GaAs多结电池宽光谱ZnS/Al2O3/MgF2减反射膜的设计与分析

肖祥江, 涂洁磊, 白红艳

肖祥江, 涂洁磊, 白红艳. GaAs多结电池宽光谱ZnS/Al2O3/MgF2减反射膜的设计与分析[J]. 应用光学, 2014, 35(4): 670-674.
引用本文: 肖祥江, 涂洁磊, 白红艳. GaAs多结电池宽光谱ZnS/Al2O3/MgF2减反射膜的设计与分析[J]. 应用光学, 2014, 35(4): 670-674.
shu
Xiao Xiang-jiang, Tu Jie-lei, Bai Hong-yan. ZnS/Al2O3/MgF2 antireflection coating with wide spectrum forGaAs multi-junction solar cells[J]. Journal of Applied Optics, 2014, 35(4): 670-674.
Citation: Xiao Xiang-jiang, Tu Jie-lei, Bai Hong-yan. ZnS/Al2O3/MgF2 antireflection coating with wide spectrum forGaAs multi-junction solar cells[J]. Journal of Applied Optics, 2014, 35(4): 670-674.
shu

GaAs多结电池宽光谱ZnS/Al2O3/MgF2减反射膜的设计与分析

  • 云南师范大学 太阳能研究所,教育部可再生能源材料先进技术与制备重点实验室,云南省农村能源工程重点实验室,云南 昆明 650092

详细信息
    作者简介:

    肖祥江（1987-），男，云南红河人，硕士研究生，主要从事光伏科学与工程专业研究工作。 Email：xxjiang918@126.com

    通讯作者:

    涂洁磊，教授，主要从事光伏科学与工程专业研究。Email：km-tjl@263.net

  • 中图分类号: TN202

ZnS/Al2O3/MgF2 antireflection coating with wide spectrum forGaAs multi-junction solar cells

  • Education Ministry Key Laboratory of Renewable Energy Advanced Materials and Manufacturing Technology,Yunnan Provincial Key Laboratory of Renewable Energy Engineering,Solar Energy Research Institute,Yunnan Normal University,Kunming 650092,China

摘要

    摘要
  • 摘要: 为了提高砷化镓(GaAs)多结太阳电池的光电转换效率，设计了宽光谱(300 nm～1 800 nm)ZnS/Al2O3/MgF2三层减反射膜，分析了各层的厚度及折射率对三层膜系有效反射率的影响。结果表明： 对于整个波长，ZnS厚度对有效反射率的影响要大于Al2O3和MgF2，MgF2厚度对有效反射率的影响最小；适当减小MgF2的折射率或增加ZnS的折射率可得到更低的有效反射率。同时，当 ZnS，Al2O3和MgF2的最优物理厚度分别为52.77 nm，82.61 nm，125.17 nm时，此时最小有效反射率为2.31％。
    Abstract: ZnS/Al2O3/MgF2 three-layer antireflection coating with wide spectrum (300 nm～1800 nm) was designed in order to improve the photoelectric conversion efficiency of GaAs multi-junction solar cells. The influence of each layer-s thickness and refractive index on the effective reflectance of film system was analyzed. The results show that the impact of the film thickness of ZnS is greater than that of Al2O3 and MgF2 on the effective reflectance in the whole wavelength,and the impact of MgF2 is the lowest; decreasing the refractivity of MgF2 or increasing the refractivity of ZnS proportionally can get lower effective reflectance. Furthermore, when the optimal physical thickness of ZnS,Al2O3 and MgF2 is 52.77 nm，82.61 nm and 125.17 nm respectively by programming calculation,the minimum effective reflectance is 2.31％.
    • HTML全文
    • 参考文献(1)
  • [1]Yang Wenhua, Li Hongbo, Wu Dingxiang. Design and analysis of anti-reflection coating for solar cells[J].Journal of Shanghai University, 2004, 10(1):39-41.
    杨文华，李红波，吴鼎祥. 太阳电池减反射膜设计与分析[J].上海大学学报，2004，10(1)：39-41.
    [2]Al-Bustani A, Feteha M Y. Design of antireflection coatings for triple hetero junction AlGaAs-GaAs spacesolar cells[J]. IEEE Xplore, 1995:55-60.
    [3]Schubert M F, Mont F W, Chhajed S, et al. Design of multilayer antireflection coatings made from co-sputtered and low-refractive-index materials by genetic algorithm[J]. Opt. Express, 2008, 16(8):5290-5298.
    [4]Stan M, Aiken D, Cho B, et al. Very high efficiency triple junction solar cells grown by MOVPE[J]. Journal of Crystal Growth, 2010, 312(23): 5204-5208.
    [5]King R R, Law D C, Edmondson K M, et al. Advances in high-efficiency III-V multijunction solar cells[J]. Advances in OptoElectronics, 2007, 2007:29523-1-8.
    [6]Friedman D. Progress and challenges for next-generation high-efficiency multijunction solar cells[J]. Current Opinion in Solid State and Materials Science, 2010, 14(6):131-138.
    [7]Wu Suyong, Long Xingwu. Optimal design of antireflective films based on genetic algorithms[J].Journal of Applied Optics, 2004, 25(4):542-546.
    吴素勇，龙兴武. 基于遗传算法的减反射膜的优化设计[J].应用光学, 2004, 25(4):542-546.
    [8]Valdivia C E, Desfonds E, Masson D, et al. Optimization of antireflection coating design for multi-junction solar cells and concentrator systems[J]. SPIE, 2008, 7099:70915.
    [9]Yang Wenhua. Design and analysis of anti-reflection coating for solar cells[D]. Shanghai:Shanghai University, 2004.
    杨文华.太阳电池减反射膜设计研究[D].上海：上海大学，2004.
    [10]Xiao Xiangjiang, Tu Jielei. Analysis of reflectance performance of TiO2/SiO2 antireflection coating on GaAs substrate[J]. Journal of Synthetic Crystals, 2012, 41(1):70-73.
    肖祥江，涂洁磊. GaAs基底TiO2/SiO2双层减反射膜的设计与制备[J].人工晶体学报，2012，41(1)：70-73.
    [11]Lu Jinjun, Liu Weiguo. Optical thin film technology[M]. Xi-an: Xi-an University of Technology Industry Press, 2005.
    卢进军，刘卫国.光学薄膜技术[M].西安：西安工业大学出版社，2005.
    [12]Yuan Hairong, Xiang Xianbi, Chang Xiulan, et al. Double layer antireflection coating on AlxGa1-xAs/GaAs solar cells[J]. Acta Energiae Solaris Sinica, 2000, 21(4):372.
    袁海荣，向贤碧，常秀兰, 等.AlxGa1-xAs/GaAs太阳电池MgF2/ZnS双层减反射膜的研究[J].太阳能学报， 2000，21(4)：372.
    [13]Palik E D. Handbook of optical constant of solids[M].America:Academic Press,1985.
    [14]Tan Tianya, Huang Jianbing, Zhan Meiqiong, et al. Design of 1 064 nm, 532 nm, 355 nm frequency-tripled antireflection coating for LBO[J]. Acta Optica Sinica, 2007, 27(7): 1327-1332.
    谭天亚，黄建兵，占美琼, 等. 三硼酸锂晶体上1 064 nm，532 nm，355 nm三倍频增透膜的设计[J]. 光学学报，2007，27(7)：1327-1332.
    [15]Luo Xiaolan. Design and preparation of TiO2based antireflection films[D]. Changsha: Hunan University, 2011:17-19.
    罗小兰. TiO2系光学减反膜的设计与制备[D].长沙：湖南大学, 2011:17-19.
