基于光学厚度的云红外辐射计算

娄树理; 周晓东

基于光学厚度的云红外辐射计算

娄树理^,,
周晓东

海军航空工程学院控制工程系,山东烟台264001

详细信息

通讯作者:
娄树理（1976-），男，山东蒙阴人，讲师，博士研究生，主要从事光电制导、图像处理、红外图像生成研究工作。

中图分类号: TN215
计量
- 文章访问数: 4198
- HTML全文浏览量: 145
- PDF下载量: 801
出版历程
- 刊出日期: 2011-03-14

Calculation of cloud infrared radiation based on optical depth

LOU Shu-li^,,
ZHOU Xiao-dong

Department of Control Engineering,Naval Aeronautical and Astronautical University,Yantai,Shandong,264001

摘要

摘要: 为了研究不同物理厚度和不同波段下云的红外辐射特性，提出了基于光学厚度的云红外辐射计算方法。综合考虑云的红外辐射的各个因素，建立了较为完善的云的红外辐射模型，引入光学厚度经验计算公式，并根据光学厚度针对中波和长波红外分别计算了云的发射率、反射率和透过率，进而得到云的红外辐射亮度分布。利用该计算方法，计算了中波和长波红外云的辐射亮度数值，计算结果表明：随着光学厚度增大，云的发射率和反射率增大，探测器接收到的云红外辐射增强。比较发现，该计算结果与实测数据有较好的一致性，该计算模型可以为云背景的红外特性分析、探测及仿真提供参考数据。
- 云 /
- 红外辐射 /
- 光学厚度 /
- 辐射亮度
Abstract: To study the infrared characteristics of clouds with different thicknesses in different wavebands, a method for calculating infrared radiation of cloud based on optical depth is proposed. The infrared model of cloud was established after studing each infrared radiative component. According to the relation of infrared characteristics to waveband and thickness, the emissivity, reflectivity and transmissivity were computed respectively in middle infrared and long infrared wavelength, and the radiance of cloud was computed accordingly. Result shows that the radiation of cloud is a funtion of optical depth, and the actual measurements and the data from the model are consistent. It is proved that infrared radiation calculation of cloud based on optical depth can be used as the data source in infrared characteristic detection, analysis and simulation for the cloud background.
- cloud /
- infrared radiation /
- optical depth /
- radiance

HTML全文

参考文献(1)

［1］徐南荣，卞南华.红外辐射与制导［M］.北京：国防工业出版社，1997.
XU Nan-rong,BIAN Nan-hua. Infrared radiation and guadiance［M］.Beijing:National Defense Industry Press,1997.（in Chinese）
［2］L-VESQUE M P.Generation of synthetic IR sky background images［A］. SPIE, 1991, 1486: 200-209.
［3］TRIANTAFILLOU S A, SEELEY G P. Two models for predictive the probability of a cloudfree line-of-sight：US, A419420［AD］.2002-11-08.
［4］LIU Shi-guang, WANG Zhang-ye, GONG Zheng, et
al. Real-time generation of infrared dynamic sky scene［A］. SPIE,2005,6045:021-0210.
［5］SUTHERLAND R A. Determination and use of IR band emissivities in a multiple scattering and thermally emitting aerosol medium：A404478［AD］.2002-07-29.
［6］SUTHERLAND R A. Verification of the aerosol emissivity model,PILOT-EX:A404448［AD］.2002-07-29.
［7］邵晓鹏. 红外纹理生成方法研究［D］.西安：西安电子科技大学,2005.
SHAO Xiao-peng.Research on infrared texture analysis and synthesis［D］.Xi'an:Xi'dian University,2005.(in Chinese)
［8］ZAPPA C J. Infrared field measurements of sea surface temperature: analysis of wake signatures and comparison of skin layer models: A288579［AD］.1994-12-05.
［9］STEPHENS G L.Radiation profiles in extended water clouds.Ⅱ:parameterization schemes［J］. Journal of the Atmosphere Sciences,1978,35:2123-2132.
［10］LINDNER T H, LI J. Parameterization of the optical properties for water clouds in the infrared［J］. Journal of Climate, 2000, 13(10):1797-1805.
［11］SLINGO A.A GCM parameterization for shortwave radiative properties of water clouds［J］. Journal of the Atmosphere Sciences,1989,46(10):1419-1427.
［12］CHYLEK P, DAMIANO P, SHETTLE E P. Infrared emittance of water clouds［J］. Journal of the Atmosphere Sciences,1992,49(16):1459-1472.
［13］STEPHENS G L.A shortwave parameterization revised to improve cloud absorption［J］. Journal of the Atmosphere Sciences,1984,41(4):687-690.
［14］郭新军，金伟其，王霞，等.云层红外表观辐射模型的研究［J］.北京理工大学学报，2003，23(4):414-418.
GUO Xin-jun,JIN Wei-qi,WANG Xia,et al.An infrared apparent radiation model for cloud［J］.Transactions of Beijing Institute of Technology,2004,23(4):414-418.(in Chinese with an English abstract)
［15］CHYLEK P, RAMASWAMY V.Simple approximation for infrared emissivity of water clouds［J］. Journal of the Atmosphere Sciences,1982, 39(1):171-177.
