Polarization properties of thin film Fabry-Pérot filter
-
摘要: 用特征矩阵法研究了薄膜法布里-珀罗滤光片的偏振特性。研究发现：随着入射角增大，s偏振光透射模和p偏振光透射模的波长逐渐分离，但分离的幅度较小；随着入射角增大，s偏振光透射模的透射率作幅度较大的震荡变化，而p偏振光透射模的透射率变化较小；当入射角以1/100的间隔变化时，可以在透射模波长不变的情况下，使s偏振光透射模的透射率发生显著变化，而p偏振光透射模的透射率基本不变。薄膜法布里-珀罗滤光片的偏振特性可以在角度变化的测量中发挥重要作用。Abstract: The polarization properties of thin film Fabry-Prot filter is investigated by eigen method. With the increase of incident angle, the wavelengths of the transmission modes of s-polarized light and p-polarized light separate gradually, but the separation is small. The transmittance of the transmission mode of s-polarized light vibrates greatly and the transmittance of the transmission mode of p-polarized light vibrates little with the increase of incident angle. When the incident angle changes at the separation of 1/100, the wavelengths of the transmission mode of s-polarized light and p-polarized light keep unchanged and the transmittance of the transmission mode of s-polarized light changes significantly, while the transmittance of the transmission mode of p-polarized light changes very small. The polarization properties of film Fabry-Prot filter can play an important role in angle measurement.
-
Keywords:
- thin film optics /
- Fabry-Pérot filter /
- polarization
-
-
［1］陈海星,顾培夫,吕维阁,等.薄膜法布里-珀罗滤光片中的超棱镜效应［J］. 光学学报, 2006,25(1):157-160.
CHEN Hai-xing, GU Pei-fu, LU Wei-ge, et al. Superprism effect in thin film Fabry-Perot filter［J］. Acta Optica Sinica, 2006,25(1):157-160.(in Chinese with an English abstract)
［2］于志明, 周静.窄带缺陷模在入射角缓慢变化中的变化规律［J］.半导体光电,2008,29(6):876-883.
YU Zhi-ming, ZHOU Jing. Changes of narrow defect mode during the small changes of incident angle［J］. Semiconductor Optoelectronics, 2008,29(6):876-883. (in Chinese with an English abstract)
［3］于志明,周静.基于一维缺陷光子晶体的角度测量仪的设计［J］.激光与红外, 2008,38(12):1237-1240.
YU Zhi-ming, ZHOU Jing. A design for the angle measurement with 1D defect photonic crystal［J］. Laser ＆ Infrared, 2008,38(12):1237-1240. (in Chinese with an English abstract)
［4］王辉,李永平.用特征矩阵法计算光子晶体的带隙结构［J］.物理学报,2001,50(11):2172-2178.
WANG Hui, LI Yong-ping. An eigen matrix method for obtaining the band structure of photonic crystals［J］. Acta Physica Sinica, 2001,50(11):2172-2178. (in Chinese with an English abstract)
［5］顾国昌,李宏强,陈洪涛,等.一维光子晶体材料中的光学传输特性［J］. 光学学报, 2000,20(6):728-734.
GU Guo-chang, LI Hong-qiang, CHEN Hong-tao, et al. Properties of light propagation in 1-D periodic dielectric structure［J］. Acta Optica Sinica, 2000, 20(6):728-734. (in Chinese with an English abstract)
