头戴显示器中自由曲面棱镜的设计

陈云亮; 李铁才; 邱祥辉

头戴显示器中自由曲面棱镜的设计

陈云亮^1,2, ,,
李铁才^1,2,
邱祥辉¹

1.
深圳航天科技创新研究院广东深圳,518057;
2.
哈尔滨工业大学深圳研究院,广东深圳518057

详细信息

通讯作者:
陈云亮（1977-），男，四川人，博士，主要从事头戴显示器光学系统设计。

中图分类号: TN873.8；TH703
计量
- 文章访问数: 4124
- HTML全文浏览量: 169
- PDF下载量: 1687
出版历程
- 刊出日期: 2009-07-09

Design of free-form-surface prism in head mounted display

1.
China Shenzhen Academy of Aerospace Technology,Shenzhen 518057,China;
2.
Harbin Institute of Technology,Shenzhen 518057,China

摘要

摘要: 由自由曲面棱镜光学系统所组成的头戴显示器具有体积小、像质高和视场大等优点。利用矢量像差理论傍轴近似结果对具有倾斜曲面的光学系统进行初始结构设计,根据这种方法，以KOPIN公司生产的VGA芯片为例，对头戴显示器中自由曲面光学系统进行设计，将确定的初始结构参数输入光学设计软件Zemax进行优化设计。设计结果验证了确定初始结构方法的可行性，表明头戴显示器中自由曲面棱镜的设计方法可应用于具有倾斜曲面的光学系统设计。
- 非共轴光学系统 /
- 自由曲面 /
- 光学系统设计 /
- 矢量像差
Abstract: The head mounted display (HMD) with a free-form-surface (FFS) prism owns merits of small volume, good image quality and wide FOV. The initialization structure of optical system with tilted surfaces was designed according to the parixial vector aberration theory. A FFS optical system for a practical HMD was designed by entering the initial structure paramiters to the Zemax software to optimize the designed results. The result verifies the feasibility of this method, and indicates that the method to design the FFS prism in HMD can be applied to the design of other optical system with titled suface.
- uncoaxial optical system /
- free form surface /
- optical system design /
- vector aberration

HTML全文

参考文献(1)

［1］ROLLAND J P. Wide angle off axis see through head mounted display［J］. Opt. Eng.,2000,39(7):1760-1767.
［2］FERRIN F J. An update on optical systems for military head mounted displays［J］.SPIE,1999,3689:178.
［3］王肇圻, 赵顺龙. 高清晰低畸变轻小型投影式头盔物镜设计［J］. 红外与激光工程,2006,35(5):505-522.
WANG Zhao-qi, ZHAO Shun-long. Design of objective lens for a compact head-mounted projective display with high definition and low distortion［J］. Infrared and Laser Engineering,2006,35(5):505-522.(in Chinese with an English abstract)
［4］FERGASON J. Optical system for head mounted display using retro-reflector and method of display an image:US, 5625572［P］. 1997-04-15.
［5］FISCHER R E, NEWELL M P. Head mounted display viewing optics with improved optical performance：US，6349004［P］. 2000-7-13.
［6］常军,翁志成,姜会林,等. 用于空间的三反射镜光学系统设计［J］. 光学学报, 2003,23(2):216-219.
CHANG Jun, WENG Zhi-cheng, JIANG Hui-ling. Design on three-reflective-mirror system used in space［J］. Acta Optica Sinica,2003,23(2):216-219.(in Chinese with an English abstract)
［7］潘君骅, 李新南. 偏轴两镜系统的设计［J］.光学学报,1994,14(8):867-871.
PAN Jun-hua, LI Xin-nan. Design of a tilted two-mirror optical system［J］. Acta Optica Sinica,1994,14(8):867-871. (in Chinese with an English abstract)
［8］杨新军,王肇圻, 母国光,等.偏心和倾斜光学系统的像差特性［J］. 光子学报, 2005,34(11):1658-1662.
YANG Xin-jun, WANG Zhao-qi, MU Guo-guang,et al. Aberration properties of the decentered and tilted optical systems［J］. Acta Photonica Sinica, 2005,34(11):1658-1662. (in Chinese with an English abstract)
［9］THOMPSON K. A graphic approach to the analysis of perturbed optical systems［J］. SPIE,1980,237:127-134.
［10］THOMPSON K. Aberration fields in tilted and decentered optical systems［D］.US:Optical Sciences Center of University of Arizona,1980.
［11］THOMPSON K. Practical methods for the optical design of systems without symmetry［J］.SPIE,1996,2774:2-7.
［12］ROGERS J R. Vector aberration theory and the design of offaxis systems［J］. SPIE,1985,554:76-81.
［13］ROGERS J R. Techniques and tools for obtaining symmetrical performance from tilted 2 component systems［J］. Opt. Eng.,2000,39(7):1776-1787.
［14］ROGERS J R. Design techniques for systems con-taining tilted components［J］. SPIE,1999,3737:286-300.
［15］FIGOSKI J W. Aberration characteristics of non-symmetric systems［J］. SPIE,1985,554:104-111.
