Design and fabrication of beam splitters ininfrared detection device
-
摘要: 在红外探测装置中，光谱分光镜是用来把3m～5m和8m～12m 2个波段的光谱分开的零件。介绍了一种在通用镀膜机上制备光谱分光镜的新工艺。在该膜系的设计过程中，把Willey公式引入到对其平均透过率最高值进行估算的过程中，同时针对国产镀膜机控制精度不高的特点，尽量使用规整膜层进行设计。为了进一步提高8m～12m波段的透过率，在膜系的最外侧引进了一层自行配制的低折射率氟化物材料，制备出了符合技术指标的红外光谱分光镜。Abstract: Beam splitters for infrared spectrum are used to split the band of 3m to 5m and 8m to 12m in infrared detection devices. A new method of designing and fabricating infrared beam splitters with a conventional coater is introduced. In the course of design, we estimated the highest value of average transmission with the formula of Willey, which was used in the design of the beam splitters. Considering the low precision of the available coater, we attempted to design coating with quarterfilms. For improving transmission from 8m to 12m, a self-prepared low refractive index material was deposited on the coating. The beam splitters for infrared spectrum fabricated met the required technical specifications.
-
-
［1］唐晋发,顾培夫,刘旭,等. 现代光学薄膜技术［M］. 杭州:浙江大学出版社,2006.
TANG Jin-fa, GU Pei-fu, LIU Xu, et al. Modern optical thin film technology［M］. Hangzhou: Zhejiang University Press, 2006. (in Chinese)
［2］麦克劳德.光学薄膜技术［M］.周九林,尹树百,译.北京:国防工业出版社,1974.
MACLEOD A. Optical coatings technology［M］. Translated by ZHOU Jiu-lin, YIN Shu-bai. Beijing: National Defence Industry Press, 1974. (in Chinese)
［3］潘永强,朱昌.硒化锌基底8μm～12μm高性能增透膜的研究［J］.红外与激光工程,2005,34(4):394-396.
PAN Yong-qiang, ZHU Chang. High performance infrared antireflection films on ZnSe substrate for 8μm～12μm［J］. Infrared and Laser Engineering,2005,34(4):394-396. (in Chinese with an English abstract)
［4］赵兴梅,师建涛,郭鸿香.短波通滤光片膜系设计［J］.应用光学,2006,27(5):415-418.
ZHAO Xing-mei,SHI Jian-tao,GUO Hong-xiang.Film system design for short-wavelength pass filter［J］.Journal of Applied Optics,2006,27(5):415-418. (in Chinese with an English abstract)
