一种8行任意扫描的电光扫瞄器

万玲玉, 卢智勇, 王戎承

万玲玉, 卢智勇, 王戎承. 一种8行任意扫描的电光扫瞄器[J]. 应用光学, 2011, 32(2): 323-328.
引用本文: 万玲玉, 卢智勇, 王戎承. 一种8行任意扫描的电光扫瞄器[J]. 应用光学, 2011, 32(2): 323-328.
shu
WAN Ling-yu, LU Zhi-yong, WANG Rong-cheng. Electro-optic laser scanner for arbitrary scanning in 8 rows[J]. Journal of Applied Optics, 2011, 32(2): 323-328.
Citation: WAN Ling-yu, LU Zhi-yong, WANG Rong-cheng. Electro-optic laser scanner for arbitrary scanning in 8 rows[J]. Journal of Applied Optics, 2011, 32(2): 323-328.
shu

一种8行任意扫描的电光扫瞄器

  • 广西大学物理科学与工程技术学院,广西南宁530004

详细信息
    通讯作者:

    万玲玉（1975- ），女，副教授，博士，主要从事衍射光学、晶体光学和空间光通信方面的研究。

  • 中图分类号: TN15; TP211.6

Electro-optic laser scanner for arbitrary scanning in 8 rows

  • College of Physical Science and Technology,Guangxi University,Nanning 530004,China

