Walker-Δ星座轨道间激光链路的稳定性研究

吴继礼; 李勇军; 赵尚弘; 王翔; 侯睿; 石磊

Walker-Δ星座轨道间激光链路的稳定性研究

1.
空军工程大学电讯工程学院,陕西西安710077

详细信息

通讯作者:
吴继礼(1981-)，男，四川名山人，博士研究生，主要从事空间光通信与组网技术工作。

中图分类号: TN929.13
计量
- 文章访问数: 3297
- HTML全文浏览量: 115
- PDF下载量: 773
- 被引次数: 0
出版历程
- 刊出日期: 2011-01-15

AStability of inter-plane laser links in Walker-Δ constellation

1.
Telecommunication Engineering School of AFEU,Xi’an 710077,China

摘要

摘要: 根据Walker-星座中相邻轨道卫星的相位差，引入轨道间激光链路连接参数K，建立参考卫星固联坐标系中目标卫星运动方程，得到不同轨道卫星之间方位角、俯仰角和距离(AER)的解析表示式，进而求出AER及其变化率极值的数值解。其中相邻轨道卫星的方位角变化率和变化范围都远大于俯仰角，对激光链路稳定性影响较大；方位角最大变化率同最小距离成反比，在极端情况下会超出激光通信终端跟踪范围导致链路中断。综合轨道间激光链路的稳定性和网络拓扑结构的复杂程度，得出相对连接相位为0是激光链路的低轨卫星星座连接配置方式。
- 卫星光网络 /
- Walker-Δ星座 /
- 星间激光链路 /
- 网络拓扑
Abstract: The relative phase between the neighboring nodes in the adjacent planes of Walker- constellation was introduced as the connecting parameter K. The motion equations in the body-fixed coordinates system of reference satellite were established to obtain the azimuth angle, elevation angle and range (AER) of the inter-plane laser links. Then, the extremums of AER and the variation rates were calculated numerically. Among the AER, the azimuth angle rate, with the maximum value inversely ratio to the minimum range, impacts the stability of laser links significantly. In some extreme cases, it would be too fast to track the laser beam because of large azimuth angle velocities. K=0 is a good trade off between the linksstability and the complexity of the network topology, and is fit for low earth satellite optical networks.
- satellite optical network /
- Walker-Δ constellation /
- inter-satellite laserlink /
- network topology

HTML全文

参考文献(1)

［1］张艳，张育林.具有星间链路的星座相位设计［J］.宇航学报,2004,25(6):669-673.ZHANG Yan, ZHANG Yu-lin. Phase design of constellation with intersatellite links［J］. Journal of Astronautics, 2004, 25(6):669-673.(in Chinese with an English abstract)［2］李晖, 顾学迈.多层卫星通信网络设计及星间链路几何特征分析［J］. 宇航学报, 2005,26(增刊):59-65.LI Hui, GU Xue-mai. Design of multilayered satellite communication networks and geometrical analysis of ISLs［J］. Journal of Astronautics, 2005,26(sup),59-65. (in Chinese with an English abstract)［3］PRATT T, BOSTIAN C, ALLNUTT J.卫星通信［M］.第2版.甘良才,译.北京: 电子工业出版社, 2005.PRATT T,BOSTIAN C,ALLNUTT J.Satellite communication［M］. Translated by GAN Liang-cai. Beijing: Publishing House of Electronics Industry, 2005.(in Chinese)［4］KELLER H, SALZWEDEL Horst. Comparison of the probability of visibility of new planned mobile satellite systems(M-Star,Celestri,SkyBridge) ［EB/OL］.http://ieeexplore.ieee.org/Xplore/login.jsp?url=http% 3A%2F%2Fieeexplore.ieee.org% 2Fiel4% 2F5616% 2F15024% 2F00686479.pdf%3Farnumber%3D686479&authDecision=-203.［5］FRAISE P, COULOMB B, MONTEUUIS B, et al. Skybridge LEO satellites: optimized for broadband communications in the 21st century［EB/OL］. http://ieeexplore.ieee.org/xpl/freeabsall.jsp?arnumber=879395.［6］SUZUKI R, YASUDA Y. Study on ISL network structure in LEO satellite communication systems［J］. Acta Astronautica, 2007,61:648-658.［7］李睿,赵洪利,曾德贤.空间激光通信及其关键技术［J］.应用光学,2006,27(2):152-154.LI Rui,ZHAO Hong-li, ZENG De-xian. Freespace laser communication and its key technology. Journal of Applied Optics, 2006,27(2):152-154. (in Chinese with an English abstract)［8］于思源,刘剑峰,张光宇,等.基于拉盖尔2高斯光束的单光子捕获理论研究［J］.应用光学,2008,29(2):303-307.YU Si-yuan, LIU Jian-feng, ZHANG Guang-yu, el al. Theoretical study of single-photon acquisition based on Laguerre-Gaussian beams［J］. Journal of Applied Optics, 2008,29(2):303-307. (in Chinese with an English abstract)［9］TOLKER-NIELSEN T, OPPENHAEUSER G.In orbit test result of an operational optical inter-satellite link between ARTEMIS and SPOT4, SILEX［J］. SPIE,2002,4635:1-15.［10］SMUTINY B, KAEMPFINER H, MUEHLNIKEL G, et al. 5.6 Gbps optical intersatellite communi-cation link［J］.SPIE,2009,7199:719906.［11］赵尚弘,李勇军,吴继礼.卫星光网络技术［M］.北京:科学出版社,2010. ZHAO Shang-hong, LI Yong-jun, WU Ji-li. Satellite optical networks［M］. Beijing: Publishing House of Science, 2010.(in Chinese)［12］LI Yong-jun,WU Ji-li,ZHAO Shang-hong, et al. A novel two-layered optical satellite network of LEO/MEO with zero phase factor［J］. Science China Information Science, 2010,53(6):1261-1276.［13］LI Yong-jun, WU Ji-li, ZHAO Shang-hong. Desi-gning of a novel optical two-layered satellite network［EB/OL］. http://ieeexplore.ieee.org/xpl/freeabsall.jsp?arnumber=4722781.［14］FIELDS R, Fields, LUNDE C, WONG R, et al. NFIRE-to-TerraSAR-X laser communication resul-ts: satellite pointing, disturbance, and other attributes consistent with successful performance［J］.SPIE,2009,7330,73300Q-1-15.
