Fast calculation of laser divergence angle based on Isight
-
摘要: 在完成激光扩束设计后，为了保证投射全程的光斑尺寸要求，需要输出几百甚至上千组镜组位移束散角的对应数据。基于Isight的实验设计模块，利用code V的命令语句进行快速计算，在不到2h的时间里得出了想要的众多数据，较大地提高了效率，并且由于位移数据都是由软件进行修改，避免了人工操作可能产生的错误。Abstract: After a Galileos beam expander is designed, hundreds or thousands data of divergence angles corresponding to the displacements of lens group are calculated to ensure light spot size. Based on the Design of Experiment (DOE) module in Isight, fast calculation is implemented using codeVs command syntax. Hundreds data are obtained in 2 hours. Efficiency is greatly improved, and manual error is avoided thanks to software operation.
-
Keywords:
- divergence angle /
- Isight /
- Design of Experiment /
- BAT
-
-
［1］张以谟.应用光学［M］.3版.北京：电子工业出版社,2008.
ZHANG Yi-mo. Applied optics［M］.3rd edition.Beijing:Publishing house of electronics industry, 2008. (in Chinese)
［2］EngineousSoftware,Inc.ISIGHT-FDversionv2.5.2. userguide［M］. USA:Engineous Software, Inc.1997.
［3］李元,焦明印,罗传伟,等.基于Isight的平面反射镜轻量优化设计［J］.应用光学，2010，31(2):194-197.
LI Yuan,JIAO Ming-yin,LUO Chuan-wei,et al.Optimization design of lightweight flat mirror based on Isight［J］.Journal of Applied Optics，2010，31(2):194-197.(in Chinese with an English abstract)
［4］Optical Research Associates Inc. CodeV prompting guide, volume IV：performing quick LDM analyses［M］. California: Optical Research Associates,2009.
