Optical axis detection instrument for shipborne photoelectrical devices
-
摘要: 为了在实验外场和装舰现场克服舰船光电装备多传感器光轴一致性标校中由于环境限制、舰船摇晃等造成的操作困难，提出一种舰船光轴检测仪方案。通过共光路和光谱转换技术实现激光光轴与可见光轴的耦合，激光像斑在可见光通道输出成像视频，依据像斑中心与装备十字刻线位置关系判断激光与可见光光轴的一致性。应用CAD/CAE技术对光轴检测仪的关键器件光轴耦合单元进行仿真分析，得到-10℃～+40℃温度范围内的反射镜面平行性误差分别为13.576332和16.397421；整机环境实验结果表明，光轴检测仪本身精度误差小于20，满足光电装备光轴的一致性要求。Abstract: A design scheme of the optical axis detection instrument for shipborne optoelectronic devices is proposed to overcome the difficulties resulted from environmental limitation and ship stagger during the process of photoelectrical multi-sensors boresight parallelism adjustment in the outer testing locate and loading ship. The coupling of laser and visible-light boresights is realized with common-path and spectrum conversion technologies. The instrument's key part-boresight coupling unit is simulated and analyzed by CAD/CAE. The parallelism errors of 13.576332 and 16.397421 between two reflectors were obtained in the range of -10℃～+40℃. The result of environmental test indicates that the accuracy error of the instrument is less than 20 and meets the design index.
-
-
［1］苏美开.光轴偏差对激光测距机测距能力的影响［J］.激光杂志，2001，22(3)：39-42.
SU Mei-kai.Effect on the range ability of laser finder by optics axis error［J］.Laser Journal，2001，22(3)：39-42.(in Chinese with an English abstract)
［2］黄静，刘朝晖，折文集,等.室内多波段光轴一致性测试系统的设计［J］.应用光学，2007,28(5)：663-666.
HUANG Jing，LIU Chao-hui，ZHE Wen-ji,et al.Design of lab test system for boresight of multi-channel optical axes［J］.Journal of Applied Optics，2007,28(5)：663-666.(in Chinese with an English abstract)
［3］许照东,安世甫,刘欣.多传感器光电系统视轴一致性测试方法研究［J］.光子学报，2007,36(11)：2121-2123.
XU Zhao-dong,AN Shi-pu,LIU Xin.Methods for testing sight-axis consistency of multi-sensor photoelectric system［J］.Acta Photonica Sinica，2007,36(11)：2121-2123.(in Chinese with an English abstract)
［4］程刚，陈方斌，袁孝民,等.基于Ansys的光学器件热变形仿真与分析［J］.应用光学，2008,29(5)：697-700.
CHENG Gang，CHEN Fang-bin,YUAN Xiao-min,et al.Thermal deformation simulation and analysis Ansys-based for optical parts［J］.Journal of Applied Optics，2008,29(5)：697-700.(in Chinese with an English abstract)
