聚合物材料并联双环型温度传感器的设计

陈伟

陈伟. 聚合物材料并联双环型温度传感器的设计[J]. 应用光学, 2010, 31(3): 495-498.
引用本文: 陈伟. 聚合物材料并联双环型温度传感器的设计[J]. 应用光学, 2010, 31(3): 495-498.
CHEN Wei. Design of polymer parallel double-ring temperature sensor[J]. Journal of Applied Optics, 2010, 31(3): 495-498.
Citation: CHEN Wei. Design of polymer parallel double-ring temperature sensor[J]. Journal of Applied Optics, 2010, 31(3): 495-498.

聚合物材料并联双环型温度传感器的设计

详细信息
    通讯作者:

    陈伟(1982-),男,江苏扬州人,硕士研究生,主要从事光无源器件的研究工作。

  • 中图分类号: TN252

Design of polymer parallel double-ring temperature sensor

  • 摘要: 利用聚合物材料折射率和温度变化之间的内在联系,设计了一种并联双环温度传感器系统,并数值模拟了以该模型为基础的聚合物材料并联双环型温度传感器。从输出的模拟波谱可以得到,随着温度的变化,输出光谱的谐振峰出现明显的位移,对于热光系数较大的聚合物材料,谐振峰的位移更加明显。温度升高1℃,谐振峰的位移为32nm。通过谐振峰的位移,可以计算出温度的变化,进一步提高测量温度的精确度。
    Abstract: A novel system of parallel double-ring temperature sensor is designed and numerical simulated, which is based on the relationship between the temperature and the refractive index of polymer. With the output of the simulation spectrum, the conclusion is achieved that the resonance peaks have distinct displacement as the temperature changes, and the higher thermo-optic coefficient of the polymer is, the more obvious resonance peaks shift. When the temperature increases by 1℃, the resonant peaks shift 32nm. The temperature changes can also be calculated with the resonant peak shift, which provide the feasibility to improve the measurement accuracy of temperature.
  • [1]REZZONICO D, GUARINO A, HERZOG C, et al.High-finesse laterally coupled organic-inorganic hybrid polymer micro-ring resonators for VLSI photonics[J]. IEEE Photon. Technol. Lett., 2006,18(7):865-867.
    [2]TAZAWA H,STEIER W H.Linearity of ring re-sonator-based electro-optic polymer modulator[J].Electron. Lett.,2005,41(23):55-56.
    [3]ZHOU Jun, PYAYT A, DALTON L R, et al. Photobleaching fabrication of microring resonator in a chromophore-containing polymer[J]. IEEE Photonics Technology Letters, 2006,18(21):2221-2223.
    [4]PYAYT A, ZHOU Jun, CHEN An-tao, et al.Electro-optic polymer microring resonators made by photobleaching[J].SPIE, 2007,6470:64700Y164700Y7 .
    [5]MA Chun-sheng, WANG Xian-yin, LI De-lu, et al. Characteristic analysis of series-cascaded microring resonator arrays[J]. Optics & Laser Technology, 2007,39(6):1183-1188.
    [6]张小康,廖常俊.硅树脂材料热光特性的测试与分析[J].光学学报,2005,25(5):629-632.
    ZHANG Xiao-kang ,LIAO Chang-jun.The test and analysis for thermo-optic effect of silicon resin[J].Acta Optica Sinica, 2005,25(5):629-632.(in Chinese with an English abstract)
    [7]柯尊淦,吴少平,郑丹.电磁波在负折射率材料填充3层平板波导中的传播特性[J].应用光学,2008,29(5):825-829.
    KE Zun-gan,WU Shao-ping,ZHENG Dan. Propagation characteristics of electromagnetic wave in slab waveguide filled with negative refraction index material[J].Journal of Applied Optics,2008,29(9):825-829. (in Chinese with an English abstract)
    [8]蒋艳,邱凤仙.有机聚合物BPDA-ODA-DR1的合成及热光性能的研究[J].光电子激光,2006,17(12):1492-1496.
    JIANG Yan, QIU Feng-xian, Synthesis and study of thermal-optical properties based on the organic polymer BPDA-ODA-DR1[J].Journal of Optoelectronics Laser, 2006,17(12):1492-1496. (in Chinese with an English abstract)
    (上接第494页)
    Appl. Phys. Lett.,2000,76(2):198-199.
    [25]CHEN S F,WANG C W.Influence of the hole injection layer on the luminescent performance of organic light-emitting diodes[J].Appl. Phys. Lett.,2004,85(5):765-767.
    [26]ADACHI C,BALDO M A,FOMEST S R.Ele-ctroluminescence mechanisms in organic light emitting devices employing a europium chelate doped in a wide energy gap bipolar conducting host[J].J. Appl. Phys.,2000,87(11):8049-8055.
    [27]MATSUSHIMA T, KINOSHITA Y, MURATA H. Formation of Ohmic hole injection by inserting an ultrathin layer of molybdenum trioxide between indium tin oxide and organic holetransporting layers[J].Appl. Phys. Lett.,2007,91(25):253504-253506.
