多平面全息三维显示及其噪声消除研究

周鹏程, 毕勇, 孙敏远, 亓岩, 张仁栗

周鹏程, 毕勇, 孙敏远, 亓岩, 张仁栗. 多平面全息三维显示及其噪声消除研究[J]. 应用光学, 2014, 35(6): 996-1002.
引用本文: 周鹏程, 毕勇, 孙敏远, 亓岩, 张仁栗. 多平面全息三维显示及其噪声消除研究[J]. 应用光学, 2014, 35(6): 996-1002.
Zhou Peng-cheng, Bi Yong, Sun Min-yuan, Qi Yan, Zhang Ren-li. Multi-plane holographic display and its noise elimination[J]. Journal of Applied Optics, 2014, 35(6): 996-1002.
Citation: Zhou Peng-cheng, Bi Yong, Sun Min-yuan, Qi Yan, Zhang Ren-li. Multi-plane holographic display and its noise elimination[J]. Journal of Applied Optics, 2014, 35(6): 996-1002.

多平面全息三维显示及其噪声消除研究

基金项目:

国家863计划(2013AA030501);中科院光电研究院创新项目(Y30B09A12Y)

详细信息
    通讯作者:

    周鹏程(1990),男,安徽安庆人,硕士研究生,主要从事全息三维显示、计算全息和衍射光学研究。 Email:zhoupengcheng@outlook.com

  • 中图分类号: TN27;O438.1

Multi-plane holographic display and its noise elimination

  • 摘要: 基于层析法和Gerchberg-Saxton迭代算法,计算得到了多个平面构成的三维物体的计算全息图,并将该计算全息图加载于空间光调制器上,获得了具备全视差的三维立体显示。基于以上方法,对灰度图像进行显示,获得了较高的像质。构建了由100个平面组成的立方体,获得了立方体的三维图像。另外,在计算全息图时附加了相位平移函数,消除了由空间光调制器的栅格结构引起的多重衍射像噪声,将能量利用效率提高到原来的379%。这样,可获得高衍射效率、高像质且具备全视差的三维全息显示。
    Abstract: The computer-generated hologram of multi-plane three dimensional object was produced based on chromatography and the Gerchberg-Saxton algorithm. And a three dimensional display with full parallax was obtained by writing the hologram into spatial light modulator. According to this method,the gray image was displayed and high image quality could be got.The cube composed of 100 planes was set up and its 3D image could be obtained.In addition, the phase translation function was added into the computer-generated hologram ,the noise of multi-order diffraction images, which arose from the grid-structure of spatial light modulator, was eliminated substantially,then the energy utilization efficiency was as much as 379% of before. Thus a 3D holographic display of high diffraction efficiency, high image-quality and full parallax can be realized.
  • [1]Yang Guijuan, Mei Yan, Bai Yaxiang, Development and application of holography[J]. Journal of Applied Optics, 2006,27(2): 96-100.
    杨桂娟, 梅妍, 白亚乡. 全息术及其应用[J]. 应用光学,2006,27(2): 96-100.
    [2]Huebschman M, Munjuluri B, Gamer H. Dynamic holographic 3-D image projection[J]. Optics Express,2003,11: 437-445.
    [3]Gabor D. A new microscopic principle[J]. Nature,1948,161: 777-778.
    [4]Lohmann A W,Pairs D. Binary Fraunhofer holograms, generated by computer[J]. Applied Optics,1967,6(1): 1739-1748.
    [5]Yu Zuliang, Jin Guofan, Computer-generated hologram[M]. Beijing: Tsinghua University Press, 1984.
    虞祖良,金国藩. 计算机制全息图[M].北京: 清华大学出版社, 1984.

    [6]Shimobaba T, Nakayama H, Masuda N, et al. Rapid calculation algorithm of Fresnel computer-generated-hologram using look-up table and wavefront-recording plane methods for three-dimensional display[J]. Optics Express,2010,18: 19504-19509.
    [7]Yang Maotian,Ding Jianping. Area encoding for design of phase-only computer-generated holograms[J]. Optics Communications,2002,203: 51-60.
    [8]Gerchberg R W,Saxton W O. A practical algorithm for the determination of phase from image and diffraction plane pictures[J]. Optik,1972,35: 237-246.
    [9]Li Junchang,Xiong Bingheng. Tutorials of information optics [M]. Beijing: Science Press, 2011.
    李俊昌,熊秉衡,信息光学教程[M].北京:科学出版社,2011.
    [10]Yu Yingjie, Wang Tao, Zheng Huadong. Optimization of optoelectronic reconstruction of phase hologram by use of digital blazed grating[J]. Acta Physics Sinica, 2009,58: 3154-3160
    于瀛洁, 王涛, 郑华东. 基于数字闪耀光栅的位相全息图光电再现优化[J]. 物理学报,2009,58: 3154-3160.
     [11]Goodman J W. Introduction to Fourier optics[M]. USA: Roberts and Company Publishers, 2005.
