Computer added Ritchey-Common test for large flat mirror measurement
-
摘要: 在瑞奇-康芒检测中，被检平面本身所固有的像散和大曲率在被检系统波像差数据中都表现为像散。由于被检平面处于发散光路中,这就使得平面面形与系统波像差之间的关系(即影响函数)变得十分复杂,推导起来十分困难，只能进行定性或半定量检测。文中介绍了如何通过计算机光线追迹模拟瑞奇-康芒检验，在两个瑞奇角下得到两组影响函数，以此建立过定方程组，由干涉仪检测得到的两个不同瑞奇角下的系统波像差，通过最小二乘法解过定方程组，拟合得到被检平面镜的面形误差；实现了大口径平面镜的定量检测，并以平面镜直接检验的面形误差作为对比，检验结果的一致验证了该方法的准确性与可行性。Abstract: In Ritchey-Common test，the intrinsic astigmatism of the mirror plane under test and the astigmatism of the large curvature can not be distinguished in the measured system wave-front aberration. The flat is set in a divergent beam, which makes the relation between figure errors of flat and wavefront aberrations (influence function) complicate and difficult to derive. The procedure to simulate the Ritchey-Common test to derive the relationships between the figure errors of an optical flat and the wavefront aberrations, as well as the procedure to construct two set of influence functions by ray-tracing program are presented. Figure errors of the flat can be extracted from a set of over defined linear equations with the aid of least squares, using the influence functions and the measured wavefront aberrations for two different Ritchey angles. Both Ritchey-Common test and direct measurement results are presented. The comparison result proved the feasibility and reliability of this method．
-
Keywords:
- optics test /
- Ritchey-Common test /
- wavefront aberration /
- influence function
-
-
［1］SHU K L. Ray-trace analysis and data reduction methods for the Ritchey-Common test［J］. Appl Opt, 1983,22(12):1879-1886.
［2］HAN SEN, ERIK NOVAK. Application of Ritchey-Common test in large flat measurements［J］. SPIE, 2001,4399:131-136.
［3］田秀云，吴时彬，伍凡，等.高精度大口径平面镜瑞奇-康芒定量检测方法研究［J］.光学技术，2004，30(4)：486-488.
TIAN Xiu-yun, WU Shi-bin, WU Fan，et al. Quantitative test method of Ritchey-Common test in large high precision flat measurements［J］.Optical Technique,2004,30(4):486-488.(in Chinese with an English abstract)
［4］MALACARA D.Optical shop testing(Third Edi-tion)［M］.New Jersey：Wiley, 2007：310-313.
［5］曹根瑞, 安德逊,邵联贞，等. 计算机辅助的瑞奇-康芒检验［J］.北京工业学院学报,1988,8(4):46-53.
CAO Gen-rui, ANDERSON D S,SHAO Lian-zhen，et al. Computer added Ritchey-Common test［J］. Beijing Inst.Technol, 1988,8(4):46-53.(in Chinese with an English abstract)
［6］田秀云，吴时彬，伍凡，等.瑞奇-康芒法中的一种数据处理方法［J］.光电工程，2004，31(1):24-25.
TIAN Xiu-yun, WU Shi-bin, WU Fan，et al. A data processing method in Ritchey-Common test［J］.Opto-Electronic Engineering，2004，31(1):24-25.(in Chinese with an English abstract)
［7］袁吕军，邢娜. 大口径光学平面瑞奇康芒检测技术的研究［J］.光学技术，2007，33(5):737-744.
YUAN Lu-jun，XING Na. Study on the Ritchey-Common interferometry for large plane optics［J］. Optical Technique, 2007，33(5):737-744.(in Chinese with an English abstract)
［8］ZYGO，CORPORATIAN. Ritchey-common metro-Pro application［M］.Connecticut: Zygo Cor-poration, 2004.
