Design of mobile phone camera lens based on ZEMAX
-
摘要: 在光学工程软件ZEMAX的辅助下，配套采用像元大小为1.75m的CMOS图像传感器，设计了一款500万像素的手机镜头，镜头视场角60，F/#2.8，半像高2.87mm,镜头总长为6mm，镜头为3P1G结构，第1、3、4片镜片采用非球面塑料，第2片镜片采用球面透镜。各个视场的横向像差均小于20m，均方根半径(RMS Radius)都在艾利斑之内，在1/2奈奎斯特频率处绝大部分视场MTF值都大于0.6，可以获得优质的成像效果。Abstract: By the aid of optical engineering software ZEMAX, a five mega pixel mobile phone camera lens matched with one CMOS image sensor of 1.75m pixel size was designed, whose FOV is 60, F number is 2.8, half image height is 2.87mm, total length is 6mm and structure is 3P1G. Aspheric plastic was used for the first, third and fourth lenses. Sphere glass was used for the second lens. Transverse aberration of all the FOVs is less than 20m, RMS radius are less than Airy disk, and MTFs of most FOVs at half the Nyquist frequency (285lp/mm)of CMOS are greater than 0.6. This lens assembly has an excellent imaging performance.
-
Keywords:
- mobile phone lens /
- ZEMAX /
- 5 mega-pixel camera /
- MTF /
- aberration correction
-
-
［1］萧萧.三星推出全球首款1200万像素触屏手机Pixon 12［OL］. http:∥news.mydrivers.com/1/136/136067.htm.2009-09-16.
XIAO Xiao. Samsung releasing the first wordwide 1200 hundred-pixel phone Pixon 12 with touch screen［OL］. http:∥news.mydrivers. com/1/136/136067.htm.2009-09-16.(in Chinese)
［2］李文静.500万像素手机镜头的光学设计［J］.激光与光电子学进展，2009,46(1)：56-59.
LI Wen-jing. Optical design of 5-mega pixel mobile phone lens［J］. Laser & Optoe Ectronics Progress,2009,46(1)：56-59. (in Chinese with an English abstract)
［3］萧泽新.工程光学设计［M］. 北京：电子工业出版社, 2002.
XIAO Ze-xin. Engineering optical design［M］. Beijing: Publishing House of Electronics Industry, 2002. (in Chinese)
［4］张前平，邓冈锋，曾阳素.照相镜头设计中非球面的应用［J］.邵阳学院学报，2008,5(1)：70-74.
ZHANG Qian-ping, DENG Gang-feng, ZENG Yang-su. Application of asphere in the design of the camera lens［J］.Journal of Shaoyang University,2008,5(1):70-74. (in Chinese with an English abstract)
［5］刘茂超，张雷，刘沛沛，等.300万像素手机镜头设计［J］.应用光学，2008，29(6)：944-948.
LIU Mao-chao, ZHANG Lei, LIU Pei-pei, et al. Design of lens for 3 mega-pixel mobile phone camera［J］. Journal of Applied 0ptics, 2008，29(6)：944-948. (in Chinese with an English abstract)
［6］李晓彤, 岑兆丰. 几何光学·像差·光学设计［M］. 浙江：浙江大学出版社, 2007.
LI Xiao-tong, CEN Zhao-feng. Geometrical optics·aberrations and optical design［M］.Zhejiang:Zhejiang University Press, 2007. (in Chinese)