摘要

    摘要
  • 摘要: 针对激光的快速智能扫描，综合利用晶体的双折射效应和电光效应，提出一种电控集成8行任意扫瞄的高速光扫描方案。主要由三级数字电光偏转器和81的周期性极化电光棱镜组构成，其中3个电光快门和3块双折射晶体构成三级数字偏转器，通过半波电压的控制实现行位置的转换，一定数目的周期性极化电光棱镜级联组成单行偏转器，通过控制电压进行单行扫描，根据电场施加方式可实现数字型或者连续型扫描。利用梯形结构的电光棱镜组设计了最大电压为5.822 kV时，扫描视场为17.256的可通过联机控制进行任意行扫描的高速激光扫描器。
    Abstract: Based on intelligent laser scanning, birefringence effect and electro-optic effect, a scanner for arbitrary scanning in 8 rows is proposed. It mainly consists of a three-order electro-optic deflector and a 81 cascade electro-optic prism group. The three-order electro-optic deflector is composed of three electrooptic shutters and three birefringent crystal plates. The laser beams are switched between rows by controlling half-wave voltage of crystal. The prism group with cascade prisms of optic-axis reciprocatingly scans rows by applied electrical field. Digital or continuous scanning were realized by changing the properties of the applied electrical field. A laser scanner with 17.256 scanning area and 5.822KV maximal voltage was designed by using the cascade electro-optic deflector of trapezium structure. It scans arbitrarily in 8 rows using on-line operation.
    • HTML全文
    • 参考文献(1)
  • ［1］CHIU Y, ZOU J, STANCIL D D, et al. Shape optimized electro-optic beam scanners: analysis, design, and simulation［J］. J.Lightwave Technol., 1999, 17(1):108-114.
    ［2］CHEN Q B, CHIU Y, LAMBETH D N, et al.Guided-wave electro-optic beam deflector using domain reversal in LiTaO3. J.Lightwave Technol., 1994,12(8):1401-1404. ［3］LI J, CHENG H C, KAWAS M J, et al.Electro-optic wafer beam deflector in LiTaO3［J］. IEEE Photonics Technology Letters, 1996, 8(11):1486-1488.
    ［4］FANG J C, KAWAS M J, ZOU J,et al.  Shape-optimized electro-optic beam scanners: experiment［J］. IEEE Photonics Technology Letters,1999,11(1),66-68.
    ［5］卢秀权,陈绍,沈德忠. KNbO3电光偏转器［J］.中国激光,1998,25（6）:519-522.
    LU Xiu-quan,CHEN Shao,SHEN De-zhong. A KNbO3 electrooptic deflector［J］. Chinese Journal of Lasers,1998,15(6): 519-522. (in Chinese with an English abstract)
    ［6］王伟.新型可调电光偏转器［J］.压电与声光,1989,11（5）:12-16.
    WANG Wei.New tunable electro-optic deflector［J］. Piezoelectrics & Acoustooptics,1989,11（5）:12-16.(in Chinese with an English abstract)
    ［7］SCRYMGEOUR D A, BARAD Y, GOPALAN V,et al. Large-angle electro-optic laser scanner on LiTaO3 fabricated by in situ monitoring of ferroelectricdomain micropatterning［J］. Appl. Optics, 2001, 40(34): 6236-6241.
    ［8］SCRYMGEOUR D A, KOC B, TIAN L,et al. Hybrid electrooptic and piezoelectric laser beam steering in wwo dimensions［J］.  J.Lightwave Technol., 2005,23(9):2772-2777.
    ［9］SCRYMGEOUR D A,SHARAN A, GOPALAN V, et al.Cascaded electro-optic scanning of laser light over large angles using domain microengineered ferroelectrics［J］. Appl.Phys.Lett., 2002,81(17):3140-3142.
    ［10］石顺祥,李家立,王广生,等. 一种新型的光波导阵列电光快速扫描器［J］. 光学学报, 2002, 22(11):1318-1322.
    SHI Shun-xiang, LI Jia-li, WANG Guang-sheng. A new type of rapid narrow laser beam electro-optic scanner［J］. Actaoptica Sinica, 2002, 22(11):1318-1322.(in Chinese with an English abstract) ［11］梁华伟 石顺祥 李家立.新型波导阵列电光扫描器特性研究［J］.光子学报，2008， 37(1) ：1-5.
    LIANG Hua-wei,SHI Shun-xiang，LI Jia-li, Study on characteristics of a novel waveguide array electro-optic scanner［J］， Acta Photonica Sinica，2008 37(1) ：1-5. (in Chinese with an English abstract)
    ［12］吴新社,蔡毅. 透射式固态电光扫描器设计［J］. 红外与激光工程,2006,35(4):424-428,489.
    WU Xin-she,CAI Yi.Design of solid-state electro-optic transmission scanner［J］. Infraredand LaserEngineering, 2006,35(4):424-428,489. (in Chinese with an English abstract)
    ［13］艾月霞,李景镇,龚向东.超越曲面电极结构电光偏转器研究［J］.光学学报,2006,35 (1):33-36.
    AI Yue-xia , LI Jing-zhen ,GONG Xiang-dong. Studies on electro-optic deflector with hypersurface electrode structure［J］. Acta Photonica Sinica， 2006,35 (1):33-36. (in Chinese with an English abstract)
    ［14］KRISHNAMURTHI M, TIAN Li-li,GOPALAN V. Design and simulation of planar electro-optic switches in ferroelectrics［J］. Applied Physics Letters, 2008,93(5),052912-1-052912-3.
    ［15］HISATAKE S, TADA K,NAGATSUMA T. Linear time-to-space mapping system using double electrooptic beam deflectors［J］. Optics Express, 2008,16(26),21753-21761.
    ［16］BOSCO A, BOOGERT S T, BOORMAN G E. A large aperture electro-optic deflector［J］. Applied Physics Letters, 2009,94(21),211104-1-211104-3.
    ［17］刘晓军, 宋浩, 王益民,等. 一种激光平行分束器的设计［J］. 应用光学,2008,29(1):31-34.
    LIU Xiao-jun, SONG Hao, WANG Yi-min,et al. A novel laser beam splitter［J］. Journal of Applied Optics, 2008,29(1):31-34. (in Chinese with an English abstract) ［18］蒋民华.晶体物理［J］.山东:山东科学技术出版社,1980.
    JIANG Min-hua. Crystal physics［J］. Shandong: Shandong Science & Technology Press,1980.(in Chinese)
    ［19］张克从,王希敏.非线性光学晶体材料科学［J］.北京：科学出版社, 2005.
    ZHANG Ke-cong, WANG Xi-min, Materials science of nonlinear optical crystal［J］.Beijing: Science Press,2005.(in Chinese)
