旋转部件切向位移偏差实时监测系统及其关键技术研究

傅倩; 陈长缨; 陈曦; 洪岳; 赵惠珊; 莫晨晓; 骆宏图

旋转部件切向位移偏差实时监测系统及其关键技术研究

傅倩^1,2, ,,
陈长缨^1,2,
陈曦^1,2,3,
洪岳^1,2,
赵惠珊^1,2,
莫晨晓^1,2,
骆宏图^1,2

1.
暨南大学光电信息与传感技术广东普通高校重点实验室,广东广州510632;
2.
暨南大学光电工程系,广东广州510632;
3.
中国电信广州无线网络运营中心,广东广州510632

详细信息

通讯作者:
傅倩(1985-),女,浙江东阳人,硕士,主要从事光电检测技术及光通信方向研究工作。

中图分类号: TN247
计量
- 文章访问数: 4328
- HTML全文浏览量: 141
- PDF下载量: 655
出版历程
- 刊出日期: 2011-03-14

Real-time detection of tangential displacement deviation in rotating parts

FU Qian^1,2, ,,
CHEN Chang-ying^1,2,
CHEN Xi^1,2,3,
HONG Yue^1,2,
ZHAO Hui-shan^1,2,
MO Chen-xiao^1,2,
LUO Hong-tu^1,2

1.
Jinan University,Key Laboratory of Optoelectronic Information and Sensing Technologies of Guangdong Higher Education Institutes,Guangzhou510632,China;
2.
Department of Photoelectric Engineering,Jinan University,Guangzhou510632,China;
3.
Wireless Network Operate Center of China Telecommunications,Guangzhou510632,China

摘要

摘要: 控制套印误差是现代印刷技术的重要课题，而印刷机滚筒在旋转过程中表面各点的切向位移偏差是套印误差产生的主要原因。为此，论文设计并实现了旋转部件切向位移偏差实时监测系统，该系统利用光电检测以及模/数混合信号处理方法实现了对印刷机套印误差的实时监测，可用于高精度印刷机械的研发与制造过程。系统采用了条形码编码技术、虚拟标尺技术、动态切向位移偏差实时测量技术以及自适应动平衡技术4项关键技术，测量精度可达到10 m。
- 切向位移偏差 /
- 光电检测 /
- 虚拟标尺 /
- 混合信号处理 /
- 自适应动平衡
Abstract: Controlling overprint error is an important for modern printing technology, and the displacement deviation of press cylinder surface in high-speed rotation state is a major cause of overprint error. The real-time monitoring system for detecting the tangential displacement deviation in rotating parts was designed and implemented. Photoelectric detection and A/D mixed-signal processing method was used to realize real-time monitoring of the press overprint error, which could be used for research and manufacturing process of high precision printing machinery. Barcode coding technology, virtual calibration technology and real-time monitoring technology for tangential displacement deviation and self-adaptive dynamic balance technology were used in the system, and the measuring precision was controlled within 10m.
- tangential displacement deviation /
- photoelectric detection /
- virtual calibration /
- mixed-signal processing /
- self-adaptive dynamic balance

HTML全文

参考文献(1)

［1］于丽杰，李德胜，王跃宗,等. 离线彩色套印误差测量系统［J］. 北京工业大学学报, 2008,34(5):466-467.

YU Li-jie, LI De-sheng, WANG Yue-zong, et al. An off-line system on detection of overprint deviation in color printing ［J］. Journal of Beijing University of Technology, 2008, 34(5):466-467. (in Chinese with an English abstrct)

［2］夏军.关于套印问题的研究［J］. 印刷杂志, 2002(06): 42-45.

XIA Jun.The study of overprint［J］.Printing Field, 2002 ( 06 ): 42-45. (in Chinese with an English abstrct)
［3］KITTILA M, HAGBERG J, JAKKU E, et al. Direct gravure printing(DGP) method for printing fine-line electrical circuits on ceramics［J］. IEEE Transactions on Electronics and Packaging Manufacturing (S1521-334x), 2004, 27(2): 109-114.

［4］TANIMIZU K, MEGURO S, ISHII. A high-speed defect detection method for color printed matter［J］. Industrial Electronics Society, 1990, IECON′90., 16th Annual Conference of IEEE, 1990, 1: 27-30;653-658.

［5］冯晓强,侯洵,杨文正,等.彩色套印色标的光电检测［J］.光子学报,2003,32(11): 1135-1336.

FENG Xiao-qiang, HOU Xun, YANG Wen-zheng, et al. Photo-electric detection of overprint deviation in color printing［J］. Acta Phononica Sinica, 2003,32(11):1335-1336. (in Chinese with an English abstrct)

［6］SHAFEI E A, El-KABBANY A S, YOUNAN A A.Rotor balancing without trial weights［J］. Journal of Engineering for Gas Turbines and Power, 2004, 126(03):604-607.

［7］周骏, 潘晓铭，周哲为.转子动平衡的技术研究［J］.机械设计与制造,2007,04(04):151-152.

ZHOU Jun, PAN Xiao-ming, ZHOU Zhe-wei. Rotator dynamic balance technology studies［J］. Machinery Design & Manufacture, 2007,04(04):151-152. (in Chinese with an English abstrct)
［8］胡太苗，叶德新，樊曙.无孔脱水洗衣机原理及脱水桶、平衡圈的几个设计参数探讨［J］.家电科技, 2004,1(06):57-58.

HU Tai-miao, YE De-xin, FAN Shu. Principle of nonporous dehydrating washer and discussion on some parameters of dehydrating barrel and balance ring［J］. Science and Technology of Household Electric Appliance , 2004,1(06):57-58. (in Chinese)

［9］沈建华, 杨艳琴, 翟骁曙. MSP430系列16位超低功耗单片机原理与应用［M］.北京: 清华大学出版社, 2005.

SHEN Jian-hua, YANG Yan-qin, ZHAI Xiao-shu. Principles and applications of MSP430 series of 16-bit ultra low power single microcontrollers［M］. Beijing: Tsinghua University Press, 2005. (in Chinese)
