车辆寻北车长镜的设计与实现

邓宏林, 郭栓运, 扈宇姝, 李彰, 梁庆仟, 周国良

邓宏林, 郭栓运, 扈宇姝, 李彰, 梁庆仟, 周国良. 车辆寻北车长镜的设计与实现[J]. 应用光学, 2011, 32(5): 849-853.
引用本文: 邓宏林, 郭栓运, 扈宇姝, 李彰, 梁庆仟, 周国良. 车辆寻北车长镜的设计与实现[J]. 应用光学, 2011, 32(5): 849-853.
shu
DENG Hong-lin, GUO Shuan-yun, HU Yu-shu, LI Zhang, LIANG Qing-qian, ZHOU Guo-liang. Design and implementation of north-finding commander sight for tank and armored vehicle[J]. Journal of Applied Optics, 2011, 32(5): 849-853.
Citation: DENG Hong-lin, GUO Shuan-yun, HU Yu-shu, LI Zhang, LIANG Qing-qian, ZHOU Guo-liang. Design and implementation of north-finding commander sight for tank and armored vehicle[J]. Journal of Applied Optics, 2011, 32(5): 849-853.
shu

车辆寻北车长镜的设计与实现

  • 西安应用光学研究所,陕西 西安 710065

详细信息
    通讯作者:

    邓宏林（1963-），男，陕西蒲城人，高级工程师，主要从事稳瞄/惯导控制技术研究工作。

  • 中图分类号: TN202;O318

Design and implementation of north-finding commander sight for tank and armored vehicle

  • Xi-an Institute of Applied Optics,Xi-an 710065,China

摘要

    摘要
  • 摘要: 描述了一种车辆寻北车长镜的设计，采用2个光纤陀螺和2个加速度计，解决了惯性测量组件力学编排结构设计与寻北、瞄准线稳定共享陀螺信息的问题，设计系统控制流程和组合算法，在保障车长镜瞄准线稳定精度的同时，增加了车体方位平台非调平状态下任意位置的寻北功能，寻北方法是：车长镜方位固定四位置转动，每个位置点停止、延迟、数据采样、存储，四位置转动完毕后，对存储数据组合、滤波、解算，输出寻北结果。对方案设计、实现途径和解算推导方法作了详细论述，性能测试验证设计实现达到预期效果。
    Abstract: A north-finding commander sight for tank and armored vehicle was designed. It adopted two fiber optic gyros and two accelerometers to realize inertial measurement and gyro information was shared by both north finding and line of sight (LOS) stabilization. The control process and combined algorithms were designed. While ensuring a high accuracy of the commander sight LOS stabilization, it performed north finding in any position when the vehicle azimuth platform was unleveled. The north-finding method was that the commander sight rotated to four fixed positions and stopped for an interval at these positions, these intervals are used to sample and store data at the four positions. After the completion of four-position rotation, the recorded data were combined, filtered and calculated to obtain the north-finding result. The concept design, implementation approach and derivation approach were discussed. The demonstration test proves that the desired specifications are achieved.
    • HTML全文
    • 参考文献(1)
  • ［1］陈文建, 梁庆仟, 蒋萧村. 稳瞄惯导周视观瞄镜的设计［J］. 应用光学, 2007, 28(5): 573-577.

    CHEN Wen-jian, LIANG Qing-qian, JIANG Xiao-cun. Design of stabilized panoramic sight with inertial navigation［J］. Journal of Applied Optics, 2007, 28(5): 573-577. (in Chinese with an English abstract)

    ［2］纪明. 自寻北/稳瞄惯性平台组合研究［J］. 火力与指挥控制, 1995, 20(1): 56-60.

    JI Ming. Northfinding/stabilizing line-of-sight inertia platform integration research［J］. Fire Control & Command Control, 1995, 20(1): 56-60. (in Chinese with an English abstract)

    ［3］郑慕桥, 冯崇植, 蓝祖佑. 坦克装甲车辆［M］. 北京: 北京理工大学出版社, 2003: 316-317.

    ZHENG Mu-qiao, FENG Chong-zhi, LAN Zu-you. Tank and armoured vehicle［M］. Beijing: Beijing Institute of Technology Press, 2003: 316-317. (in Chinese)

    ［4］周国良, 梁庆仟, 黄晓峰, 等. 光纤陀螺寻北仪控制系统的设计与实现［J］. 应用光学, 2006, 27(2): 144-146.

    ZHOU Guo-liang, LIANG Qing-qian, HUANG Xiao-feng, et al. Implementation and design of control system of FOG north finder［J］. Journal of Applied Optics, 2006, 27(2): 144-146. (in Chinese with an English abstract)

    ［5］汤勇刚, 吴美平. 战车捷联惯导系统的多功能兼容机理分析［J］. 兵工自动化, 2006, 25(9): 1-2, 13.

    TANG Yong-gang, WU Mei-ping. Analysis of multi-function compatible mechanism of tank-s SINS［J］. Ordnance Industry Automation, 2006, 25(9): 1-2, 13. (in Chinese with an English abstract)

    ［6］田玉平. 自动控制原理［M］. 2版. 北京: 科技出版社, 2002.

    TIAN Yu-ping. Automatic control theory［M］. 2nd ed. Beijing: Science & Technology Press, 2002.(in Chinese)

    ［7］韩利竹, 王华. MATLAB电子仿真与应用［M］. 2版. 北京: 国防工业出版社, 2001.

    HAN Li-zhu, WANG Hua. MATLAB simulation and application［M］. 2nd ed. Beijing: National Defence Industry Press, 2001. (in Chinese)

    ［8］寇英信, 黄国荣, 张斌. 机载光电瞄准系统在惯导系统校正中的应用［J］. 电光与控制, 2002, 9(2): 19-21.

    KOU Ying-xin, HUANG Guo-rong, ZHANG Bin. Application of airborne OES in inertial navigation system correction［J］. Electronics Optics & Control, 2002, 9(2): 19-21. (in Chinese with an English abstract)

    ［9］张坤, 彭雪明. 车载定位定向技术研究［J］. 现代防御技术, 2006, 34(4): 61-65.

    ZHANG Kun, PENG Xue-ming. Study on vehicular orienting and locating technology［J］. Modern Defence Technology, 2006, 34(4): 61-65. (in Chinese with an English abstract)

    ［10］徐珍, 杨莉, 刘建业. 车载惯性稳瞄/寻北组合系统研究［J］. 测控技术, 2000, 19(5): 55-57.

    XU Zhen, YANG Li, LIU Jian-ye. Research on inertial integrated system of north seeking/alignment stabilizing on vehicle［J］. Measurement & Control Technology, 2000, 19(5): 55-57. (in Chinese with an English abstract)
