Eye-safe repetition laser based on optical parametric oscillator
-
摘要: 对KTP-OPO的相位匹配进行了理论分析和计算，并绘制了角度调谐曲线。基于光参量振荡器，选用KTP非线性晶体，在1.57m人眼安全激光波段进行了实验研究。将脉冲氙灯侧面泵浦Nd∶YAG 1.064 m激光应用于腔内KTP-OPO设计中，在工作频率5 Hz时，输出激光能量32 mJ，脉冲宽度7.22 ns，光光转换效率为41%。这一结果使重频远距离人眼安全激光测距成为可能。
-
关键词:
- 非线性光学 /
- 光参量振荡器（OPO） /
- 人眼安全激光 /
- 相位匹配 /
- KTP晶体
Abstract: The phase-matching mode of KTP-OPO was theoretically analyzed and calculated, and the angle-tuning curve of KTP-OPO was given. A 1.57 m eye-safe laser based on optical parametric oscillator was experimentally studied, which adopted KTP nonlinear optical crystal. Using a xeno-flash-lamp-pumped 1.064 m Nd∶YAG laser in intracavity KTP-OPO，under the repetition rate of 5 Hz, a laser output with the energy of 32 mJ and the pulse width of 7.22 ns was obtained. The optical-to-optical conversion efficiency was 41%, which makes long range laser range finding possible. -
-
［1］W.克希奈尔.固体激光工程［M］.北京:科学出版社,2002.
KOECHNER W. Solid-state laser engineering［M］. Beijing: Science Press,2002.(in Chinese)
［2］王月珠，姚宝权，王骐. 临界及非临界相位匹配KTP光学参量振荡器［J］. 光学学报，2000，20（10）:1368-1373.
WANG Yue-zhu,YAO Bao-quan,WANG Qi.KTP optical parametric oscillator with both critically and non-critically phase-matching［J］. Acta Optica Sinica,2000,20(10):1368-1373. (in Chinese with an English abstract)
［3］JU You-lun , YAO Bao-quan, QI Sheng. High power 1.57μm OPO pumped by MOPA with SBS［J］. Chinese Optics Letters，2005,3(6):358-360.
［4］何京良，王瑞华，黄海涛，等.高效大功率全固态1.5μm腔内光参量振荡器［J］.中国激光，2009，36（7）：1789-1792.
HE Jing-liang,WANG Rui-hua,HUANG Hai-tao,et al. Efficiency and high power all-solid-state 1.5 μm intracavity optical parametric oscillator［J］.Chinese Journal Laser，2009，36（7）：1789-1792. (in Chinese with an English abstract)
［5］王月珠，于欣，姚宝权,等.脉宽可调光参量振荡器的研究［J］.中国激光，2001，28（8）：689-692.
WANG Yue-zhu,YU Xin, YAO Bao-quan et al. Research of optical parametric oscillator with pulse-width-tunable［J］. Chinese Journal Laser，2001，28（8）：689-692.(in Chinese with an English abstract)
［6］KATO K. Second harmonic and sum-frequency generation to 4950 nm and 458.9 nm in KTP ［J］.IEEE J. Quant.Electron.,1988,QE-24(1):3-4.
［7］任钢，蔡邦维，钟鸣,等. 3 μm ~4 μm KTA 光参量振荡器的理论设计［J］. 中国激光，2006，33（增刊）：222-225.REN Gang, CAI Bang-wei, ZHONG Ming ,et al. Theoretical design of 3 μm ~4 μm KTA optical parametric oscillator［J］. Chinese Journal Lasers, 2006,30(sup) :222-225. (in Chinese with an English abstract)
［8］王滨，李彤，吕百达 等. 中红外砷酸钛氧钾光参量振荡器的实验研究［J］. 激光技术，2007，31（3）225-227.
WANG Bin, LI Tong，Lu Bai-dA, et al.. Experimental study of a kalium titanyl arsenate optical parametric oscillator in the mid-infrared band［J］.Laser Technology，2007，31（3）225-227. (in Chinese with an English abstract)
