显微镜景深拓展技术研究

张平, 吴嘉敏, 林靖宇, 刘烨斌

张平, 吴嘉敏, 林靖宇, 刘烨斌. 显微镜景深拓展技术研究[J]. 应用光学, 2014, 35(6): 1075-1082.
引用本文: 张平, 吴嘉敏, 林靖宇, 刘烨斌. 显微镜景深拓展技术研究[J]. 应用光学, 2014, 35(6): 1075-1082.
shu
Zhang Ping, Wu Jia-min, Lin Jing-yu, Liu Ye-bin. Extended depth of field in microscopy[J]. Journal of Applied Optics, 2014, 35(6): 1075-1082.
Citation: Zhang Ping, Wu Jia-min, Lin Jing-yu, Liu Ye-bin. Extended depth of field in microscopy[J]. Journal of Applied Optics, 2014, 35(6): 1075-1082.
shu

显微镜景深拓展技术研究

  • 1.

    清华大学 自动化系,北京 100084;

  • 2.

    江苏北方湖光光电有限公司,江苏 无锡 214035

基金项目:

国家自然科学基金委国际合作项目“计算摄像学中的新理论及新方法”（61120106003）

详细信息
    通讯作者:

    张平（1979-），男，江苏张家港人，博士，高工，主要从事光电系统研究工作。 Email:zhangping_wuxi@163.com

  • 中图分类号: TN29;TH742

Extended depth of field in microscopy

  • 1.

    Department of Automation ,Tsinghua University,Beijing 100084,China;

  • 2.

    Jiangsu North Huguang Optics &Electronics Co. Ltd., Wuxi 214035,China

摘要

    摘要
  • 摘要: 随着生命科学需求的日益迫切，显微镜的景深拓展成为显微领域的一个重要发展方向，为了更好地了解、研究显微景深问题，对景深拓展技术进行研究与总结。以显微景深的大幅提升为出发点，就光学切片扫描、空间光调制、波前编码及光场显微4个方面进行了全面的综合性论述。对这些技术的原理、方式及拓展水平进行了阐述，并就其技术缺陷、发展方向进行了归纳总结。随着技术水平的提高，显微景深较传统显微镜可提高1~2个数量级。
    Abstract: Due to the urgent needs in life sciences, the extended depth of field (EDOF) in microscopy is becoming a focus. In order to study the microscopy depth of filed, the EDOF was studied and summarized. Based on the dramatic enhancement of EDOF, the optical scanning, spatial light modulation, wavefront coding and light filed microscopy were introduced and compared synthetically. Their theory, method and capacities for EDOF were summarized, and the technology defect and future development were analyzed. With the enhancement of technologies, the depth of filed in microscopy can be enhanced about 1 or 2 orders of magnitude compared with traditional microscopy.
