被动无热化切换式长波红外双视场望远镜

顿雄; 孟军合; 张振

被动无热化切换式长波红外双视场望远镜

1.
天津津航技术物理研究所,天津300192

详细信息

通讯作者:
顿雄（1986-），男，湖北荆州人，硕士，主要从事光学系统研究工作。

顿雄（1986-），男，湖北荆州人，硕士，主要从事光学系统研究工作。

中图分类号: TN21
计量
- 文章访问数: 4003
- HTML全文浏览量: 112
- PDF下载量: 751
- 被引次数: 0
出版历程
- 刊出日期: 2011-07-15

Athermalised dual FOV LWIR telescope

1.
Tianjin Jinhang Institute of Technical Physics,Tianjin 300192,China

摘要

摘要: 提出切换式双视场光学系统的结构形式，探讨了切换式双视场光学系统的被动无热化设计理论。在此基础上，设计了工作波长为7.7 m～10.3 m的被动无热化切换式双视场望远镜。采用衍射面和非球面减少光学元件数量并提高像质，切换式双视场望远镜在-55℃～+70℃全温度带内MTF@18 lp/mm0.45。最后对设计结果进行了扩展，给出2个以该结构形式和材料分配为基础的镜头设计结果，结果表明该结构形式和材料分配具有一定的普适性。
- 切换式 /
- 望远镜 /
- 无热化 /
- 双视场
Abstract: Switch-zoom dual field-of-view long-wave infrade (LWIR) telescopes are widely used in IR system，and they have the advantages of high transmission in narrow field view (FOV) and high resolution in wide FOV. This paper established the configuration of a switch-zoom dual FOV telescope, explained the athermalization theory of the switch-zoom dual FOV telescope, and designed a passively athermalised switch-zoom dual FOV LWIR telescope operating in 7.7 m~10.3 m. Diffractive surface and aspheric surface were used to improve the quality of optical system.The MTF was 0.45 @18 lp/mm at -55℃~+70℃. Finally, 2 other lenses were designed based on the designing result of the switch-zoom dual FOV telescope, which indicated that the configuration and arrangement of the passively athermalised switch-zoom dual FOV telescope are applicale in a variety of designs.
- switch-zoom /
- telescope /
- athermalization /
- dual FOV

HTML全文

参考文献(1)

［1］AKRAM M N. A step-zoom dual field-of-view IR telescope［J］. SPIE，2002,4832:328-333.
［2］XIONG Tao, YANG Chang-cheng. Long wavelength infrared dual field-of-view optical system［J］. SPIE，2007, 67222O: 1-6.
［3］吴晓靖，孟军和. 红外光学系统无热化设计的途径［J］，红外与激光工程，2003，32(6)：572-576.
WU Xiao-jing, MENG Jun-he. Approach of athermalizing infrared optical systems［J］. Infrared and Laser Engineering, 2003, 32(6): 572-576. (in Chinese with an English abstract)
［4］吴晓靖，孙赤全，孟军和. 红外光学系统无热化设计与变焦距镜头的关系［J］，红外与激光工程，2002，31(3):249-252.
WU Xiao-jing, SUN Chi-quan, MENG Jun-he. Relationship between athermalizing infrared optical system and zoom lens ［J］.Infrared and Laser Engineering, 2002, 31 (3): 249-252. (in Chinese with an English abstract)
［5］吴晓靖，孟军和. 使用简单机械结构实现红外光学系统无热化［J］.红外与激光工程，2005, 34(4)：16-18.
WU Xiao-jing, MENG Jun-he. Approach of athermalizing infrared optical systems［J］. Infrared and Laser Engineering, 2003, 32(6): 16-18. (in Chinese with an English abstract)
［6］王学新，焦明印. 红外光学系统无热化设计方法的研究［J］.应用光学，2009,30(1):129-133.
WANG Xue-xin, JIAO Ming-yin. Athermalization design for infrared optical systems［J］. Journal of Applied Optics,2009,30(1):129-133. (in Chinese with an English abstract)
［7］王学新，焦明印. 光学被动式和机电式组合消热差方法的研究［J］, 应用光学，2010,31(3):354-359.
WANG Xue-xin, JIAO Ming-yin. Combination ofoptical passive and mechanical-electrical athermalisation ［J］. Journal of Applied Optics, 2010,31(3):354-359. (in Chinese with an English abstract)
［8］沈良吉，冯卓祥. 3.7 μm～4.8 μm波段折/衍混合红外光学系统的无热化设计［J］. 应用光学，2009, 30(4):154-158.
SHEN Liang-ji, FENG Zhuo-xiang. Athermal design of refractive/diffractive hybrid infrared optical system working at 3.7μm～4.8μm ［J］. Journal of Applied Optics, 2009, 30(4):154-158. (in Chinese with an English abstract)
［9］LI Sheng-hui, YANG Chang-cheng. Optical passive athermalization for infrared zoom system［J］. SPIE，2007, 67224E:1-8.
［10］TAMAGAWA Y, WAKABAYASH S. New design method for athermalized optical systems［J］. SPIE，1992,1752:232-238.
