Ultrasonic infrared technology for checking inner wall of metal pipeline
-
摘要: 为提高管道的运送效率，及时检测排除管道内壁的缺陷非常重要。提出利用超声红外无损检测方法对管道内部进行检测。超声主动热激励试件，高频红外热像仪记录试件表面温度变化，结合了超声摩擦生热和红外热成像的优点。对壁厚约为3.3mm检测难度较大的金属管内壁缺陷进行了检测。通过对采集数据和热图的处理分析，准确快速地确定缺陷所在的位置。实物对比分析表明：超声热激励红外无损检测技术可以对金属管道内壁缺陷进行准确检测定位。Abstract: Defect detection and elimination inside the wall of metal pipeline is very important for efficient transportation. The ultrasonic infrared thermal wave nondestructive test technology was employed to detect defects in metal pipeline. It adopted ultrasonic as a heat source to excite the sample and a high frequency infrared camera as a detector to capture the surface temperature, which combined the advantages of ultrasonic heating and infrared thermal technology. The pipeline with wall thickness of 3.33mm was inspected by this technology. By analyzing the temperature signal and typical time thermograph, the effective flaw information was obtained. Experiment conclusively indicates that the position of the defects on the inner wall can be accurately detected by the ultrasonic infrared nondestructive test technology.
-
Keywords:
- metal pipeline /
- nondestructive test /
- ultrasonic heating /
- infrared test /
- inner wall defect
-
-
［1］李晓刚，付冬梅. 红外热像检测与诊断技术［M］.北京：中国电力出版社，2006.
LI Xiao-gang, FU Dong-mei. Infrared thermal-graphic detective and diagnostics technology［M］. Beijing：China Electric Power Press，2006. （in Chinese）
［2］DING You-fu，SHEN Jing-ling，ZHANG Cun-lin.Analysis of infrared thermal wave nondestructive testing on flat bottom hole sample by the finite element method［C］∥ Shanghai：IEEE Infrared Millimeter Waves and 14th International Conference on Teraherz Electronics, 2006.
［3］FAVRO L D，XIAOYAN H, ZHONG O, et al. Th-omas sonic IR imaging of cracks and delaminations［J］. Analytical Sciences,2001,17：451-453.
［4］PEREZ I，DAVIS W R. Optimizing the thermosonics signal［J］. Review of Progress in QNDE, 2003,22(1):505-512.
［5］ZWESCHPER T, DILLENZ A, RIEGERT G. Ul-trasound excited thermography using frequency modulated elastic waves［J］. Insight-NonDestructive Testing and Condition Monitoring, 2003,45(3):178-182.
［6］陈大鹏，李晓丽，李艳红.超声红外热像技术检测激光焊缝质量［J］.无损检测，2008，30（10）：747-749.
CHEN Da-peng，LI Xiao-li，LI Yan-hong. Ultrasonic infrared thermography tests the quality of laser welded seams［J］. Nondestructive Testing, 2008，30（10）：747-749.(in Chinese with an English abstract)
