聚对二甲苯薄膜的制备及其在有机电致发光二极管中的应用研究

胡永茂; 李汝恒; 何鋆; 张学清; 李茂琼; 朱艳

聚对二甲苯薄膜的制备及其在有机电致发光二极管中的应用研究

1.
大理学院工程学院,云南大理 671003;
2.
复旦大学应用表面物理国家重点实验室,上海 200433;
3.
昆明理工大学材料科学与工程学院,云南昆明 650093

详细信息

作者简介:
胡永茂（1974-），男，云南洱源人，博士，副教授，主要从事半导体功能材料与器件研究工作。 Email:yongmaohu@163.com

中图分类号: TN202；O469
计量
- 文章访问数: 1563
- HTML全文浏览量: 105
- PDF下载量: 217
出版历程
- 刊出日期: 2014-07-14

Preparation of Parylene-N ultrathin films and their applications in organic light emitting diodes

1.
School of Engineering,Dali University,Dali 671003,China;
2.
State Key Laboratoryof Surface Physics,Fudan University,Shanghai 200433,China;
3.
Faculty of Materials Scienceand Engineering,Kunming University of Science and Technology,Kunming 650093,China

摘要

摘要: 使用自制的分子束源制备了聚对二甲苯（ParyleneN，PPXN）薄膜。通过对该分子束源的设计和不断优化，PPXN薄膜可以在室温、10-3 Pa的较低反应压强下以0.01 nm/s~0.02 nm/s的速率沉积聚合。用红外透射光谱和原子力显微镜测量了PPXN薄膜的成分和表面形貌。结果表明，所制备的薄膜成分为PPXN，薄膜呈波浪状、无尖刺的表面形貌。准确控制的PPXN薄膜在有机电致发光二极管中用作缓冲层，对载流子的注入和传输进行调控，有效地改善了器件内部的载流子平衡。最优化结构的器件较未插入PPXN缓冲层的器件，电流效率提高80%以上。
- 聚对二甲苯 /
- 分子束源 /
- 缓冲层 /
- 有机电致发光二极管 /
- 电流效率
Abstract: Ultrathin poly-p-xylylene (PPXN) films were prepared by using a home-made Knudsen cell (KC). By special design and optimization of the KC, the growth rate was well controlled in the range of 0.01nm/s -0.02 nm/s at room temperature in a relatively lower reaction pressure of 10-3 Pa. The PPXN films were identified by infrared (IR) spectra. The morphology of PPXN films were measured by atomic force microscope (AFM). It was resulted that the PPXN surface showed a spike-free undulated morphology. The well controlled PPXN thin films were used as buffers in organic light emitting diodes to control carrier injection and transport, and improvements of more than 80% in device current efficiency were achieved.
- Parylene-N /
- Knudsen cell /
- buffer layer /
- organic light emitting devices /
- current efficiency

HTML全文

参考文献(1)

[1]Lee T, Lee J, Park C. Characterization of parylene deposition process for the passivation of organic light emitting diodes [J]. Korean J. Chem. Eng., 2002, 19(4): 722-727.
[2]Kim N, Potscavage W J, Domercq J B, et al. A hybrid encapsulation method for organic electronics [J]. Appl. Phys. Lett., 2009, 94（16）: 163308-1-3.
[3]Yoon Y S, Park H Y, Lim Y C, et al. Effects of parylene buffer layer on flexible substrate in organic light emitting diode [J]. Thin Solid Films, 2006, 513: 258-263.
[4]Sohna S, Kima K, Khoa S, et al. Effects of plasma polymerized para-xylene intermediate layers on characteristics of flexible organic light emitting diodes fabricated on polyethylene terephthalate substrates [J]. Journal of Alloys and Compounds, 2008, 449: 191-195.
[5]Yamashita K, Mori T, Mizutani T. Encapsulation of organic light-emitting diode using thermal chemical-vapour-deposition polymer film [J]. J. Phys. D: Appl. Phys., 2001, 34 : 740-743.
[6]Najafov H, Lee B, Zhou Q, et al. Observation of long-range exciton diffusion in highly ordered organic semiconductors [J]. Nature Materials, 2010, 9: 938-943.
[7]Ou Y, Wang P I, Vanamurthy L H, et al. Thermal stability study of pore sealing using parylene N [J]. Journal of the Electrochemical Society, 2008, 155(10): H819-H822.
[8]Jeong Y S, Ratier B, Moliton A, et al. UV-visible and infrared characterization of poly(p-xylylene) films for waveguide applications and OLED encapsulation [J]. Synthetic Metals, 2002, 127: 189-193.
[9]Ke L, Kumar R S, Zhang K, et al. Organic light emitting devices performance improvement by inserting thin parylene layer [J]. Synthetic Metals, 2004, 140: 295-299.
[10]Hu Y M, He Y, Chen X Q, et al. Obvious efficiency enhancement of organic light-emitting diodes by parylene-N buffer layer [J]. Appl. Phys. Lett., 2012, 100: 163303.
[11]Hu Y M, He Y, Chen X Q, et al. Insertion of parylene-N films in electron transport layer: An effective approach for efficiency improvement of organic light emitting diodes [J]. J. Appl. Phys., 2012, 112: 104505.
[12]Ganguli S, Agrawal H, Wang B, et al. Improved growth and thermal stability of Parylene films [J]. J. Vac. Sci. Technol., 1997, 15(6): 3138-3142.
[13]Yang R, Ganguli S, Karcz J, et al. High deposition rate parylene films [J]. J. Cryst. Growth, 1998, 183: 385-390.
[14]Bae I S, Cho S H, Lee S B, et al. Growth of plasma-polymerized thin films by PECVD method and study on their surface and optical characteristics [J]. Surface & Coatings Technology, 2005, 193: 142-146.
[15]Achyuta A K H, White A J, Lewis H G P, et al. Incorporation of linear spacer molecules in vapor-deposited silicone polymer thin films [J]. Macromolecules, 2009, 42: 1970-1978.
[16]Kahouli A, Sylvestre A, Ortega L, et al. Structural and dielectric study of parylene C thin films [J]. Appl. Phys. Lett., 2009, 94(15): 152901-1-3.
[17]Zhao J M, Zhang S T, Wang X J, et al. Dual role of LiF as a hole-injection buffer in organic light-emitting Diodes [J]. Appl. Phys. Lett., 2004, 84: 2913.
[18]Senkevich J J, Wang P I. Molecular layer chemistry via parylenes[J]. Chem. Vap. Deposition, 2009, 15: 91-94.
[19]Mallikarjunan A, Murarka S P, Lu T M. Metal drift behavior in low dielectric constant organosiloxane polymer [J]. Appl. Phys. Lett., 2001, 79(12): 1855-1857.
[20]Zhang S T, Wang Z J, Zhao J M, et al. Electron blocking and hole injection: The role of N,N′Bis(naphthalen-1-y)N, N′bis(phenyl) benzidine in organic light-emitting devices [J]. Appl. Phys. Lett., 2004, 84(15): 2916-2918.
