光子晶体光纤光栅谱特性的数值模拟研究

毕卫红; 王洋; 齐跃峰

光子晶体光纤光栅谱特性的数值模拟研究

1.
燕山大学信息科学与工程学院,河北秦皇岛066004;
2.
秦皇岛港股份有限公司技术中心,河北秦皇岛066000

详细信息

作者简介:
毕卫红(1960-)，女，河北卢龙人，教授，博导，主要从事光电传感领域和信号处理方向的研究工作。

中图分类号: TN253
计量
- 文章访问数: 2899
- HTML全文浏览量: 154
- PDF下载量: 743
出版历程
- 刊出日期: 2010-09-14

Numerical simulation of spectral transmission characteristics of photonic crystal fiber grating

1.
Department of Information Science and Engineering,Yanshan University,Qinhuangdao 066004,China;
2.
Centre for Information Technology,Qinhuangdao Port Company Limited,Qinhuangdao 066000,China

摘要

摘要: 应用多极法理论和传输矩阵法，对基于包层空气孔为正六边形对称结构的光子晶体光纤的布喇格光栅特性进行了计算和仿真。对比研究了常规单模光纤所成光栅与相同光栅周期的光子晶体光纤布喇格光栅反射谱之间的差异，重点研究了光子晶体光纤的结构参数变化(间隙孔半径、层数)与光子晶体光纤光栅的谐振峰变化规律。当光子晶体光纤的间隙孔半径增大时，光子晶体光纤光栅的谐振波长出现蓝移；当光子晶体光纤的间隙孔径不变、层数增加时，光子晶体光纤光栅的谐振波长出现红移。
- 光纤光学 /
- 光子晶体光纤光栅 /
- 多极法 /
- 耦合模理论 /
- 反射谱
Abstract: The mode field of a kind of photonic crystal fiber structure with hexagon symmetry hole cladding was analyzed by multipole method, and the effective refractive indexes of base mode at different wave lengths were obtained. The characteristics of this photonic crystal fiber grating were computed and simulated by coupled-mode method and transmission matrix method, and the difference between conventional fiber grating and photonic crystal fiber grating on their reflection spectrum was compared. The paper also analyzed the changes of photonic crystal fiber grating resonant wavelength with the structural change of photonic crystal fiber. Photonic crystal fiber grating has shorter resonant wavelength with increased radius of photonic crystal fiber pillars. Photonic crystal fiber grating has longer resonant wavelength with increased layers of photonic crystal fiber pillars but same radius.
- fiber optics /
- photonic crystal fiber grating /
- multipole method /
- couple mode theory /
- reflection spectrum

HTML全文

参考文献(1)

［1］ABEDINKS, MIYAZAKIT, KUBOTAF. Wave-length conversion of pseudorandom pulses at 10Gb/s by using soliton self-frequency shift in a photonic crystal fiber［J］. IEEE Photonics Technology Letters, 2004,16(4):1119-1121.
［2］SHARPINGJE, FIORENTINOM, KUMARP, et al. All-optical switching based on cross-phase modulation in microstructure fiber［J］. IEEE Photonics Technology Letters, 2002,14(1):77-79.
［3］RUSELLP. Photonic crystal fibers［J］. Science, 2003,299(10):358-362.
［4］DIEZ A, BIRKS T A,REEVES W H, et al. Excitation of cladding modes in photonic crystal fibers by flexural acoustic waves［J］. Optics Letters, 2000,25(9):1499-1501.
［5］SIAHLOAI, OXENLOWELK, BERGKS, et al. A high speed demultiplexer based on a nonlinear optical loop mirror with a photonic crystal fiber［J］. IEEE Photonics Technology Letters, 2003,15(8):1147-1149.
［6］WHITE T P, McPHEDRAN R C. Calculation of air-guided mode in photonic crystal fibers using the multipole method［J］. Optics Express,2001,9(13):721-732.
［7］KUHLMEY B T,WHITE T P,RENVERSEZ G,et al. Multipole method for microstructured optical fibers II: implementation and results［J］. Journal of the Optical Society of America B,2002,19(10):2331-2340.
［8］CAMPBELL S, McPHEDRAN R C, STERKE C M. Differential multipole method for microstru-ctured optical fibers［J］. Journal of the Optical Society of America B, 2004,21(11):1919-1928.
［9］ERDOGAN T. Fiber grating spectra［J］. IEEE Journal of Lightwave Technology,1997,15(8):1277-1294.
