左手材料平板对傍轴高斯光束聚焦特性分析

易煦农, 刘劲松, 陈欢, 杜秋姣

易煦农, 刘劲松, 陈欢, 杜秋姣. 左手材料平板对傍轴高斯光束聚焦特性分析[J]. 应用光学, 2010, 31(6): 883-887.
引用本文: 易煦农, 刘劲松, 陈欢, 杜秋姣. 左手材料平板对傍轴高斯光束聚焦特性分析[J]. 应用光学, 2010, 31(6): 883-887.
YI Xu-nong, LIU Jin-song, CHEN Huan, DU Qiu-jiao. Analysis of focusing properties for paraxial Gaussian beam focused by a left-handed material slab[J]. Journal of Applied Optics, 2010, 31(6): 883-887.
Citation: YI Xu-nong, LIU Jin-song, CHEN Huan, DU Qiu-jiao. Analysis of focusing properties for paraxial Gaussian beam focused by a left-handed material slab[J]. Journal of Applied Optics, 2010, 31(6): 883-887.

左手材料平板对傍轴高斯光束聚焦特性分析

详细信息
    通讯作者:

    易煦农(1979-),男,湖南湘潭人,华中科技大学光电子科学与工程学院博士研究生,主要从事新型人工电磁材料的光传输特性研究。

  • 中图分类号: TN204

Analysis of focusing properties for paraxial Gaussian beam focused by a left-handed material slab

  • 摘要: 在傍轴近似下,推导出了左手材料平板聚焦系统的传输矩阵,并利用ABCD定律得到了高斯光束在左手材料中和经过平板透镜聚焦后的传输公式。高斯光束在左手材料内部和像空间的传输公式的研究表明:像高斯光束和物高斯光束束腰大小一致,即左手材料平板透镜实际上对高斯光束没有聚焦作用。研究同时表明左手材料平板对高斯光束的聚焦与几何光学成像规律完全一致,而不存在一般透镜聚焦时的焦移效应。
    Abstract: Under paraxial approximation, the transfer matrix of left-handed slab focusing system is derived. Using ABCD law, the propagation expressions for Gaussian beam focused by a left-handed material slab are obtained. On the basis of propagation formula, the focusing properties of Gaussian beam are analyzed. The beam waist of image Gaussian beam is equal to the beam waist of object Gaussian beam under paraxial approximation, that is to say, the left-handed material slab can not focus Gaussian beam. The focusing for Gaussian beam with a left-handed material coincides with imaging rules of geometrical optics and does not have focal shift.
  • [1]VESELAGO V G. The electrodynamics of substan-ces with simultaneously negative values of ε and μ[J]. Sov.Phys.Usp.,1968,10(4):509-514.
    [2]SMITH D R, PADILLA W J, VIER D C, et al. A composite medium with simultaneously negative permeability and permittivity[J]. Phys. Rev. Lett., 2000, 84(18):4184-4187.
    [3]PENDRY J B.Negative refraction makes a perfect lens[J]. Phys. Rev.Lett.,2000,85(18):3966-3969.
    [4]SHELBY R A, SMITH D R, SCHULTZ S. Ex-perimental verification of a negative index of refraction[J]. Science, 2001,292(6):77-79.
    [5]PARAZZOLI C G, GREEGOR R B, LI K, et al. Experimental verification and simulation of negative index of refraction using Snell’s law[J]. Phys.Rev.Lett.,2003,90(10):1074011-1074014.
    [6]SMITH D R, PENDRY J B, WILTSHIRE M C K. Metamaterials and negative refractive index[J]. Science, 2004,305(5685):788-792.
    [7]SHADRIVOV I V,SUKHORUKOV A A,KIVS-HAR Y S. Guided modes in negative index waveguides[J]. Phys.Rev.E,2003,67(5):057602.
    [8]SHADRIVOV I V, SUKHORUKOV A A, KIVS-HAR Y S, et al. Nonlinear surface waves in left-handed materials[J]. Phys.Rev.E,2004,69(1):016617.
    [9]BROCK J B, HOUCK A A, CHUANG I L. Focu-sing inside negative index materials[J]. Appl Phys Lett, 2004,85(13):2472-2474.
    [10]LUO H L, HU W, REN Z Z, et al. Focusing and phase compensation of paraxial beams by a lefthanded material slab[J]. Opt. Commun., 2006,266:327-331.
    [11]林振,梁昌洪.负媒质模型的时域有限差分法分析[J].强激光与粒子束,2006,18(4):615-617.
    LIN Zhen, LIANG Chang-hong. Time domain analysis of negative refractive index materials by FDTD method[J]. High Power Laser and Particle Beams, 2006,18(4):615-617. (in Chinese with an English abstract)
    [12]梁斌明,姚翠雅,李卓,等. 折射率偏离-1时的平板成像特性及改善[J].应用光学,2010,31(1):19-23.
    LIANG Bin-ming, YAO Cui-ya, LI Zhuo, et al. Slab imaging performance from-1 and its improvement[J]. Journal of Applied Optics, 2010,31(1):19-23. (in Chinese with an English abstract)
    [13]CATER W H. Focal shift and concept of effective Fresnel number for a Gaussian laser beam[J]. Appl.Opt.,1982,21(11):1989-1994.
