Influence of different Cs-to-O current ratios on sensitivity and stability of activating GaAs photocathodes
-
摘要: 鉴于不同的铯氧电流激活GaAs光阴极时会对激活过程和结果产生不同的影响，从而影响GaAs光阴极的灵敏度和稳定性。以固定铯源电流，改变氧源电流的方式获取不同铯、氧电流比，激活同类GaAs光阴极，得到了3组实验数据。对数据进行分析，结果表明：同类光阴极在相同条件下激活时，光电流出现的时间几乎一致，并且首个光电流峰值也非常接近；激活时ICs/IO=1.07是目前获得高灵敏度、高稳定性GaAs光阴极的最佳电流比，而ICs/IO=1.10时光阴极灵敏度低但稳定性好，ICs/IO=1.03时光阴极灵敏度高但稳定性差。双偶极层模型认为Cs、O激活后GaAs表面形成了稳定均匀的GaAs-O-Cs:Cs-O-Cs双偶极层，并达到了负电子亲和势，这一点与实验数据的分析结果相一致。该方法可用于提高GaAs光阴极灵敏度和稳定性。
-
关键词:
- 光阴极灵敏度 /
- 光阴极稳定性 /
- Cs-to-O电流比 /
- 光电流
Abstract: Since the different cesium and oxygen currents during the activating process may cause the undefined influence on the sensitivity and stability of GaAs photocathodes, the long-term research was implemented. For the purpose of increasing sensitivity and stability of GaAs photocathodes, three different cesium-to-oxygen current ratios (fixed cesium current and alterable oxygen current) were used to activate the similar GaAs photocathodes, and three sets of experimental results were obtained. The analysis results of experimental data show that the appearance times of photocurrent are almost identical and the peak values of the first photocurrent are very close; ICs/IO=1.07 is the optimum current ratio for high sensitivity and high stability, ICs/IO=1.10 is for low sensitivity but high stability, and ICs/IO=1.03 is for high sensitivity but low stability. Based on the double-dipole model, the stable and uniform double-dipole layers of GaAs-O-Cs:Cs-O-Cs are formed and negative electron affinity is achieved on GaAs surface activated by cesium and oxygen, which cnsists with the analysis results for theexperimental data. The effective technical method can be used to improve the sensitivity and stability of GaAs photocathodes. -
-
［1］向世明，倪国强. 光电子成像器件原理［M］. 北京：国防工业出版社，1999.
XIANG Shi-ming, NI Guo-qiang. The principle of photoelectronic imaging devices［M］. Beijing: National Defence Press, 1999. (in Chinese)
［2］冯驰，向世明，高景华，等. GaAs与玻璃窗口热压粘接工艺设计［J］. 真空电子技术，2006，6：40-41.
FENG Chi, XIANG Shi-ming, GAO Jing-hua, et al. Technology design of thermal-compression bonding GaAs with glass window［J］. Vacuum Electronics, 2006,6:40-41. (in Chinese with an English abstract)
［3］ELBAHNASAWY R F,MCINERNEY J G,HUG-HES G.Oxidation and carbon contamination in GaAs(100) wet treatments［J］. Materialstoday, 1999,573:145-150.
［4］ANDREEV V E, BAKIN V V, LITVINOV A N, et al. Atomic and electronic engineering of P-GaAs-(Cs, O) vacuum interface［J］. AIP,2001,570:901-907.
［5］ELAMRAWI K A,ELSAYED-ALI H E.Prepa-ration and operation of hydrogen cleaned GaAs(100) negative electron affinity photocathodes［J］. J. Vac. Sci.Technol.A,1999,17(3):823-831.
［6］MORE′ S D,TANAKA S,TANAKA S I,et al. Cesiumoxide-GaAs interface and layer thickness in NEA surface formation［J］. SPIN,2000,570:916-919.
［7］向世明.微光像增强器光阴极灵敏度理论极限问题研究［J］.应用光学，2008，29(1)：48-51.
XIANG Shi-ming. Theoretical limit for photoca-thode sensitivity of image intensifier［J］. Journal of Applied Optics, 2008,29(1):48-51. (in Chinese with an English abstract)
［8］承欢，江剑平. 阴极电子学［M］.陕西：西北电讯工程学院出版社，1986.
CHENG Huan, JIANG Jian-ping. Photocathode electronics［M］. Shaanxi: Press of Northwest Institute of Telecommunication Engineering, 1986. (in Chinese)
［9］杜晓晴，常本康，宗志园，等. NEA光电阴极的表面模型［J］. 红外技术，2003，25(1)：68-71.
DU Xiao-qing, CHANG Ben-kang, ZONG Zhi-yuan, et al. Surface models for NEA photocathode［J］. Infrared Technology, 2003,25(1):68-71. (in Chinese with an English abstract)
