聚合物电光调制器中M-Z波导TM模分析

廖进昆; 刘永智; 廖翊韬; 甘小勇; 陆荣国

聚合物电光调制器中M-Z波导TM模分析

1.
电子科技大学光电信息学院,成都610054
2.
四川大学电气信息学院通信工程系,成都610065

详细信息

通讯作者:
廖进昆

计量
- 文章访问数: 3601
- HTML全文浏览量: 114
- PDF下载量: 1050
出版历程
- 刊出日期: 2006-03-09

TM mode analysis of Mach-Zenhder waveguidein electro-optical polymer modulators

1.
School of Optoelectronic Information,UESTC,Chengdu 610054,China;
2.
School of Electrical Information,Sichuan University,Chengdu 610065,China

More Information

Corresponding author:
LIAO Jinkun

摘要

摘要: M-Z光波导是聚合物电光调制器的重要结构单元。利用有效折射率法计算聚合物脊形波导的横向折射率分布，将三维光波场传播简化为二维传播。从导模满足的标量波动方程出发，结合透明边界条件，采用Crank-Nicholson差分格式，得出有限差分束传播法的基本计算格式。通过对MZ型波导结构中TM模的传播及损耗特性进行理论分析，系统地研究了脊宽、分支角等结构参数对损耗的影响。研究表明，有效折射率法与二维有限差分束传播法的结合可以较好地解决脊形MZ波导的设计问题。该方法具有精度高、计算量小及效率高等优点，为聚合物电光调制器的制备提供了理论依据。
- 电光聚合物 /
- Mach-Zenhder波导 /
- TM模 /
- 有限差分束传播法 /
- 有效折射率法
Abstract: Mach-Zehnder optical waveguide is an important component unit in electrooptic polymer modulators. By using effective index method (EIM) to calculate the transverse refractive index distribution of polymeric ridge waveguide, 3D light wave field propagation is successfully simplified into 2D propagation. Proceeding from the scalar wave equation observed by the guided modes, the basic computing scheme of the finite difference beam propagation method is obtained by utilizing the transparent boundary condition (TBC) and the CrankNicholson difference scheme. The effect of structure parameters such as ridge width and branch angle on the loss was theoretically studied with the support of the theoretical analysis of the TM mode light wave propagation and loss characteristics in the MZ waveguide structure. The combinational approach of EIM and 2DBPM demonstrates that the design of MZ waveguide can be made effectively by evaluating the influence of the structural parameters on the loss characteristics. The approach has high precision, small calculation complexity and high efficiency, and it provides a theoretical basis for the fabrication of electrooptical polymer modulators.
- electro-optical polymer /
- Mach-Zehnder waveguide /
- TM mode /
- FDBMP /
- effective index method
