一种FBG重构算法及其应用

李海兰; 张兴娇; 叶志清

一种FBG重构算法及其应用

1.
江西师范大学物理通信与电子学院,江西南昌330022

详细信息

通讯作者:
李海兰(1986-)，女，江西吉安人，硕士研究生，主要从事光纤光栅及其应用的研究工作。

中图分类号: TN253
计量
- 文章访问数: 2966
- HTML全文浏览量: 130
- PDF下载量: 1056
- 被引次数: 0
出版历程
- 刊出日期: 2010-05-15

New FBG synthesis algorithm and its application

1.
Institute of Physics and Communication &Electronics,Jiangxi Normal University,Nanchang 330022,China

摘要

摘要: 从耦合模理论和传输矩阵方法出发，介绍了一种设计复杂光纤光栅的有效的简单方法。该方法只考虑光栅内部的一级反射，发现滤波器的反射谱和FBG的耦合函数间存在近似的傅里叶变换关系，能简单快速地对弱反射光栅进行设计。该方法的有效性通过设计光纤通信系统中常用的两种色散补偿器得以体现：第一种色散补偿器的色散值在3dB带宽内恒为17ps/nm，另一种则为具有线性色散斜率的色散补偿器。数值仿真结果表明：此方法可以有效地从反射信息中提取光纤光栅参数，能够应用在利用光纤光栅反射特性的复杂滤波器的设计中。
- 光纤光学 /
- 重构算法 /
- FBG /
- 反射特性 /
- 色散补偿器
Abstract: The approach of inferring the grating profile from its reflection spectrum is referred to as fiber Bragg grating (FBG) synthesis algorithm. Synthesis of FBG is of great significance for the design of special FBG to have desired characteristics. A simple and efficient method based on the coupled-mode theory and transfer matrix method for the design of complex FBG was proposed. The method takes into account only the first reflection, exploiting the approximate Fourier transform relation that exists between the filter spectral response and the coupling function. Its low algorithmic complexity enables the fast synthesis of weak reflection FBG. The method is illustrated by designing two types of dispersion compensators for the applications of optical fiber communication systems, constant dispersion coefficient with 17ps/nm in its 3dB passband and linear dispersion slope coefficient compensators. Numerical simulation results show that the method is very effective for parameter reconstruction of fiber gratings according to desired reflectivity characteristics and can be applied in the design of complex filter based on the reflectivity characteristics of fiber gratings.
- fiber optics /
- synthesis algorithm /
- FBG /
- reflective characteristics /
- dispersion compensator

HTML全文

参考文献(1)

［1］RAO Y J. In-fiber Bragg grating sensors［J］. Mea-surement Science and Technology, 1997,8(355):1442-1462.
［2］OUELLETTE F, KRUG P A, STEPHENS T, et al. Broadband and WDM dispersion compensation using chirped sampled fiber Bragg gratings［J］. Electronics Letters, 1995, 31(11):899-901.
［3］CHENG H C, LO Y L. The synthesis of multiple parameters of arbitrary FBGs via a genetic algorithm and two thermally modulated intensity spectra［J］. Lightwave Technology, 2005,23(6):2158-2168.
［4］陈聪,周骏,龚沈光. 基于Kolmogoroff方法重构光纤光栅相位响应［J］.光电子激光,2004,15(2):160-164.
CHEN Cong, ZHOU Jun, GONG Shen-guang. Phase reconstruction of fiber gratings based on Kolmogoroff method［J］. Journal of Optoelectronics·Laser,2004,15(2):160-164. (in Chinese with an English abstract)
［5］DONG P, AZANA J, KIRK A G. Synthesis of fiber Bragg grating parameters from reflectivity by means of a simulated annealing algorithm［J］. Optics Communications, 2003,228(46):303-308.
［6］戴一堂.新型光纤布拉格光栅的研究与应用［D］. 北京: 清华大学,2006.
DAI Yi-tang. Research on the theory and application of novel fiber Bragg gratings［D］. Beijing: Tsinghua University, 2006. (in Chinese)
［7］YIN Yu-zhe, CHEN Xiang-fei, DAI Yi-tang, et al. A novel method for inverse fiber Bragg grating structure design［J］. Optics Communications, 2003,228(1-3):79-84.
［8］穆柯军,周晓军,任国荣,等.用遗传算法从时延特性重构光纤光栅参数［J］. 中国激光, 2007,34(5):688-693.
MU Ke-jun, ZHOU Xiao-jun, REN Guo-rong, et al. Reconstruction of parameters of fiber gratings from time-delay characteristics using the genatic algorithm［J］. Chinese Journal of Lasers, 2007,34(5):688-693. (in Chinese with an English abstract)
