Third generation of image intensifier brightness gain measurement device
-
摘要: 微光像增强器是微光夜视仪的核心器件，它是微光夜视整机性能和价格的决定因素。微光像增强器是在微弱的光线下工作的 ,因此必然是光能放大器。亮度增益是评价微光像增强器光电性能的一个重要参数，它直接影响了微光整机的性能，因此，对像增强器的亮度增益测试技术的研究具有重要意义。文中介绍了三代微光像增强器的亮度增益测量原理和装置，并对测量结果进行了不确定度评定。Abstract: The glimmer intensifier is core component of low light level night vision device, and it is the determining factor of glimmer night vision complete machine performance and price. Since the glimmer intensifier works under weak light , it is the light energy amplifier. Brightness gain is a key parameter of the glimmer intensifier electro-optic property assessment, which effects the complete machine performance directly, therefore, research on the brightness gain test technology of image intensifier has great significance. This paper introduced the principle and equipment of third generation glimmer intensifier brightness gain measurement, and carried on the uncertainty evaluation of the measurement result.
-
Keywords:
- LLL image intensifier /
- luminance gain /
- uncertainty
-
-
［1］高岳，王仲春，高稚允.像管亮度增益与背景测试仪［J］.应用光学，2003,24(5)：14-15.
GAO Yue, WANG Zhong-chun, GAO Zhi-yun. Test instrument for brightness gain and background of image tube［J］. Journal of Applied optics, 2003,24(5)：14-15.(in Chinese with an English abstract)
［2］钱芸生，常本康，邱亚峰，等.微光像增强器亮度增益和等效背景照度测试技术［J］.真空电子技术，2004(2)：35-37.
QIAN Yun-sheng, CHANG Ben-kang, QIU Ya-feng, et al. Measurement of luminance gain and equivalent background input LLL image intensifiers［J］. Vacuum Electronics, 2004(2)：35-37. (in Chinese with an English abstract)
［3］邹异松，刘玉风，白廷柱.光电成像原理［M］.北京：北京理工大学出版社，1997:84-90.
ZOU Yi-song, LIU Yu-feng, BAI Ting-zhu. Principles of optical imaging［M］. Beijing；Beijing Institute of Technology Press, 1997:84-90. (in Chinese)
［4］方如章，刘玉凤.光电器件［M］.北京：国防工业出版社，1988:151-154.
FANG Ru-zhang, LIU Yu-feng. Optoelectronic devices［M］. Beijing: National Defence Industry Press, 1997:84-90. (in Chinese)
［5］周斌，刘秉琦.CCD用于像增强器亮度增益测试的研究［J］.传感器技术，2004，23(12):20-24.
ZHOU Bin, LIU Bing-qi. Research of test of image intensifier's brightness gain with CCD transducer［J］. Journal of Transducer Technology, 2004，23(12):20-24. (in Chinese with an English abstract)
［6］刘宇，马月琴，姜均炎，等.一种新的微光像增强器综合测试系统［J］.应用光学，1997,18(3):17-22.
LIU Yu, Ma Yue-qin, JIANG Jun-yan, et al. A new comprehensive test system for low-light-level image intensifiers［J］.Journal of Applied optics, 1997,18(3):17-22. (in Chinese with an English abstract)
