结构简洁的光学变焦距手机镜头设计

张韧剑; 冯亚萍; 江曼; 任兆玉

结构简洁的光学变焦距手机镜头设计

1.
西北大学光子学与光子技术研究所,陕西西安 710069;
2.
宁波大学理学院,浙江宁波315211

详细信息

通讯作者:
张韧剑(1985-)，男，陕西宝鸡人，硕士研究生，主要从事光学设计和固体激光器件方面的研究.

中图分类号: TN942.21
计量
- 文章访问数: 3647
- HTML全文浏览量: 111
- PDF下载量: 1154
- 被引次数: 0
出版历程
- 刊出日期: 2011-01-15

ACompact optical zoom lens system for mobile phones

1.
Institute of Photonics &Photo Technology,Northwest University,Xi’an 710069,China;
2.
Ningbo University’s Faculty of Science,Ningbo 315211,China

摘要

摘要: 通过利用ZEMAX光学工程设计软件设计了一款适用于手机的2倍内置式光学变焦距镜头。镜头仅由4片非球面的塑料透镜和1片BK7的红外滤光片构成，能够达到285lp/mm的空间频率，可匹配1.75m的COMS图像传感器，全视场RMS半径均小于艾利斑半径，全视场最大畸变小于3%，MTF值在1/2奈奎斯特频率处的大部分视场大于0.5，总长度小于9.2mm。整个变焦距系统结构紧凑，分辨率高，成本低，可满足手机镜头光学变焦的要求。
- 光学变焦 /
- ZEMAX /
- 非球面透镜 /
- MTF /
- 手机镜头
Abstract: A compact 2X optical zoom lens system for mobile phones was designed with ZEMAX. The system consists of 4 plastic aspheric lenses and an IR filter. The limiting resolution is 285lp/mm, which matches the CMOS image sensor of 1.75m pixel size. In the whole field of view (FOV), the RMS raidus is less than airy disk and the maximum distortion is less than 3%, the MTF at the half Nyquist frequency (285pl/mm)of CMOS in most part of the FOV were greater than 0.5,and the length of the optical zoom lens system is less than 9.2mm. It is compact in structure, high in resolution and low in cost, which meets the zoom lens system requirements of mobile phones.
- optical zoom /
- ZEMAX /
- aspherical lens /
- MTF /
- phone camera

HTML全文

参考文献(1)

［1］CHUNG Jae-Hoon, JUNG Sung-Hoon, LEE Man-Hyung. Implementation of a 3 times zoom lens barrel system for a 5M camera module using a mobile phone［M］. International Journal of Control, Automation, and Systems,2009,7(5):745-754.［2］FANGA Y C, TSAIB H L, CHIEN Y H. 2X optical digital zoom lens with short total length and extremely small front aperture for two million pixel CMOS on mobile phone［M］. Optical Society of America,2006,220(3630):WB6.［3］陶纯堪.变焦距光学系统设计［M］.北京：国防工业出版社，1988.TAO Chun-kan. Zoom lens design［M］. Beijing:National Defence Industry Press,1988.(in Chinese)［4］温同强，黄城，陆建华，等. 紧凑型变焦镜头的设计［J］. 科学技术与工程，2008，8(17)：4979-4982.WEN Tong-qiang,HUANG Cheng,LU Jian-hua,et al. New design of the compact digital zoom lens［J］. 2008,8(17):4979-4982.(in Chinese with an English abstract)［5］高明，段晶.高变倍比数码变焦镜头设计［J］. 应用光学,2009，30(1)：1-5.GAO Ming,DUAN Jing.Optical design of highmagnification digital zoom lens［J］. Journal of Applied Optics, 2009,30(6):1-5. (in Chinese with an English abstract)［6］张萍，王诚，宋东王番，等. 500万像素手机镜头设计［J］.应用光学，2009，30(6)：934-938.ZHANG Ping,WANG Cheng,SONG Dong-fan,et al. Design of lens for 5 mega-pixel mobile phone cameras［J］. Journal of Applied 0ptics, 2009,30(6):934-938. (in Chinese with an English abstract)［7］李晓彤，岑兆丰. 几何光学像差光学设计［M］.浙江：浙江大学出版社， 2007.LI Xiao-tong, CEN Zhao-feng. Geometrical optics·aberrations and optical design［M］.Zhejiang:Zhejiang University Press, 2007. (in Chinese)
