Optical design for low-level-light color night vision systemand its image quality evaluation
-
摘要: 为了充分利用可见光和长波红外所蕴含的不同信息进行数据融合、彩色显示，分析了3种不同类型双波段光学系统及其成像性能，设计了全折射光学系统、折反射光学系统和离轴三反射双谱光学系统。采用不同的分光形式，反射可见光波段，透射长波红外波段，使3种不同类型光学系统的全视场角和相对孔径分别为5和1∶1.7；光学系统在可见光波段成像质量对应的空间频率50lp/mm处的MTF=0.60，在长波红外波段成像质量对应的空间频率15lp/mm处的MTF=0.30。对不同结构类型的系统特点进行分析和讨论，给出了各种像差曲线和光学传递函数曲线,为多波段彩色夜视设计了不同类型的光学系统。Abstract: In order to use visible and long wave infrared information for image fusion and color display, three dual-band imaging optical systems and theirs imaging performance were analyzed. All-refractive optical system, catadioptric optical system and off-axis three-reflection dual spectrum optical system were designed. A beam splitter was adopted to reflect visible and transmit LW infrared. Its full field of view and relative aperture are up to 5 and F/1.7, and MTF is higher than 0.60 at 50lp/mm in the visible region, higher than 0.30 at 18lp/mm in the LWIR region. The construction features of the lens are discussed, the aberration curves and MTF curves of the system are presented.
-
Keywords:
- night vision /
- optical system /
- low-level-light color /
- dual-band
-
-
［1］陶茜,郭宏,王岭雪,等. 一种双通道夜视图像彩色融合系统［J］.应用光学, 2004，25(5)：47-50.
TAO Qian, GUO Hong, WANG Ling-xue,et al. A dual-channel night vision color image fusion system［J］.Journal of Applied Optics, 2004，25(5)：47-50. (in Chinese with an English abstract)
［2］樊学武，马臻，陈荣利，等.红外双波段卡塞格林光学系统设计［J］.光子学报， 2003，32(4):463-465.
FAN Xue-wu, MA Zhen, CHEN Rong-li, et al. The design of Cassegrain optic system for double infrared wavebands［J］. Acta Photonica Sinica, 2003，32(4):463-465. (in Chinese with an English abstract)
［3］张亮，安源，金光. 大视场、长焦距离轴三反射镜光学系统的设计［J］.红外与激光工程.2007，36(2):278-280.
ZHANG Liang,AN Yuan,JIN Guang. Optical design of the uncoaxial three-mirror system withwide field of view and long focal length［J］. Infrared and Laser Engineering,2007,36(2):278-280. (in Chinese with an English abstract)
［4］张颖新，乔 凯，屈会鹏，等. 微光双谱彩色夜视系统研究［J］.光电技术应用.2006，21(5):24-27.
ZHANG Ying-xin,QIAO Kai,QU Hui-peng,et al. Research on low-light of dual-spectrum color night vision system［J］. Electro-Optic Technology Application,2006，21(5):24-27.(in Chinese with an English abstract)
［5］倪平平. 红外与微光图像融合夜视系统设计［D］.南京：南京理工大学，2006.
NI Ping-ping. Night vision system design of image fusion with low-light and thermal infrared［D］. Nangjing: Nangjing University of Science and Technology, 2006.(in Chinese)
［6］卜江萍.用于凝视式相机的大视场离轴三反光学系统研究［D］.北京：中国科学院，2006.
BU Jiang-ping. Study on wide field off-axis reflective sytem for fixation camera［D］. BeiJing:Chinese Academy of Sciences，2006.（in Chinese）
