离子束反应溅射沉积SiO2薄膜的光学特性

米高园; 朱昌; 戚云娟; 达斯坦科; 格拉索夫; 扎瓦斯基

离子束反应溅射沉积SiO2薄膜的光学特性

1.
西安工业大学,陕西西安 710032;
2.
白俄罗斯国立信息与无线电大学,白俄罗斯明斯科 220013

详细信息

通讯作者:
米高园（1985-），女，陕西长安人，硕士研究生，主要从事薄膜技术和等离子方面的研究工作。

中图分类号: TN305.92； O484.4
计量
- 文章访问数: 3861
- HTML全文浏览量: 101
- PDF下载量: 637
- 被引次数: 0
出版历程
- 刊出日期: 2011-03-15

Optical properties of silicon oxide thin films deposited by reactive ion-beam sputtering method

1.
Xi-an Technological University,Xi-an 710032,China;
2.
Belarusian State University of Informatics and Radioelectronics,Minsk 220013,Belarus

摘要

摘要: 主要研究采用离子束反应溅射（RIBS）制备SiO2薄膜的折射率、消光系数、化学计量比与氧气在氩氧混合工作气体中含量及其沉积速率的关系。研究结果表明：RIBS制备的SiO2薄膜在0.63 m处折射率n= 1.48，消光系数小于10-5；随着沉积速率的增加，薄膜的折射率和消光系数随之变大，当沉积速率超过0.3 nm/s，即使是在纯氧环境溅射，折射率值也不低于1.5；通过对红外透射光谱的主吸收峰位置研究得到沉积的SiO2薄膜为缺氧型，化学计量比不超过1.8，且红外吸收峰位置和SiO2折射率存在对应关系，因此在不加热衬底情况下使用RIBS制备SiO2薄膜时，会限制沉积速率的提高。
- 氧化硅 /
- 反应离子束溅射 /
- 光学常数 /
- 沉积速率
Abstract: Silicon oxide thin films deposited by reactive ion-beam sputtering (RIBS) of Si targets in Ar/O2 producer gas mixture were investigated. The refractive index n, extinction coefficient k, and stoichiometry were dependent on the oxygen concentration in Ar/O2 producer gas mixture and the deposition rate. Silicon oxide films with refractive index of n =1.48 and extinction coefficient of less than 10-5 were deposited with the RIBS method at the wavelength of 0.63 m. An increase in the deposition rate results in the growth of refractive index and extinction coefficient of the film due to incomplete oxidation of silicon and formation of suboxides. In the case of deposition rate more than 0.3 nm/s, even if sputtering is performed in pure oxygen environment, the minimal value of refractive index is more than 1.5. The ana-lysis of the IR transmission spectrum proves that all the deposited films have oxygen deficiency, and the stoichiometry of silicon oxide does not exceed 1.8 based on the investigation of the position of the main absorption peak. The dependence between IR adsorption peak position and refractive index of silicon oxide is established. Thus, depositing silicon-oxide thin films with RIBS without heating the substrates limits the increase of deposition rate.
- silicon oxide /
- reactive ion-beam sputtering /
- optical constant /
- deposition rate

HTML全文

参考文献(1)

［1］NPD Group Company. Flexible display (report)［R］. ［S.l.］: DisplaySearch, an NPD Group Company, 2006: 359.
［2］VARASI M, MISIANO C, LASAPONARA L. Deposition of optical thin films by ion-beam sputtering［J］. Thin Solid Films, 1984, 117(3): 163-172.
［3］GOLOSOV D A, ZAVATSKIY S M, DOSTANKO A P, et al. Optical properties of a silicon oxide thin films deposited by reactive magnetron sputtering method［C］. ［S.l.］: VI International Conference Plasma Physics and Plasma Technology, 2009(2): 535-538.
［4］GOLOSOV D A, ZAVATSKIY S M, DOSTANKO A P. Properties of silicon oxide films deposited by methods of ionbeam and reactive ion-beam sputtering［C］. ［S.l.］: IV International Conference Modern Methods and Technologies Material Formation and Processing, 2009(1): 81-86.
［5］朱昌, 米高园, 达斯坦科, 等. 比较2种溅射方法镀制的氧化硅薄膜［J］. 应用光学, 2010, 31(5): 855-859.
ZHU Chang, MI Gao-yuan, DOSTANKO A P, et al. Comparison of reactive magnetron and reactive ion-beam sputtering methods for deposition of silicon oxide thin films［J］. Journal of Applied Optics, 2010, 31(5): 855-859. (in Chinese with an English abstract)
［6］GIUSTINO F, PASQUARELLO A. Infrared spectra at surfaces and interfaces from first principles: evolution of the spectra across the Si(100)-SiO2 interface［J］. Physical Review Letters, 2005, 95(18): 7402-7403.
［7］TOMOZEIU N, VAN HAPERT J J, VAN FAASSEN E E, et al. Structural properties of a-SiOx layers deposited by reactive sputtering technique［J］. Optoelectronics and Advanced Materials, 2002, 4(3): 513-521.
［8］TOMOZEIU N. SiOx thin films deposited by r.f. magnetron reactive sputtering: structural properties designed by deposition conditions［J］. Optoelectronics and Advanced Materials, 2006, 8(2): 769-775.
