Optimal design of 3-D superresolution pupil filter
-
摘要: 利用matlab优化工具箱，采用非线性规划，对三区振幅型（透过率为101）和三区位相型（相位角为0）光瞳滤波器进行三维超分辨优化设计，建立了优化模型，经计算机多次迭代运算，改变斯特尔比s值，给出了优化结果。结果显示：所设计的滤波器较好地实现了横向和轴向三维超分辨，且轴向超分辨能力优于横向；相同斯特尔比下，位相型三维超分辨能力优于振幅型，并且这两种滤波器结构简单，容易实现。Abstract: Three-zone amplitude-type superresolution pupil filters (1-0-1) and three-zone phase-type superresolution pupil filters (-0-) are designed with Matlab optimization toolbox and non-linear programming. The optimal model is established and some examples of optimization are given. The optimization results show the both filters have preferable 3-D superresolution characteristics, the axial resolution is better than transverse resolution, and the phase-type resolution is better than amplitude-type resolution at the same Strehl ratio. The structures of the both filters are simple and easy to be implemented.
-
Keywords:
- optical measurement /
- pupil filter /
- 3-D superresolution /
- non-linear programming
-
-
［1］BORN M, WOLF E. Principles of optics［M］. London: Cambridge University Press,1999:484-492.
［2］SHEPPARD C J R, HEGEDUS Z S. Axial behavior of pupil-plane filters［J］. J.Opt.Soc.Am.A, 1988,5(5):643-647.
［3］MANUEL M C,PEDRO A.Three dimensional sup-errsolution by annular binary filters［J］. Optics Communications,1999,165:267-278.
［4］丁洪萍，李庆辉，邹文艺．三区振幅型超分辨光瞳滤波器的设计［J］.光学学报，2004,24(9)：1177-1180.
DENG HONG-ping,LI Qing-hui,ZOU Wen-yi.Design of 3-zone amplitude-type superresolution pupil filters［J］. Acta Optica Sinica, 2004,24(9):1177-1180. (in Chinese with an English abstract)
［5］邓小强，王桂英，徐至展.三维超分辨光瞳滤波器［J］.中国激光，2001,28(5)：461-462.
DENG Xiao-qiang,WANG Gui-ying,XU Zhi-zhan.3-D superresolution pupil filter［J］. Chinese Journal of Lasers, 2001,28(5)：461-462.(in Chinese with an English abstract)
［6］GU Min, SHEPPARD C J R. Confocal fluorescent microscopy with a finite sized circular detector［J］. J.Opt.Soc.Am.A,1992,9(1):151-155.
