头盔瞄准具瞄准线参数解算方法的研究

详细信息

Resolving method of bore-sighting parameters for helmet-mounted sight

摘要: 结合双目机器视觉测量技术和CCD测量的原理，给出一种头盔瞄准线参数测量新方法，对可能存在的误差源进行分析，并提出解决方法。双目机器视觉测量方法在头盔瞄准具瞄准线测量数学模型的基础上，应用机器视觉方法对头盔上的特征点进行重建，获取特征点的坐标进而解算瞄准线的参数。双目机器视觉测量系统结构简单，测量精度能满足头盔瞄准具瞄准线参数解算的精度要求。
- 瞄准线 /
- 双目机器视觉 /
- 坐标测量
Abstract: In combination with the measurement technology of the stereo machine vision and the measurement principle of CCD, a new method to measure the sighting line parameters of the helmet-mounted sight is presented, the possible error source is analyzed, and the solution is proposed. Based on the mathematical model of bore-sighting measurement for helmet-mounted sight, the characteristic points on the helmet were constructed by means of machine vision to acquire the characteristic point coordinate, and then resolve the parameters of the boresighting. The structure of the system is simple. The measuring accuracy can satisfy the accuracy requirement of resolving the bore-sighting parameters for the helmet-mounted sight.
- sight line /
- stereo machine vision /
- coordinate survey
