Diamond turning compensation techniques of diffractive optical elements
-
摘要: 超精密单点金刚石车削加工是高精度衍射光学元件制造的重要方法，但是以往的加工方法是直接一次车削加工成型，无法实现具有加工-检测-补偿加工-检测的闭环控制特点的超精密加工，从而导致零件精度较低。针对这种加工技术的缺陷，通过研究衍射光学元件金刚石车削过程和面形状误差补偿，对表面轮廓仪实际测量的轮廓数据进行处理，计算出实际车削曲线与理想曲线之间的法向残余误差，以此获得新的金刚石车削加工轨迹，实现衍射光学元件的超精密闭环控制加工。利用单点金刚石车床对口径78的衍射光学元件进行补偿加工试验，最终使其PV值由10.4 m经过一次补偿加工后降为4.3 m。Abstract: The ultra-precision diamond turning is a significant way to manufacture high- precision diffractive optical elements (DOE); however, this way is unable to achieve compensation machine currently that results in lower machining accuracy. Based on the study on the process of diamond turning and the compensation of surface shape error, and on the analysis of actual measurement data by the surface profile, the normal residual error was calculated between the actual turning curve and the ideal curve to get new machining trace of diamond turning in this paper. The compensation test on DOE of 78 with the diamond turning machine was done, and finally the value of peak value (PV) converges rapidly from 10.4 m to 4.3 m.
-
[1]Li Yingxuan.The diffractive optical element in the application of the optical system[J].Yun Guang Ji Shu，2002，34（3）：1-7.
李应选.衍射光学元件在光学系统中的应用[J].云光技术，2002，34（3）：1-7.
[2]Zhang Jinliang，Li Junqi.The ultra-precision diamond turning technology[J].Journal of Applied Optics，2003，24（Sup.）：80-87.
张锦亮，李军琪.金刚石超精密切削加工技术[J].应用光学，2003，24（增刊）：80-87.
[3]Blough C G, Rossi M, Mack S K, et al.Single-point diamond turning and replication of visible and near-infrared diffractive optical elements[J].Applied Optics, 1997, 36 (30)：4648-4654.
[4]Liu Qingjing. The diamond turning in the application of the infrared-diffractive optical element manufacture[J].Journal of Laser and Infrared，2001，32(2)：107-109.
刘庆京.金刚石车削在红外衍射光学元件加工中的应用[J].激光与红外，2001，32(2)： 107-109.
[5]Tso P L，Chuang H C. A study on the form error compensation for aspheric lens machining[J].Key Engineering Materials，2003(238239)：369-374.
[6]Rahman M，Heikkaea J，Eappaeainen K.Modeling，measurement and error compensation of multi-axis machine tools.part I：theory [J].International Journal of Machine Tools & Manufacture，2000，40(10)：1535-1546.
[7]Wang Shuxin，Yun Jintian，Zhang Zhifei，et al.Modeling and compensation technique for the geometric errors of five-axis CNC machine tools[J].Chinese Journal of Mechanical Engineering，2003，16(2)：197-201.
[8]Wan Daping，Hu Dejin，Wu Qi，et al.Online grinding wheel wear compensation by image based measuring techniques [J].Chinese Journal of Mechanical Engineering，2006，19(4)：509-513.
[9]Leger J，Holz M，Swanson G，et al.Coherent laser beam addition：an application of binary optics technology[J].Lincoln Laboratory Journal, 1998，1(2)：225-246.
[10]Krystek M. A fast Gauss filtering algorithm for roughness measurements[J].Precision Engineering，1996，19(2)：198-200. -
