油管位置光电检测技术的研究

Research on Photoelectric Measurement of the Vitta’s Position

1.
Dept of Measuring &Control Engineering Nanchang Institute of Aeronautical Technology,Nanchang 330034,China;
2.
Dept of Optoelectronics,Huazhong University of Science and Technology,Wuhan430074,China

摘要: 本文提出了一种测量汽车油管位置的方法。该方法采用平行光投影的光学系统，以高分辨率面阵CCD成像，通过数字信号处理(DSP)系统进行图像采集与处理，处理速度快，可以实现实时处理。在图像处理中，采用合适的边缘检测方法，提高了测量精度。数据处理中采用了最小二乘法拟合曲线，可以精确的拟合出油管像的曲线。与理论曲线相比较，就可以有效地测量油管的位置。
- 曲线拟合 /
- 图像处理 /
- 测量
Abstract: A method to measure the vitta’s position is given in this paper.The method takes use of collimated beam projection optics and highresolution CCD to obtain images. The image acquisition, image processing are all resolved by digital signal processing(DSP) system. The processing velocity is so fast as to realize the realtime measurement. In image processing, a suitable edge detection method is used to improve the measurement accuracy. Least square method is used to fit the curves of the vitta’s position images in the data processing.
- curve fitting /
- image processing /
- measurement
