，0.333或0.255；行频误差为1%及3%时，不同积分级数下调制传递函数变化曲线表明，增大行频误差及增加积分级数将使调制传递函数值减小，图像分辨率降低。成像实验结果符合所构建调制传递函数的定量分析结论。
    Abstract: Scanning modulation transfer function (MTF) for linear time-delay integration (TDI) charge coupled device (CCD) using push-broom imaging mode was established. The MTF which took the discrete sampling characteristics of linear TDI CCD into account, was based on the imaging modulation mean within sampling interval. The numerical analysis of the proposed MTF indicated that the value of MTF at Nyquist frequency for linear TDI CCD with 10 m pixel size was 0.363, 0.333 and 0.255 respectively, when the number of row transfer phase clocks was 4, 3 and 2. When the row frequency error was 1% or 3%,the changes of MTF curves with different integration numbers implied that increasing the row frequency error and the integration number could decrease the value of MTF and reduce the image resolution. The results of imaging experiment agree with the quantity analysis of the proposed MTF.
    • HTML全文
    • 参考文献(1)
  • ［1］FELTS J C, KARIM M A. Modulation transfer function of chargecoupled devices［J］. Applied Optics, 1990, 29(5): 717-722.

    ［2］郑琳, 仲思东, 何对燕. 电荷耦合成像器件的调制传递函数［J］. 武汉测绘科技大学学报, 1996, 21(2): 176-182.

    ZHENG Lin, ZHONG Si-dong, HE Dui-yan. The modulation transfer function of charge-coupled devices［J］. Journal of Wuhan Technical University of Surveying and Mapping, 1996, 21(2): 176-182. (in Chinese with an English abstract)

    ［3］MAGNAN P, ESTRIBEAU M, ROLLAND G, et al. Theoretical evaluation of MTF and charge collection efficiency in CCD and CMOS image sensors［J］. SPIE, 2009, 7427: 23-34.

    ［4］王凌, 冯华君, 徐之海. 基于调制传递函数的CCD亚像元成像质量评价［J］. 浙江大学学报：工学版, 2004, 38(7): 845-847.

    WANG Ling, FENG Hua-jun, XU Zhi-hai. Evaluation for subpixel imaging quantity of CCD sensor based on modulation transfer function［J］. Journal of Zhejiang University:Engineering Science, 2004, 38(7): 845-847. (in Chinese with an English abstract)

    ［5］王凌, 徐之海, 冯华君, 等. 线阵推扫式CCD亚像元成像的列向动态调制传递函数［J］. 浙江大学学报：工学版, 2008, 42(2): 317-320.

    WANG Ling, XU Zhi-hai, FENG Hua-jun, et al. Transverse dynamic modulation transfer function of subpixel push-scanning imaging by linear CCD［J］. Journal of Zhejiang University:Engineering Science, 2008, 42(2): 317-320. (in Chinese with an English abstract)

    ［6］LAMBERT B M, HARBOLD J M. Experimental methods for measurement of the modulation transfer function (MTF) for time delay and integrate (TDI) charge coupled device (CCD) image sensors［J］. SPIE, 2009, 7405: 75-83.

    ［7］马天波, 郭永飞, 李云飞. 科学级TDI CCD相机的行频精度［J］. 光学精密工程, 2010, 18(9): 2028-2035.

    MA Tian-bo, GUO Yong-fei, LI Yun-fei. Precision of row frequency of scientific grade TDI CCD camera［J］. Optics and Precision Engineering, 2010, 18(9): 2028-2035. (in Chinese with an English abstract)

    ［8］许世文, 姚新程, 付苓. 推扫式TDICCD成像时像移影响的分析［J］. 光电工程, 1999, 26(1): 60-63.

    XU Shi-wen, YAO Xin-cheng, FU Ling. An analysis for the influence of image motion on push-broom TDI-CCD imaging［J］. Opto-Electronic Engineering, 1999, 26(1): 60-63. (in Chinese with an English abstract)

    ［9］刘亚侠. TDI CCD遥感相机标定技术的研究［D］. 长春: 中国科学院长春光学精密机械与物理研究所, 2005.

    LIU Ya-xia. Research on the calibration technique of the TDI CCD remote sensing camera［D］. Changchun: Changchun Institute of Optics, Fine mechanics and Physics, CAS, 2005. (in Chinese)

    ［10］HOCK K M. Effect of oversampling in pixel arrays［J］. Optical Engineering, 1995, 34(5): 1281-1288.

    ［11］杨秉新. TDI CCD相机的相对孔径与器件像元尺寸关系的研究［J］. 航天返回与遥感, 2001, 22(2): 9-12.

    YANG Bing-xin. Investigation on the relationship of relative aperture to pixel dimensions for TDI CCD camera［J］. Space Craft Recovery and Remote Sensing, 2001, 22(2): 9-12. (in Chinese with an English abstract)
