Method for preprocessing mammography image based on CCD
-
摘要: 为提高由闪烁屏到CCD的光耦合效率，减小大相对孔径和近距离成像造成CCD图像严重失真，提出一种有效补偿图像失真的预处理方法。该方法根据物像共轭关系将物面划分为与图像传感器像素相对应的许多微小物元，应用蒙特卡罗方法模拟从每一物元发出的光在像面上形成的光分布，即点扩散函数。由所有物元的点扩散函数构成一个点扩散数组，数组的每一行对应一个物元的点扩散函数。基于该点扩散数组建立描述像元与物元关系的线性方程组，解线性方程组可得到接近实物的图像。用实际光学系统的计算结果验证了该方法的有效性。Abstract: The key to apply CCD to implement mammography is to improve the coupled efficiency of light from scintillation screen to CCD, and it is necessary that the image system has a large relative aperture and adopts close imaging, which makes the CCD image seriously distorted. This paper presents an efficient preprocessing method to compensate image distortion. According to the conjugate relation between the object and its image, the object plane was divided into many micro object elements that have one-to-one correspondence with the pixels of image sensor; Monte Carlo method was used to simulate the light distribution on image plane made by the light from each object element, namely point spread function. A point spread array was constructed from all point spread functions of all elements; each row of the array corresponds to the point spread of function an object element. A linear system of equations to describe the relation between all object elements and all image pixels was built on the basis of the point spread array, and a lifelike image was obtained by solving the linear system of equations. The calculation results for an actual optical system verified the validity of the method.
-
Keywords:
- mammography /
- CCD /
- Monte Carlo simulation /
- point spread function
-
-
［1］WETZEL K.Digital radiography: CCDs deserve an-other look［J］. Advanced Imaging, 2004,19(9):12-13.
［2］FISCHER U, HERMANN K P, BAUM F. Digital mammography: current state and future aspects［J］. European Radiology, 2006,16(1):38-44.
［3］KALLERGI M. Digital mammography: from theory to practice［J］. Cancer Control, 1998,5(1):72-79.
［4］TIPNIS S V, NAGARKAR V V, GAYSINSKIY V, et al. Large area CCD based imaging system for mammography［J］. Nuclear Science Symposium,1999,2:1043-1046.
［5］中华人民共和国卫生部政策法规司. 乳腺X射线摄影质量控制检测规范GBZ 186-2007［S］. 北京：人民卫生出版社，2008.
Policy and Regulations Department, Ministry of Health of the People’s Republic of China. Inspection standard on the quality control of mammography (GBZ 186-2007)［S］. Beijing: People’s Medical Publishing House, 2008.(in Chinese)
［6］EVANS D S, WORKMAN A, PAYNE M. A com-parison of the imaging properties of CCD-based devices used for small field digital mammography［J］. Phys. Med. Biol.,2002,47(1):117-135.
［7］WANG Li-hong, JACQUES S J, ZHANG Li-qiong. MCML-Monte Carlo modeling of light transport in multi-layered tissue［J］. Computer Methods and Programs in Biomedicine, 1995,47(2):131-146.
［8］福建光学技术研究所，国营红星电机厂.光学镜头手册(第9册)［M］.北京:国防工业出版社，1987.
Fujian Institute of Optical Technology, Nationalized Red-start Electrical-motor Factory. Optical lens manual (9th book)［M］. Beijing: National Defence Industry Press，1987.(in Chinese)
