一种平板显示无缝拼接技术的研究

孟凡华; 黄永峰

一种平板显示无缝拼接技术的研究

孟凡华^,,
黄永峰

1.
广东威创视讯科技股份有限公司,广东广州510663

详细信息

通讯作者:
孟凡华(1960-)，江苏铜山人，高级工程师，主要从事大屏幕显示技术研究工作。

中图分类号: TN27
计量
- 文章访问数: 2404
- HTML全文浏览量: 133
- PDF下载量: 1037
- 被引次数: 0
出版历程
- 刊出日期: 2010-05-15

Seamless tiling technology based on FPD

MENG Fan-hua^,,
HUANG Yong-feng

1.
Vtron Technologies LTD,Guangzhou 510663,China

摘要

摘要: 针对平板显示技术最新进展和技术特点，提出利用光学移像技术实现平板显示屏无缝拼接显示的方法。采用隔行/隔列或分时显示技术，在平板显示屏邻近边框区域设置重叠显示区显示2幅图像，借用偏振光旋转装置与偏振反射膜，实现图像的分离。通过斜方棱镜将分离出的图像引导至显示器件边框位置覆盖边框，将原来36mm宽的拼接缝减小至3条不到0.5mm宽的棱镜拼接缝，实现了平板显示屏的无缝拼接。
- 平板显示 /
- 无缝拼接 /
- 光学移像
Abstract: Based on the latest development and technical characteristics of FPD technology, a method for producing seamless tiled FPD panels using optical image-shifting technology was put forward. Two image sections were displayed near the border of FPD panels by means of interlace frame display. The image sections were separated using polarizing rotation apparatus and polarizing beam splitter. The separated image section was moved by imageshifting prism to cover the border. The tiled seam width was reduced from 36 millimeters to three pieces of 0.5 millimeter wide prism seam. The seamless tiling of FPD panels was realized successfully with this technology.
- FPD /
- tiled display /
- image-shifting

HTML全文

参考文献(1)

［1］投影时代. 大型显示墙拼接器件——欧丽安等离子［EB/OL］.［2007-08-29］.http://yutong.group.china.alibaba.com/news/detail/v5000441-d100074 2981.html.
Projection Time. Large tiled display wallOrion PDP［EB/OL］.［2007-08-29］. http://yutong.group.china.alibaba.com/news/detail/v5000441-d10007 42981.html.(in Chinese)
［2］投影时代.液晶屏的显示原理及DID屏的特征［EB/OL］. ［2008-09-10］.http://www.pjtime.com/2008/9/15898943.shtml.
Projection Time. The principle of LCD and Characteristics of DID LCD［EB/OL］. ［2008-09-10］. http://www.pjtime.com/2008/9/1589 8943.shtml.(in Chinese)
［3］STARK B H. Visual display screen arrangement：US，0077544 A1［P］. 2006-04-13. http://www.freepatentsonline.com/y2006/0077544.html.
［4］王继平. 导光纤维显示屏：中国，94101872.5［P］. 1995-02-22.
WANG Ji-ping. Optical fiber display: China, 94101872.5［P］.1995-02-22.(in Chinese)
［5］李众庆.一种消除拼接显示屏间拼缝的方法及装置：中国，200410091097.8［P］. 2006-05-24.
LI Zhong-qing. Method and apparatus for seamless tiled display: China, 200410091097.8［P］. 2006-05-24.(in Chinese)
［6］孙刚，A.B.Davey，W.A.Crossland. 一种基于PL-LCD体系结构的新型图像拼接技术的研究［J］.现代显示，2004，43(3)：21-24.
Sun Gang，A.B.Davey，W.A.Crossland. Novel tiling research based on PL-LCD architecture［J］. Advanced Display, 2004,43(3):21-24.(in Chinese with an English abstract)
