基于像差校正的望远系统装调方法研究

李莉; 李刚; 徐春梅; 沈洪斌; 王元铂; 殷建玲

基于像差校正的望远系统装调方法研究

军械工程学院电子与光学工程系,河北石家庄 050003

详细信息

通讯作者:
李莉（1981-），女，河北邢台人，硕士，讲师，主要从事光学设计、光电装备检测技术方面的研究。 Email：liliopt@163.com

中图分类号: TN248.1;TP39
计量
- 文章访问数: 1618
- HTML全文浏览量: 121
- PDF下载量: 203
出版历程
- 刊出日期: 2014-10-14

Assembly and adjustment method based on aberrations correction for telescope optical system

School of Electronics and Optic Ordnance Engineering College,Shijiazhuang 050003,China

摘要

摘要: 为了保证望远镜装配完成后的成像质量和其他关键指标，提出基于像差校正的望远镜装调方法。首先利用Zemax建立光学系统模型，模拟光学零件失调状态，分析各零件的每种失调状态对各类像差的影响情况，进而定量计算光学零件对系统像差的敏感矩阵，得出系统失调特性，拟定最佳装调方案。在此理论分析的指导下，进行基于星点检验法的装调实验，装调后仪器各项指标达到要求，分辨率优于技术指标要求7.5，验证了基于像差校正的光学系统装调方案的可行性。
- 光学系统装调 /
- 像差 /
- Zemax /
- 望远镜
Abstract: In order to ensure the imaging quality of certain type telescope at assembly stage, an alignment method based on aberrations correction was proposed. The optical system model of this telescope was set up and the misalignment phenomena for every optical element was simulated to analyze the changes of aberrations, then the sensitivity matrix of optical element for aberrations was calculated and the best alignment scheme was determined to improve the assembly quality and efficiency.Finally the alignment experiment based on star test was conducted, the results show that the technique indicators are all satisfied after alignment and the resolution is better than required 7.5,which could validate the feasibility of our method and offer operability for the assembly and adjustment of this kind of instrument.
- optical system assembly and alignment /
- aberration /
- Zemax /
- telescope

HTML全文

参考文献(1)

［1］Yang Hosoon, Kang Myungseok , Kim Sunghee, et al. Development of Cassegrain type 0.9 m collimator［J］. SPIE, 2005, 5869,:586913-1.
［2］Jin Chunshui，Wang Liping，Zhang Lichao, et al. Development of an experimental EUVL system［J］. SPIE, 2007, 6724:672408.
［3］Liu Ke，Li Yanqiu, Liu Jingfeng, et al. Computer aided alignment of a 20× schwarzschild projection optics［J］. SPIE, 2008, 7130:713042.
［4］Kim E D, Choi Youngwan, Kang Myungseok, et al. Lessons learned from the optics and focal plane alignment of a wide field of view RC telescope［J］.SPIE, 2005, 5877:58770C.
［5］Zhao Xiting, Jiao Wenchun, Liao Zhibo, et al. Study on computer-aided alignment method of a three-mirror off-axis aspherical optical system［J］. SPIE, 2010, 7656 :76566M.
［6］Che Chicheng, Li Yingcai, Fan Xuewu. Research on computer-aided alignment based on vector aberration theory[J]. Acta Photonica Sinica, 2008， 37(8): 1630-1634.
车驰骋,李英才,樊学武.基于矢量波像差理论的计算机辅助装调技术研究[J].光子学报，2008，37（8）:1630-1634.
［7］Born M. Principles of optics[M]. 7th ed.Beijing: Publishing House of Electronics Industry, 2009.
波恩·埃米尔·沃尔夫.光学原理[M].7版.北京：机械工业出版社，2007.
［8］Focus Software Incorporated .ZEMAX optical design program users guide[M].NewYork: Focus Software Incorporated, 2009.
［9］Li Xuyang, Li Yingcai, Ma Zhen, et al. Computer aided alignment method of coaxial three-mirror-anastigmat system[J].Journal of Applied Optics, 2009, 30(6): 901-906.
李旭阳，李英才，马臻,等.折轴三反射光学系统的计算机辅助装调技术研究[J].应用光学，2009，30（6）:901-906.
［10］Han Juan, Duan Jiayou, Zhang Jun. Alignment method for large aperture aspheric mirror[J]. Journal of Applied Optics, 2012, 33(3),:490-495.
韩娟，段嘉友，张钧.大口径非球面主反射镜的装调方法研究[J].应用光学，2012，33（3）:490-495.
［11］Sha Dingguo. Optical testing technology[M].Beijing.:Beijing Institute of Technology Press, 2010.
沙定国.光学测试技术[M].北京:北京理工大学出版社，2010.
