38× zoom ratio wideband TV lens optics
-
摘要: 针对大视场高变倍比宽波段光学系统的特点，运用换根方式机械补偿光学系统设计技术和hhp图及孔径图分析法，实现了38变倍比，解决了大视场宽波段系统的初、高级像差难以平衡的难题,同时提出运用凸轮程序公式编程计算不齐焦段的补偿组实际位移量，对Code V的凸轮曲线设计值进行修正的方法，保证了高变倍比光学系统的齐焦性。Abstract: According to the characteristics of large FOV high zoom ratio wideband optical system, a 38 zoom ratio was designed, the primary and advanced aberrations of large FOV wideband system were balanced by using the mechanical compensation technique of changing root, the h-hp diagram and the aperture diagram analysis. A method using the cam formula to calculate the displacement of compensation group with no parfocality by programming and modify the design value of cam curve in Code V was put forward. This method ensured the parfocality of the high zoom ratio optical system.
-
Keywords:
- large FOV /
- high zoom ratio /
- mechanical compensation /
- h-hp diagram /
- aperture diagram /
- cam curve
-
-
［1］电影镜头设计组 .电影摄影物镜光学设计［M］．北京:中国工业出版社，1971.
Movie Lens Design Group .Optical design of movie photography objective lens［M］.Beijing:Chinese Industry Publishing Company, 1971.(in Chinese)
［2］晏蕾,贾平，洪永丰，等.变焦距镜头凸轮曲线形式的选择［J］.应用光学，2010，31（6）：876-882.
YAN Lei,JIA Ping,HONG Yong-feng,et al.Selection of cam cure for zoom lens［J］.Journal of Applied Optics, 2010，31（6）：876-882.(in Chinese with an English abstract)
［3］陶纯堪.变焦距光学系统设计［M］.北京：国防工业出版社，1988.
TAO Chun-kan.Optical design of zoom lens system ［M］.Beijing:National Defence Industry Press, 1988.(in Chinese)
［4］袁旭沧.光学设计［M］.北京：科学出版社，1983.
YUAN Xu-cang.Optical design［M］. Beijing :Science Press, 1983.(in Chinese)
