起偏角对保偏光纤中光波偏振度的影响

韩彪刘继芳, 何伟杰

韩彪刘继芳, 何伟杰, . 起偏角对保偏光纤中光波偏振度的影响[J]. 应用光学, 2010, 31(5): 792-795.
引用本文: 韩彪刘继芳, 何伟杰, . 起偏角对保偏光纤中光波偏振度的影响[J]. 应用光学, 2010, 31(5): 792-795.
shu
HAN Biao, LIU Ji-fang, HE Wei-jie. Influence of starting angle on light’s degree of polarization in polarization maintaining fiber[J]. Journal of Applied Optics, 2010, 31(5): 792-795.
Citation: HAN Biao, LIU Ji-fang, HE Wei-jie. Influence of starting angle on light’s degree of polarization in polarization maintaining fiber[J]. Journal of Applied Optics, 2010, 31(5): 792-795.
shu

起偏角对保偏光纤中光波偏振度的影响

  • 西安电子科技大学 技术物理学院,陕西西安710071

详细信息

  • 中图分类号: TN929.11；TP212.14

Influence of starting angle on light’s degree of polarization in polarization maintaining fiber

  • School of Technical Physics,Xidian University,Xi’an 710071,China

摘要

    摘要
  • 摘要: 实际应用中，入射到保偏光纤的光波通常是准单色光。当入射光的偏振方向与保偏光纤本征轴未对准时，光波在保偏光纤中传播时的偏振度会发生变化。利用部分相干理论分析了准单色偏振光和部分偏振光在保偏光纤中传播时偏振度随起偏角和传播距离的变化情况。实验研究了部分偏振光的偏振度随起偏角变化的规律。研究结果表明：传播距离在厘米量级内时，偏振度随传播距离的变化较明显，对于一般的长距离传输而言，传播距离对偏振度的影响可以忽略；与传播距离相比，起偏角对偏振度的影响较大，为了使偏振度的相对变化量小于0.01%，起偏角必须控制在0.405以内。
    Abstract: In practical application, the light injected to polarization maintaining fiber（PMF）-is typically quasi-monochromatic. When the polarization direction of the incident light and the birefringence axes of the fiber were misaligned, the degree of polarization(DOP) would be changed in transmission process. Using partial coherence theory, the dependence of polarized and partially polarized lights DOP on the starting angle and transmission distance in PMF were analyzed theoretically. And some experiments were done to study the dependence of partially polarized light's DOP on the starting angle. The results show that, if the transmission distance is in centimeter magnitude, the influence on DOP is great. To normal long distance transmission, its influence could be neglected. Compared with the transmission distance, DOP varies greatly with the starting angle. To achieve the relative change of DOP less than 0.01%, the starting angle must be smaller than 0.405.
    • HTML全文
    • 参考文献(1)
  • ［1］陈伟, 李诗愈,成煜,等.保偏光纤技术进展及发展趋势［J］. 光通信研究,2003(6):54-57.
    CHEN Wei, LI Shi-yu, CHENG Yu, et al. The technology progress and developing trends of polarization maintaining optical fibers［J］. Study on Optical Communications, 2003(6):54-57. (in Chinese with an English abstract)
    ［2］胡庆,王敏琦,袁绥华.偏振光在保密通信中的应用研究［J］.半导体光电,2001,22(6):397-400.
    HU Qing, WANG Min-qi, YUAN Sui-hua. Application of polarized light in secret communication［J］. Semiconductor Optoelectronics, 2001,22(6):397-400. (in Chinese with an English abstract)
    ［3］李彦,张春熹,欧攀,等.光源偏振度对光纤陀螺零偏影响的研究［J］. 光学技术,2006,32(6):893-896.
    LI Yan, ZHANG Chun-xi, OU Pan, et al. Research on the influence of the source degree of polarization on the bias stability of interference fiber optical gyroscope［J］. Optical Technique, 2006,32(6):893-896. (in Chinese with an English abstract)
    ［4］石顺祥,张海兴,刘劲松.物理光学与应用光学［M］.西安:西安电子科技大学出版社,2000.
    SHI Shun-xiang, ZHANG Hai-xing, LIU Jin-song. Physical optics and applied optics［M］. Xi’an: Xidian University Press, 2000. (in Chinese)
    ［5］柳建春,高立民,李康,等.光纤陀螺消偏结构与偏振度关系的研究［J］. 光子学报, 2005,34(6):948-951.
    LIU Jian-chun, GAO Li-min, LI Kang, et al. Research on the relationship between depolarized structure of fiber optical gyros and degree of polarity［J］. Acta Photonica Sinica,2005,34(6):948-951. (in Chinese with an English abstract)
    ［6］马科斯·波恩, 埃米尔·沃尔夫. 光学原理［M］.第七版.杨葭荪,译. 北京:电子工业出版社,2006.
    BORN M, WOLF E. Principles of optics［M］. 7th ed.Translated by YANG Jia-sun. Beijing: Publi-shing House of Electronics Industry, 2006. (in Chinese)
    ［7］王淑敏.消偏光纤陀螺的偏振态研究［D］.杭州: 浙江大学,2003.
    WANG Shu-min. Depolarizer FOG study of the polarization states［D］. Hangzhou: Zhejiang University, 2003. (in Chinese)
    ［8］延凤平,姚毅,简水生.基于Lyot型光纤消偏器特性的研究［J］.光学学报,1996,16(6):848-852.
    YAN Feng-ping, YAO Yi, JIAN Shui-sheng. Characteristics of Lyot optical fiber depolarizer［J］. Acta Optica Sinica, 1996,16(6):848-852. (in Chinese with an English abstract)
    ［9］LEFEVRE H C.光纤陀螺仪［M］.张桂才, 王巍, 译.北京:国防工业出版社,2002.
    LEFEVRE H C. The fiber-optic gyroscope［M］. Translated by ZHANG Gui-cai, WANG Wei. Beijing: National Defense Industry Press,2002. (in Chinese)
